1st PRINTING FEB 02
STANDARD VERSION
OWNER'S MANUAL
SEGA ENTERPRISES, INC. USA
MANUAL NO. 999-1384

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the The King of Route 66 and is the answer not in the manual?

Questions and answers

Related Manuals for Sega The King of Route 66

Summary of Contents for Sega The King of Route 66

  • Page 1 1st PRINTING FEB 02 STANDARD VERSION OWNER’S MANUAL SEGA ENTERPRISES, INC. USA MANUAL NO. 999-1384...
  • Page 2 VISIT OUR WEBSITE!

  • Page 3: Before Using The Product

    BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING: To maintain the safety: To ensure the safe usage of the product, be sure to read the following before using the product. The following instructions are intended for the users, operators and the personnel in charge of the operation of the product. After carefully reading and sufficiently understanding the warning displays and cautions, handle the product appropriately.

  • Page 4: Inspections Immediately After Transporting The Product To The Location

    SEGA shall not be held responsible for any accidents, compensation for damage to a third party, resulting from the specifications not designated by SEGA.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING: TABLE OF CONTENTS INTRODUCTION OF THE OWNER'S MANUAL ..........1 - 3 1. HANDLING PRECAUTIONS................4 2. PRECAUTIONS CONCERNING INSTALLATION LOCATION ....5 3. OPERATION AREA..................6 4.

  • Page 6: Introduction Of The Owners Manual

    29” SANWA COLOR MONITOR INTRODUCTION OF THE OWNERS MANUAL SEGA ENTERPRISES, LTD., has for more than 30 years been supplying various innovative and popular amusement products to the world market. This Owners Manual is intended to provide detailed descriptions together with all the necessary installation, game settings and parts ordering information related to THE KING OF ROUTE 66 STANDARD, a new SEGA product.
  • Page 7 General Precautions Follow Instructions: All operating and use instructions should be followed. Attachments: Do not use attachments not recommended by the product manufacturer as they may cause hazards. Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a child or adult, and serious damage to the product.
  • Page 8 Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

  • Page 9: Handling Precautions

    • SEGA shall not be held responsible for damage, compensation for damage to a third party, caused by specification changes not designated by SEGA.

  • Page 10: Precautions Concerning Installation Location

    2. PRECAUTIONS CONCERNING INSTALLATION LOCATION This product is an indoor game machine. Do not install it outside. Even indoors, avoid installing in places mentioned below so as not to cause a fire, electric shock, injury and or malfunctioning. Places subject to rain or water leakage, or places subject to high humidity in the proximity of an indoor swimming pool and or shower, etc.

  • Page 11: Operation Area

    To avoid machine malfunctioning and a fire, do not place any obstacles near the ventilation opening. SEGA shall not be held responsible for damage, compensation for damage to a third party, resulting from the failure to observe this instruction.

  • Page 12: Precautions To Be Heeded For Operation

    4 . PRECAUTIONS TO BE HEEDED FOR OPERATION In order to prevent accidents, be sure to comply with the following points before and during operation. PRECAUTIONS TO BE HEEDED FOR OPERATION BEFORE STARTING THE OPERATION In order to avoid accidents, check the following before starting the operation: Check if all of the adjusters are in contact with the surface.
  • Page 13 PRECAUTIONS TO BE HEEDED DURING OPERATION To avoid injury and accidents, those who fall under the following catagories are not allowed to play the game: * Intoxicated persons * Those who have high blood pressure or heart problems. * Those who have experienced muscle convulsion or loss of consciousness when playing video games, etc.
  • Page 14 Immediately stop such violent acts as hitting and kicking the product. Such violent acts can cause parts damage or falling down, resulting in injury due to fragments and falling down. Children should be accompanied by their guardians for playing the game. The steering wheel has reaction mechanism.

  • Page 15: Name Of Parts

    5 . NAME OF PARTS BILLBOARD MONITOR CONTROL PANEL ACCELERATOR & BRAKE SEAT GAME SPECIFICATIONS WIDTH LENGTH HEIGHT WEIGHT All measurements are rounded UP DURING SHIPPING 40” 77” 84” 700 LBS WHEN ASSEMBLED 33.75” X 70” 78” 650 LBS www.seuservice.com...

  • Page 16: Accessories

    6 . ACCESSORIES When transporting the machine, make sure that the following parts are supplied. TABLE 5 ACCESSORIES KEY MASTER DESCRIPTION OWNERS MANUAL 9301A (2) Part No. (Qty.) 999-1384 ( 1 Qty) For opening/closing For the CASHBOX DOOR Note the doors The Keys are inside the Coin Figures Chute Door at the time of ship-...

  • Page 17: Filter Board

    HOW TO USE THE CARTON BOX When requesting for the replacement/repair of this product's Game Board (NAO- STOP MI BOARD), follow the instructions below. Transporting the Game Board in an undesignated status is unacceptable. An erroneous handling can cause parts dam- age.
  • Page 18 APPLIES TO ‘MODEL 3’ BOARDS CONTAINED IN THE FOLLOWING GAMES: LOST WORLD, VIRTUA FIGHTER 3, SUPER GT, SEGA BASS FISHING, STRIKER 2 HARLEY DAVIDSON, RALLY 2, DAYTONA 2, DIRT DEVILS, HOUSE OF THE DEAD 2, OCEAN HUNTER, STAR WARS TRILOGY, ZOMBIE REVENGE, CRAZY TAXI, ARI-...

