bouncepad Core Desk Assembly Instructions

Core Desk
Assembly Instructions
Tools Required:
Pencil
Electric Drill
7mm Spanner
*or adjustable spanner
5.0mm Drillbit
*if fixing from below
2.5mm Drillbit
*if fixing from above
16mm *if routing the tablet
cable through your
Holesaw
mounting surface
Socket Driver
Sheet Code: BP-IM-079_REV3
Release Date: 05/08/2024
Copyright 2024 Spotspot Ltd. (T/A
Bouncepad) all rights reserved.
Confidential, no part of this publication
may be reproduced or transmitted in any
form without the written permission of the
copyright holder.
Maximum Mounting
surface thickness :
Metric Imperial
25 mm 1"
Follow steps
A B
A if "Fixing
from below".
Mount Washer
M4 Split washer
M4 Locking Nut
7mm Spanner
Tighten screw(s) using hand tools, using electric
tools may damage your Bouncepad.
Mount Washer
M4 Split washer
M4 Wing Nut
Secure the arm to the
A4
surface. Locking Nuts
offer higher security.
Flat Cable Fixings Kit
Tablet Mounting
Plate
Desk
Mounting
Arm
Surface
Mounting Kit
In the Box
Minimum Mounting
surface thickness :
Metric Imperial
34 mm 1 5/16"
Front
Follow steps
Using the Mount
A1
B if "Fixing
washer, mark the drill
from Above".
hole locations.
*see overleaf
A5
Go to step 1.
4x No.8 4x M4x10mm
Countersunk Countersunk
Self tapping
Screw
4x M4x40mm
Socketset
screw
1x T20 Pin
Torx Driver Bit
Shell
1x Mount 1x Case
Washer Washer
Fixings List
* Due to the modular nature of our product range you may receive additional fixings in the fixings kit
Mount Washer
Ø5.0mm Drillbit
4x Ø5.0mm
1x Ø16.0mm
Drill each hole
A2
- using the
specified drill size.
Mount Plate
4x Ø2.5mm
1x Ø16.0mm
Front
Using the Mount Plate,
B1
mark the drill hole
locations as shown.
4x M4
Screw Wing Nut
4x M4x16mm
Buttonhead
screw
1x Cable
Clamp
Maximum Mounting
surface thickness :
Metric
25
1x Cleaning
Wipe
8x M4 Split 4x M4
Washer Locking Nut
Tighten screw(s)
using hand tools,
using electric tools
may damage your
Bouncepad.
Ø16.0mm
Holesaw
Locate & screw the
A3
Socket screws into the
Desk as shown
Ø2.5mm Drillbit
Ø16.0mm Holesaw
Drill each hole - using the specified
B2
drill sizes.
2x 3mm x 6mm
Pan Head
Screws
4x M3x10mm
Countersunk
Screw
1x T10 Pin Torx
Allen Key
Imperial
1"
mm
Front
M4x40mm
Socketset
screw
