215-292 Rev. F; ECN 12-05-016G
© 2012 Bradley
Page 1 of 4
11/12/2012
Installation
S19-130SS
Stainless Steel Drench Shower
Vertical Supply
Table of Contents
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly of Components and Parts List . . . . . . . . . . . . . . . 4
P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX 262.251 5817
bradleycorp.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bradley S19-130SS
Summary of Contents for Bradley S19-130SS
- Page 1 Assembly of Components and Parts List ....4 215-292 Rev. F; ECN 12-05-016G P.O. Box 309, Menomonee Falls, WI USA 53052-0309 © 2012 Bradley PHONE 800.BRADLEY (800.272.3539) FAX 262.251 5817 Page 1 of 4 11/12/2012 bradleycorp.com...
- Page 2 Main water supply to the eyewash should be “ON” at all times. Provisions shall be made to prevent unauthorized shutoff. The ANSI Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed emergency fixtures require a minimum of 30 PSI (0.21 MPa) flowing pressure. Flushing fluid should be tepid per ANSI Z358.1.
- Page 3 84" (2134 mm) from the floor. Step 2: Connect water supply 9" (229mm) IMPORTANT! Do not rely on Bradley’s Drench Shower to support supply piping. 1. Connect water supply piping to 1" NPT inlet All dimensions assume standard thread on unit (piping supplied by installer).
- Page 4 Stainless Steel Showerhead 3.11 161-079 Jam Nut Only 128-156A Pull Rod, 25½" 128-143 Handle S30-062 1" Stay-Open Ball Valve Assembly 114-050 Safety Sign S27-276 1" Ball Valve with Nut 204-421 Emergency Inspection Tag Bradley • 215-292 Rev. F; ECN 12-05-016G 11/12/2012...
