Simoniz PLATINUM XG03/039-8042-2 Use And Care Manual

Gas pressure washer 3050 psi / 2.8 gpm
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3050 PSI / 2.8 GPM
GAS PRESSURE WASHER
MODEL: XG03/ 039-8042-2
Use and Care Guide
Congratulations on the purchase of your new pressure washer. In
order to ensure you have the best possible experience, please read
through the following instructions. If you require any help, please
contact the customer service department at:
1-866-474-6664
Version. 01
Contact us for assistance; we're here to help.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLATINUM XG03/039-8042-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simoniz PLATINUM XG03/039-8042-2

Summary of Contents for Simoniz PLATINUM XG03/039-8042-2

  • Page 1 3050 PSI / 2.8 GPM GAS PRESSURE WASHER MODEL: XG03/ 039-8042-2 Use and Care Guide Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience, please read through the following instructions. If you require any help, please contact the customer service department at: 1-866-474-6664 Version.

  • Page 2: Table Of Contents

    Table of Contents 1. Important Precautions ............... 3 1.1 Definitions ............................3 1.2 Safety Warnings ..........................3 2. Intended Applications ................. 7 3. Exploded View ................... 8 4. Parts List ................... 8 5. Assembly Instructions ................ 9 5.1 Surface Preparation ........................9 5.2 Water Supply (Cold Water Only) ....................

  • Page 3: Important Precautions

    MODEL : XG03/ 039-8042-2 Important Precautions 1. Important Precautions FLAMMABLE AND COMBUSTIBLE MATERIALS IMPORTANT, RETAIN FOR FUTURE REFERENCE AND READ CAREFULLY! Alerts against the presence of materials/gases which can be extremely flammable. Do not attempt to install or operate this device until you have read the safety instructions in this manual.
  • Page 4 1. Important Precautions CAUTION — HOT ENGINE AND MUFFLER 1.2 Safety Warnings THE ENGINE AND MUFFLER BECOME VERY HOT DURING AND AFTER USE. DANGER — WORK AREA SAFETY AVOID TOUCHING THE ENGINE OR THE MUFFLER DURING OR AFTER USE. AND EXHAUST FUMES •...
  • Page 5 MODEL : XG03/ 039-8042-2 1. Important Precautions CAUTION–ENGINE SAFETY 1.2 Safety Warnings • Certain components in this product and its related accessories contain chemicals which are known to FLAMMABLE AND POISONOUS cause cancer, birth defects, or other reproductive MATERIALS harm. Wash hands after handling. •...
  • Page 6 Important Precautions 1. Important Precautions 1.2 Safety Warnings CAUTION — WATER CONNECTIONS • For use with fresh and clean water only. Do not use this product with other liquids. CAUTION — SPECIFIC SAFETY • The water supply system must be protected against backflow.

  • Page 7: Intended Applications

    Ensure proper maintenance. Check for for suggested applications. For questions regarding other misalignment or binding of moving parts, breakage uses, please refer to our website at www.simoniz.ca or call of parts and other conditions that may affect the us at 1-844-474-6664.

  • Page 8: Exploded View

    Exploded View / Parts List 3. Exploded View 4. Parts List Item # Part Name Qty. Part # Part Name Diagram Qty. Quick-Connect Wand XG03-020-0002 Extension Wand XE32-020-0001 Spark Plug Wrench Gun Assembly XG03-020-0003 Project Tips (X5) 1 set XG03-020-0004 Engine Oil Funnel Pressure Hose XG02-050-0004...

  • Page 9: Assembly Instructions

    MODEL : XG03/ 039-8042-2 Assembly Instructions 5. Assembly Instructions 5.4 Assembly 5.1 Surface Preparation Before beginning any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture.
  • Page 10 Assembly Instructions Assembly Instructions 5. Assembly Instructions 0˚ 15˚ 25˚ 40˚ Soap Connect garden hose to pump inlet and water supply To install tip, gently slide the collar back before respectively. Turn water on. inserting it, then release the collar to lock the tip. Attach the desired spray tip to the wand.

  • Page 11: Engine Operation

    MODEL : XG03/ 039-8042-2 Engine Operation Engine Operation 6. Engine Operation 6.1 Adding/Checking Oil TIP: When adding oil use provided oil funnel. IMPORTANT Oil has been drained for shipping. Failure to fill engine with oil before starting engine will result in permanent damage and will void engine warranty.

  • Page 12: Adding Fuel

    Engine Operation 6. Engine Operation 6.2 Adding Fuel WARNING • Make sure there is enough fuel in the fuel tank before operating the pressure washer. • Use only clean, fresh, unleaded fuel. Use a minimum of 87 octane/87 AKI (91 RON). •...

