2300 PSI / 2.0 GPM
PRESSURE WASHER
MODEL: XE 32 / 039-8123-0
Use and Care Guide
Congratulations on the purchase of your new pressure washer. In
order to ensure you have the best possible experience please read
through the following instructions. If you require any help, please
contact the customer service department at:
1-866-474-6664
Version. 01
Contact us for assistance; we're here to help.
Advertisement
Table of Contents
Related Manuals for Simoniz PLATINUM XE 32
Summary of Contents for Simoniz PLATINUM XE 32
- Page 1 2300 PSI / 2.0 GPM PRESSURE WASHER MODEL: XE 32 / 039-8123-0 Use and Care Guide Congratulations on the purchase of your new pressure washer. In order to ensure you have the best possible experience please read through the following instructions. If you require any help, please contact the customer service department at: 1-866-474-6664 Version.
-
Page 2: Table Of Contents
Table of Contentsw 1. Important Precautions ............... 3 1.1 Definitions ............................3 1.2 Safety Warnings ..........................3 1.3 Intended Applications ........................5 2. Safety Features and Electrical Information ......... 5 2.1 Extension Cords ..........................5 3. Exploded View ................... 6 4. -
Page 3: Important Precautions
MODEL : XE 32 / 039-8123-0 Important Precautions 1. Important Precautions IMPORTANT, RETAIN FOR FUTURE 1.2 Safety Warnings REFERENCE AND READ CAREFULLY! DANGER Do not attempt to install or operate this device until you have read the safety instructions in this manual. Safety items To reduce the risk of fire, electric shock, explosion or throughout this manual are labelled with Danger, Warning, injury to people, read the following:... - Page 4 Important Precautions 1. Important Precautions CAUTION — USE • Learn how to stop the device and release the 1.2 Safety Warnings pressure quickly. Familiarize yourself with the controls. • Keep all connections dry and off the ground. • Avoid accidental starts. Shut power OFF before WARNING —...
-
Page 5: Intended Applications
This equipment was not instructions listed below: designed for industrial use. Please refer to the icons below for suggested applications. For questions regarding other uses, please refer to our website at www.simoniz.ca or call CAUTION — USE A SUFFICIENT us at 1-844-474-6664. GAUGE •... -
Page 6: Exploded View
Exploded View / Parts List 3. Exploded View 4. Parts List Item # Part Name Qty. Part # Item # Part Name Qty. Part # Quick-connect Wand XE16-020-0002 Wand Holder XE32-020-0006 Extension Wand XE32-020-0001 Gun Holder XE32-020-0007 Gun Assembly XE32-020-0003 Up-handle Assembly XE32-300-0000 1 set... -
Page 7: Assembly Instructions
MODEL : XE 32 / 039-8123-0 Assembly Instructions 5. Assembly Instructions 5.4 Assembly 5.1 Surface Preparation Before beginning any cleaning task, it is important to inspect the area for objects that could create a hazard. Remove any objects from the work area that could be tripped over, such as toys or outdoor furniture. -
Page 8: Assembly Steps
Assembly Instructions 5. Assembly Instructions 0˚ 15˚ 25˚ 40˚ Connect garden hose to pump inlet and water supply respectively. Turn water on. To install tip, gently slide the collar back before inserting it, then release the collar to lock the tip. Attach the desired spray tip to the wand. - Page 9 MODEL : XE 32 / 039-8123-0 Assembly Instructions 5. Assembly Instructions PURGING Turn switch clockwise to ON (I) to turn on the machine. Turn the switch counter-clockwise to OFF (O) to turn off the machine. Purge air by squeezing the trigger on the gun until there is a steady stream of water CAUTION Drain unit after each use (for storage): remove water...
-
Page 10: Operating Instructions
Operating Instructions 6. Operating Instructions 6.1 Working with Foam Blaster Working with a detergent ensures quick soaking of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively. Always spray detergent on a dry surface, do not pre-soak the area. Wetting the surface first dilutes the detergent and reduces its cleaning ability. -
Page 11: Shutting Down And Cleaning Up
MODEL : XE 32 / 039-8123-0 Operating Instructions 6. Operating Instructions 6.2 Shutting Down and Cleaning Up 6.4 Warnings Turn off water supply and disconnect the CAUTION garden hose from the water inlet on the pressure washer. Failure to clean this product properly will cause the detergent injection system to become clogged and Pull the trigger to release any remaining water inoperable. -
Page 12: Winterizing And Long-Term Storage
Winterizing 7. Winterizing and Long-Term Storage 7.1 Optimum Winterizing Procedure 7.2 Quick Winterizing Procedure Winterizing your pressure washer will help protect and If you are unable to perform the optimum winterizing prolong its life. We strongly recommend you follow the below procedure, you can still protect your pressure washer from steps using a pressure washer antifreeze before storing winter damage by doing the following:... -
Page 13: Cleaning And Maintenance
MODEL : XE 32 / 039-8123-0 Cleaning and Maintenance 8. Cleaning and Maintenance 8.3 Water Filter Screen 8.1 Connections The connections on the pressure washer’s hoses, gun, and spray wand should be cleaned and lubricated with non-water soluble grease regularly. The pressure washer is equipped with a water inlet screen to protect the pump. -
Page 14: Troubleshooting
Troubleshooting 10. Troubleshooting Disconnect the device from the power source before making any repairs. Problem Cause Solution The device is in OFF mode. Turn main switch button to “I” position. The power cord is not plugged in. Plug in the power cord. The extension cord is too long. - Page 15 No water coming out of the nozzle. Kink in the garden hose. Remove the kink in the garden hose. IF YOU ENCOUNTER ANY ADDITIONAL DIFFICULTIES NOT LISTED, VISIT OUR WEBSITE AT www.simoniz.ca OR CALL CUSTOMER SERVICE FOR HELP AT 1-866-474-6664...
-
Page 16: Warranty
The warranty is void if the equipment is used for commercial, rental or industrial purposes. If you have further questions, please visit our website (www.simoniz.ca) or call 1-866-474-6664. If you have further questions, please contact us at support@activeproducts.com or call 1-844-777-4555. -
Page 17: Icons Definitions
MODEL : XE 32 / 039-8123-0 Icons Definitions 12. Icons Definitions Hearing Protection This Way Up To protect hearing damage from the device When handling product, arrows must always noise, wear hearing protection while point up. operating the device. Store Indoors Stacking Limitation To avoid damage from freezing, store indoors Shows maximum stacking height, in units. - Page 18 Notes...
- Page 19 MODEL : XE 32 / 039-8123-0 Notes...
- Page 20 2300 PSI ELECTRIC PRESSURE WASHER MODEL: XE 32 / 039-8123-0 Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8...
