Bradley S19-130BF Installation

Drench shower - vertical supply

Download this manual

215-1263 Rev. C; ECN 07-522

Page 1 of 5

8/27/07

Installation

S19-130BF

S19-130ABF

Drench Shower - Vertical Supply

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . 2

Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . 3

S19-130BF Components and Parts List . . . . . . . . . . . . 4

S19-130ABF Components and Parts List . . . . . . . . . . . 5

P.O. Box 309, Menomonee Falls, WI USA 53052-0309

PHONE 1-800-BRADLEY FAX (262) 251-5817

http://www.bradleycorp.com

Need help?

Do you have a question about the S19-130BF and is the answer not in the manual?

Page 1 Installation Instructions ......3 S19-130BF Components and Parts List ... . 4 S19-130ABF Components and Parts List .
Page 2 For questions regarding the operation or installation of this product, visit www. bradleycorp.com or call 1-800-BRADLEY. Product warranties may also be found under ”Product Information” on our web site at www.bradleycorp.com. 8/27/07 Bradley Corporation • 215-1263 Rev. C; ECN 07-522...
Page 3: Installation
Tighten jam nut. Step 2: Connect water supply IMPORTANT: Do not rely on Bradley’s Drench Shower to support supply piping. 1. Connect water supply piping to 1" NPT inlet on unit (piping supplied by installer). Provide adequate supports (supplied by installer) for supply pipe using pipe hangers or other means.
Page 4: Parts List
S19-130BF, S19-130ABF Installation Assembly of Components - S19-130BF (Plastic Showerhead) 1" NPT Supply Inlet P.O. Box 309, Menomonee Falls, WI 53051 TEST THIS UNIT EACH WEEK DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN. ESSAI HEBDOMADAIRE Test-operate valve(s) each week and sign below.
Page 5 Friction Washer 160-138 Screw 128-132 Handle 125-001DP Washer 142-002DC Lockwasher 153-312 Adapter, Celcon S90-365D Pull Rod - 45" Long 114-050 Safety Sign 161-026 Hex Nut 1/4"-20 Stn. Steel 204-421 Emergency Inspection Tag Bradley Corporation • 215-1263 Rev. C; ECN 07-522 8/27/07...

S19-130abf