  • Page 13: Checking Air Filter

    MODEL : XG03/ 039-8042-2 Engine Operation 6. Engine Operation 6.3 Checking Air Filter 6.4 Purging Release the safety trigger if it is locked. PURGING Detach air cleaner cover, unscrew the wingnuts, then pull out the foam element carefully. Wash it with clean water.

  • Page 14: Starting Engine

    Engine Operation 6. Engine Operation 6.5 Starting Engine 1. Set the engine I/O switch to ON (I) position. 2. Move the throttle control to LEFT position. 3. Move the fuel valve to RIGHT position 4. Move the choke lever to LEFT position. 5.

  • Page 15: Stopping Engine

    MODEL : XG03/ 039-8042-2 Engine Operation 6. Engine Operation 6.6 Stopping Engine 3. Set the engine I/O switch to OFF (O) position. 1. To stop the engine move the choke lever to the LEFT position. IMPORTANT Restarting the engine after running it for over 5 minutes, place the choke lever to RIGHT position to restart the engine.

  • Page 16: Working With Detergent

    Follow Engage the safety lock on the detergent manufacturer’s directions or call the the spray gun. Simoniz® toll-free number at 1-866-4SIMONIZ (1-866- 474-6664) if you have any questions or concerns. IMPORTANT Working with a detergent ensures quick soaking of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively.

  • Page 17: Shutting Down And Cleaning Up

    MODEL : XG03/ 039-8042-2 Engine Operation 6. Operating Instructions 6.8 Shutting Down and Cleaning Up Turn off water supply and disconnect the CAUTION garden hose from the water inlet on the pressure washer. Failure to clean this product properly will cause the detergent injection system to become clogged and Pull the trigger to release any remaining water inoperable.

  • Page 18: Cleaning And Maintenance

    Cleaning and Maintenance 7. Cleaning and Maintenance 7.3 Engine Maintenance 7.1 Cleaning the Spray Tips Draining Engine Oil CAUTION The engine oil should be replaced after the first 20 hours of operation, or after the first month of use. After that, it should Clogging of the spray tip increases the water pressure be replaced every 100 hours or every 6 months.

  • Page 19: Engine Maintenance

    MODEL : XG03/ 039-8042-2 Cleaning and Maintenance 7. Cleaning and Maintenance 7.4 Short Term Storing 7.3 Engine Maintenance (cont.) Store idle product out of the reach of children and do 2. Using provided spark plug wrench, remove the spark plug not allow persons unfamiliar with the product or these by turning it counter-clockwise.

  • Page 20: Winterizing And Long-Term Storage

    Winterizing 7. Cleaning and Maintenance 8. Winterizing and Long-Term Storage 7.5 Long Term Storing (cont.) 8.1 Optimum Winterizing Procedure 3. Drain Oil Winterizing your pressure washer will help protect and a. Drain the oil following the “To Drain the Engine Oil” prolong its life.

  • Page 21: Technical Specifications

    MODEL : XG03/ 039-8042-2 Technical Specifications 9. Technical Specifications Peak Pressure: 3050 PSI Rated Max Pressure: 2400 PSI Rated Water Flow: 2.8 GPM (10.6 LPM) Minimum Inlet Pressure: 30 PSI Maximum Inlet Pressure: 100 PSI Pump Type: Heavy-duty maintenance-free cam Thermal Relief Valve: Included Maximum Temperature of Pumped Water:...

  • Page 22: Troubleshooting

    Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution The engine power switch is in the OFF (0) position. Ensure the switch is in the ON (I) position. No fuel. Fill the fuel tank with regular gasoline. Low oil shut down sensor tripped to protect engine.
  • Page 23 High pressure hose can’t be The O-rings are not lubricated. Put lubricating oil or water on the O-rings. connected to pump or gun. IF YOU ENCOUNTER ANY ADDITIONAL DIFFICULTIES NOT LISTED, VISIT OUR WEBSITE AT www.simoniz.ca OR CALL CUSTOMER SERVICE FOR HELP AT 1-866-474-6664...

  • Page 24: Warranty

    The warranty is void if the equipment is used for commercial, rental or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-474-6664. Made in China...

  • Page 25: Hearing Protection

    MODEL : XG03/ 039-8042-2 Icons Definitions 12. Icons Definitions Hearing Protection This Way Up To protect hearing from the device noise, When handling product, arrows must always wear hearing protection while operating the point up. device. Store Indoors Stacking Limitation To avoid damage from freezing, store indoors Shows maximum stacking height, in units.
  • Page 26 Note...
  • Page 27 MODEL : XG03/ 039-8042-2 Note...
  • Page 28 3050 PSI / 2.8 GPM GAS PRESSURE WASHER MODEL: XG03 / 039-8042-2 Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8...
