Samba™ OPLC™
The Unitronics SM35-J-T20 offers the following onboard I/Os:
 12 Digital Inputs, configurable via wiring to include 2 Analog and 3 HSC/Shaft-encoder Inputs
8 Transistor Outputs
General Description
The SAMBA SM35-J-T20 OPLC is an All-in-One Programmable Logic Controller that
Comprises a built-in 3.5" Color Touchscreen
Communications
1 built-in serial port: RS232
Optional: the user may install -
- Second RS232/RS485 port (V100-17-RS4/V100-17-RS4X),or
- Ethernet (V100-17-ET2),or
- CANbus (V100-17-CAN)
Kit Contents
Samba controller
I/O connectors (x2)
Battery (installed)
Alert Symbols and General Restrictions
This document uses the following alert symbols to highlight notices that must be observed in order to
ensure personal safety and/or prevent property damages.
Symbol
Meaning
Danger
Warning
Caution
Caution
 Before using this product, the user must read and understand this document.
 All examples and diagrams are intended to aid understanding, and do not guarantee operation.
Unitronics accepts no responsibility for actual use of this product based on these examples.
 Please dispose of this product according to local and national standards and regulations.
 Only qualified service personnel should open this device or carry out repairs.
Failure to comply with appropriate safety guidelines can cause severe injury or property damage.
 Do not attempt to use this device with parameters that exceed permissible levels.
 Do not connect/disconnect the device when power is on.
Environmental Considerations
 Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration, in accordance
with the standards given in the product's technical specification sheet.
 Do not place in water or let water leak onto the unit.
 Do not allow debris to fall inside the unit during installation.
 Ventilation: 10mm space required between controller's top/bottom edges & enclosure walls.
 Install at maximum distance from high-voltage cables and power equipment.
Unitronics
SM35-J-T20
Installation Guide
.
Mounting brackets (x2)
Rubber seal
Description
The identified danger causes physical and property damage.
The identified danger could cause physical and property damage.
Use caution.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Samba OPLC SM35-J-T20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Unitronics Samba OPLC SM35-J-T20

  • Page 1  All examples and diagrams are intended to aid understanding, and do not guarantee operation. Unitronics accepts no responsibility for actual use of this product based on these examples.  Please dispose of this product according to local and national standards and regulations.
  • Page 2: Panel Mounting

    4. Tighten the bracket’s screws against the panel. Hold the bracket securely against the unit while tightening the screw. 5. When properly mounted, the controller is squarely situated in the panel cut-out as shown in the figure to the right. Unitronics...
  • Page 3: Wiring Procedure

    Inputs 1, 3, and 5 can function as either counter reset, as part of a shaft-encoder, or as normal digital inputs. If inputs 0, 2, 4 are set as high-speed counters (without reset), inputs 1, 3, 5 can function as normal digital inputs. Unitronics...
  • Page 4 Set to JP5 (Input 10) JP6 (Input 11) Digital* Analog Analog Inputs AN0/AN1: Set Type Set to JP3 (AN0) JP4 (AN1) Voltage* Current *Default settings I/O Wiring npn Input Wiring Input wiring npn (sink) HSC input wiring, npn (sink) Unitronics...
  • Page 5 Shaft-encoder Analog Input Wiring Analog input wiring, current (2/3 wire) Analog input wiring, current/voltage (4-wire)  Shields should be connected at the signal’s source.  The 0V signal of the analog input must be connected to the controller’s 0V. Unitronics...
  • Page 6: Power Supply

    To maximize system performance, avoid electromagnetic interference by:  Mounting the controller on a metal panel.  Connect each common and ground connection directly to the earth ground of your system. For ground wiring use the shortest and thickest possible wire. Unitronics...
  • Page 7: Communication Port

    Do not force the board into place; doing so may damage the controller. 2. Replace the back cover of the controller and fasten the corner screws. Note that you must replace the back cover securely before powering up the controller. Unitronics...
  • Page 8 SM35-J-T20 Installation Guide The information in this document reflects products at the date of printing. Unitronics reserves the right, subject to all applicable laws, at any time, at its sole discretion, and without notice, to discontinue or change the features, designs, materials and other specifications of its products, and to either permanently or temporarily withdraw any of the forgoing from the market.
