Bradley S19-120SSBF Installation

Barrier free stainless steel drench shower - horizontal supply

Advertisement

Quick Links

For questions regarding the operation, installation or maintenance of this product, visit bradleycorp.com
or call 800.BRADLEY (800.272.3539).
Product warranties and parts information may also be found under "Resources" on our website at bradleycorp.com.
215-1262 Rev. J; ECO 19-05-002F
© 2019 Bradley
Page 1 of 4
8/21/2019
Installation
S19-120SSBF
Barrier Free Stainless Steel Drench
Shower - Horizontal Supply
Table of Contents
Pre-Installation Information ....................................... 2
Installation Instructions ............................................. 3
Assembly of Components ......................................... 4
Parts List ................................................................... 4
Read the instructions in this manual before
beginning installation. Save these instructions
and refer to them for inspection, maintenance
and troubleshooting information.
