HUCK Seiltechnik Cheops-Pyramide Maxi 4643-3B Assembly Instructions Manual

With anchor plates
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen
Cheops-Pyramide „Maxi" Art.-Nr. 4643-3B
Betreiber:
Standort:
\\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc
seiltechnik@huck.net
•
www.huck.net
A
Assembly Instructions
With Anchor Plates
______________________________________________
______________________________________________
Seiltechnik
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cheops-Pyramide Maxi 4643-3B and is the answer not in the manual?

Questions and answers

Related Manuals for HUCK Seiltechnik Cheops-Pyramide Maxi 4643-3B

Summary of Contents for HUCK Seiltechnik Cheops-Pyramide Maxi 4643-3B

  • Page 1 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Assembly Instructions Cheops-Pyramide „Maxi“ Art.-Nr. 4643-3B With Anchor Plates Betreiber: ______________________________________________ Standort: ______________________________________________ \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 1 -...
  • Page 2 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Revision 0 – 2009-15-09 The first allowed version Assembly instructions JF Revision 5– 2010-04-01 Ø 13 m All rights reserved © Copyright 2006 Huck Seiltechnik GmbH \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 3 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Assembly Instructions Cheops-Pyramide „Maxi“ Art.-Nr. 4643-3B With Anchor Plates ..........................1 Introdution Assembling ....................4 Data sheet: Cheops-Pyramide „Maxi“ Art.-Nr. 4643-3B..........6 Delivery contents (parts list with part numbers)............7 Erection instructions ....................
  • Page 4 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 1 Introdution Assembling General information This equipment should be installed, inspected, maintained and operated in ac- cordance with EN1176-7 guidelines. Before installation work commences, please check that you have all of the equipment and fixation components in the parts list provided (see Tables 3-1 and 3-2).
  • Page 5 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Drawings / Views All optical drawings are showing only the measurements/dimensions and are no mandatory technical views of the complete item. We reserve the right to change technical details of our articles which are serving for the further development of our articles and are reasonable for the customer.
  • Page 6 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 2 Data sheet: Cheops-Pyramide „Maxi“ Art.-Nr. 4643-3B 1. Space requirmentØ 11,00 m and/or Ø 13,00 m including safety zone. Height of fall: 1,70 m Attention! The version with ground anchors has a foundation radius of Ø...

  • Page 7: Delivery Contents (Parts List With Part Numbers)

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 3 Delivery contents (parts list with part numbers) in words Table -3.1: Delivery contents, in words Pos. Quanti- Element / Size O.K Missing Description Steelpost, galv. Ø 159 mm; 6,30 m lg.
  • Page 8 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Pos. Quanti- Element / Size O.K Missing Description Paint brush At customers request 1.5Ltr. Paint At customers request \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 9 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik in symbols Table -3.2: Delivery contents, in symbols Quantity Pos. Symbol Ø 159 mm, 6,30 m long ࡬Ø 360 mm x 12 mm Ø 1250 mm 500 x 500 mm \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 10 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Pos. Quantity Symbol 100 4 M12 x 30 galvinized 101 4 für M12 galvinized 102 16 M16 x 30 galvinized 102a 16 M16 x 30 galvinized (for Ancorplate) 103 16 für M16...
  • Page 11 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Pos. Quantity Symbol 109 1 für M16 110 16 M16galvinized 111 16 10er chain 2,40 m long 112 16 10mm shackle 113 32 galvinized 600 mm lang...

  • Page 12: Erection Instructions

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 4 Erection instructions 12 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 13 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 13 -...
  • Page 14 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 14 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 15 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Connections and Fittings must be Secured with Loctite All screws, nuts and bolts must have loctite applied (except for nylock nuts) \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 15 -...
  • Page 16 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net www.huck.net • Seiltechnik 16 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 17 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 17 -...
  • Page 18 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 18 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 19 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 19 -...
  • Page 20 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 20 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 21 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 21 -...
  • Page 22 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 22 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 23 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 23 -...
  • Page 24 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 24 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...
  • Page 25 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Version: Cheops-Pyramide „Maxi“ (with anchor plates) Use ground pegs to secure anchor plates Anchor chains(All anchor chains are to be equaly fitted! Lefto- ver chain links are to be clipped off after play component has...

  • Page 26: Post Installation Checks

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 5 Post installation checks If the equipment has not been installed safely, you must ensure that the public is prevented from using it. Marking filler depth Labelling the posts to show the depth of material provided as fall protection (i.e.
  • Page 27 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Maintenance instructions Maxi Cheops pyramid (registered design) Art. 4643-3B With Anchor Plates \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 27 -...
  • Page 28 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Revision history Revision 0 – 2009-15-09 The first allowed versionJF Maiantanance instruction Revision 5 – 2010—04-01 Ø 13 m All rights reserved © Copyright 2005 Huck Seiltechnik GmbH 28 - \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc...

  • Page 29: Introduction Maintenance

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 6 Introduction maintenance General information This equipment should be installed, inspected, maintained and operated in ac- cordance with EN1176-7 guidelines. Please note: Providing any necessary repairs are carried out, a piece of play equipment that is inspected regularly cannot become so damaged that it is dangerous.

  • Page 30: General Maintenance Information

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 7 General maintenance information Maintenance intervals Maintenance intervals are based on average use. Please note that more fre- quent inspections and/or maintenance are required if the play equipment is subject to intensive use.
  • Page 31 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Faults must be repaired as soon as they are detected. If serious defects that compromise safety cannot be repaired straight away, the public must be prevented from using the equipment with immediate effect.

  • Page 32: Maintenance Timetable

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 8 Maintenance timetable Special advices 8.1.1 Maintenance interval We strongly advise to carry out inspections and maintenance work within the specified periods as use of the equipment, weather and malicious vandalism cause wear and tear that compromise safety and function of the equipment.

  • Page 33: Regular Maintenance

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 9 Regular maintenance Image \\SOVE-FIL01\felles\Mont-anv-2010\33-100-100 støpefri forankr.doc - 33 -...

  • Page 34: Quarterly Maintenance

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 10 Monthly maintenance 10.1 Check the spaces between the equipment and the ground (clearance and height of fall). 10.2 Check the ground surface in the area with fall protection for hard objects and loose foundations.

  • Page 35: Annual Maintenance

    HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik Annual Maintenance 12 Annual maintenance 12.1 Ascertaining that the equipment, foundations and surfaces are safe for operation. 12.2 In particular, the equipment should be checked for decay and corrosion.
  • Page 36 HUCK Seiltechnik GmbH • Dillerberg 3 • 35614 Asslar-Berghausen seiltechnik@huck.net • www.huck.net Seiltechnik 13 Maintenance Log Name: Cheops-Pyramide „Maxi“ ________________ / Art.-Nr. 4643-3B ________________________________ _____ Location: ________________________________ ________________________________ _______________________ Customer or Operator ________________________________ ________________________________ _____________ (City,Council,Kindergarten) Day of Surveyor or...

  • Page 37: Hand Over Document

    Huck Huck Seiltechnik GmbH • 35614 Aßlar/Berghausen • Germany • www.huck.net seiltechnik@huck.net 14 Hand over document After the installation of the equipment pass the installation and mainte- nance documents to the operator. The operator has to receive the hand over documents. The complete filled and signed hand over document should be sent to the supplier.
