SERVICE PROCEDURE
Replacing Switch Box JSS
Applicable Model(s)
Jobsite Table Saws (JSS-MCS) (JSS-120A60)
Tools Needed
13mm combination wrench
•
•
Needle nose pliers
•
5mm hex wrench
#2 Phillips screwdriver
•
•
Assistant to help flip the saw
Part(s) or Service Kit(s) Needed
•
For Model JSS-120A60 -
•
For Model JSS-MCA -
PROCEDURE SUMMARY
This procedure instructs how to remove and replace the switch box assembly on the Jobsite Saw.
SAFETY
WARNING:
Disconnect the plug from the power source from the tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
WARNING:
Wear gloves when handling the saw blade.
WARNING:
When servicing your tool, use only replacement parts from SawStop.
WARNING:
Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles
and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
WARNING:
Read and understand the instruction manual and all safety warnings that came with your
tool before attempting to maintain or operate the tool. Failure to follow instructions or heed warnings
may result in electric shock, fire, serious personal injury or property damage. Save these instructions and
refer to them whenever necessary.
SawStop.com/support
JSS-457
JSS-124
For questions, contact SawStop Technical Support
Phone: 503-582-9934 / Email:
service@sawstop.com
071124
