Sumake ST-66342V Original Instructions Manual

Self-general vacuum remove-pro tool w/ rubber erase & hose & dust bag

Advertisement

SUMAKE
Self-General Vacuum Remove-Pro Tool
W/ Rubber Erase & Hose & Dust Bag
Specification:
Free Speed
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
ST-66342V
3950 r/min
10 CFM (283 L/min)
13-3/4" (350 mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
2.91 lbs (1.32 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Sound Pressure Level
Load:
0.4 m/s²
Sound power level
Uncertainty
K= 1.5 m/s
²
Noise
Remark
EN ISO 15744
Please always
load: 82 dB(A)
wear ear
protector at
environment
load: 93 dB(A)
noise level > 80
dB(A) due to
risk of impaired
Uncertainty
hearing!
K= 3dB
ST-66342V-S-1408E-STF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST-66342V and is the answer not in the manual?

Questions and answers

Summary of Contents for Sumake ST-66342V

  • Page 1 > 80 dB(A) due to Air Pressure 90 psi (6.3 bar) risk of impaired Uncertainty Uncertainty hearing! K= 1.5 m/s K= 3dB ² Net Weight 2.91 lbs (1.32 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-66342V-S-1408E-STF...
  • Page 2: Ec Declaration Of Conformity

    DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment: SELF-GENERAL VACUUM REMOVE-PRO TOOL W/RUBBER ERASER Model/ Serial No.:ST-66342V to which this declaration applies, complies with these normative documents: ...
  • Page 3 Application: It is useful for various sanding work, to smooth wood and automotive or wood finishes by abrasion with sandpaper. (Easerr) Pad mounting dangers:  Correct sanding pad mounting is necessary to prevent injury from loosen wheels.  Do not use chipped or cracked sanding pad. Use only wheels fitting the machine easily.
  • Page 4: Parts List

    Hex (3/16") 66342-26 Bearing (6001Z) 66342-61A Hex (5mm) 66342-27A Thread Ring Gear 66342-66 Screw 66342-28 Idler Gear (16T) 66342-67 Rubber Hose & Bag [ST-66342V(VW)] 66342-29 Needle Bearing 66342-68 Pin (3x5) 66342-30 Idler Gear Pin 66342-69 Nut [ST-66342(W)] 66342-31A Gear Plate 66342-70...
  • Page 5 ERASER Original instructions SUMAKE Industrial Co. Ltd.
  • Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
  • Page 7 5. Release the start and stop device in the case of an interruption of the energy supply. 6. Use only lubricants recommended by the manufacturer. 7. Personal protective safety glasses shall be used, suitable gloves and protective clothing are recommended 8.
  • Page 8: Specific Safety Instructions

    Specific safety instructions Warnings shall be given about any specific or unusual hazards associated with the use of the power tool. Such warnings shall indicate the nature of the hazard, the risk of injury and the avoidance action to take. General preparation and connection: Before connecting the air hose, apply 4 to 5 drops of SAE#10-20 spindle oil at the air inlet.