  • Page 19: Assembling And Installation

    7 . ASSEMBLING AND INSTALLATION •Assembling should be performed as per this manual. Since this is a complex machine, erroneous assembling may cause damage to the machine, or malfunctioning to occur. •When assembling, be sure to perform work by plural persons. Depending on the assembly work, there are some cases in which a single person performing the work can cause personal injury or parts damage.
  • Page 20 SECURING IN PLACE (ADJUSTER ADJUSTMENT) Be sure to have all the Adjusters make contact with the floor surface. Unless the Adjusters come into contact with the floor surface, the Cabinet can move of itself, causing an accident. This machine has 4 each of casters and adjusters (shown below). When the installation position is deter- mined, cause the adjusters to come into contact with the floor directly, make adjustments in a manner so that the casters will be raised approximately 5mm.

  • Page 21: Power Supply

    POWER SUPPLY Ensure that the power cord is not exposed on the surface (passage, etc.). If ex- posed, they can be caught and are susceptible to damage. If damaged, the cord can cause an electric shock or short circuit. Ensure that the wiring position is not in the customer's passage way or the wiring has protective covering.

  • Page 22: Turning Power On

    TURNING POWER ON Turn the AC Unit's main switch on to supply power. When power is turned on, the fluorescent lamp inside the MAIN BILLBOARD lights up. The monitor displays NAOMI SYSTEM boot up and then proceeds to the advertise mode. During this time, the initialization setting is automatically performed.

  • Page 23: Memory Test

    ASSEMBLING CHECK In the TEST MODE, ascertain that the assembly has been made correctly and that the IC BOARD is satis- factory. In the test mode, perform the following test: (1) MEMORY TEST Selecting the RAM TEST item on the test mode MEMORY TEST MODE menu screen causes the on-board memory to be tested automatically.

  • Page 24: Sound Test

    (3) INPUT TEST INPUT TEST Selecting the INPUT TEST on the test mode menu screen causes the screen (on which SERVICE TEST each switch is tested) to be displayed. Press START each switch. For the coin switch test, insert VIEW HORN a coin from the coin inlet with the coin chute SHIFT [L]...

  • Page 25: Precautions To Be Heeded When Moving The Machine

    8 . PRECAUTIONS TO BE HEEDED WHEN MOVING THE MACHINE When moving the machine, be sure to pull out the plug from the power sup- ply. Moving the machine with the plug inserted can damage the power cord and cause a fire or electric shock. When moving the machine on the floor, retract the Adjusters and ensure that Casters make contact with the floor.

  • Page 26: Game Description

    “The King of Route 66” : How to Play, Game Rules and Test Mode 9. GAME DESCRIPTION OVERVIEW An action-packed trailer-truck race that runs along America’s famed “Route 66” Voice-recognition CB-style device enables real oral communication between rival players. 3 area types and a “mini-stage” during which the trailer is appended to the cab. 3 freight transport sections per area.
  • Page 27 OPERATION STEERING WHEEL GEAR <Large Wheel> Select Screen: Select by turning right or left. In Game: Directs the truck. <Driver Side Horn> Select Screen: Enter selection. In Game: Forces cars preceding Players truck to change lanes or speed up. <MIC> Voice Recognition: Engage NITRO command.
  • Page 28 MIC OPERATION MIC Button Receiver Press MIC button. This puts the device in Standby, either for voice recognition or communication. While pressing the MIC button, speak into the receiver of the MIC. (Note: Speaking too loudly, or with the mouth too close to the component may prevent the device from working optimally.) Release MIC button.
  • Page 29 CONVOY COMBO <To be changed on Convoy Combo ver.> Figure B Figure A During the game, the Player may receive radio communications from other truckers(Figure A). The incoming message will be phrased as a question, to which the Player must respond by selecting an answer out of 2 choices, and entering the selection through the CB feature.

  • Page 30: Screen Display

    SCREEN DISPLAY Transport Fee Clock Rearview Mirror Gear Display CB-RADIO Command Tachometer Clock: The Clock displays the time remaining for the Player. Once a destination is reached and the goods are delivered, a certain amount of time is added onto the Clock. Rearview Mirror: When the POV is set to Driver’s, the Player may see the rear view.
  • Page 31 DUAL PLAYER MODE Operation Insert credits and press START to arrive at the Entry Registration screen. If Single Player Mode is desired, simply press start again to begin the game. Those wishing to compete with a human opponent in Dual Player Mode must insert coins into the opponent’s cabinet.

  • Page 32: Select Screen

    SELECT SCREEN Truck Select <Dual Player> <Single Player> <To be changed on overseas ver.> Select a vehicle from 5 options: TEXAS HAWK, HIGHWAY CAT, IRON BULL, SOUL MAN and ICHIBAN. All vehicles are rated bason on SPEED, TORQUE AND TOUGHNESS. Area Select <Single Player:>...

  • Page 33: Name Entry

    Trailer Select <Single Player> Depending on the section being played, the Player must select 1 trailer from a choice of 2 - 3. The destinations, and therefore courses, differ depending on the goods being transported. These are divided into classes of EASY, NORMAL and HARD. NAME ENTRY The top 10 scores are recorded along with the names of the Players.

  • Page 34: Explanation Of Test And Data Display

    10. EXPLANATION OF TEST AND DATA DISPLAY By operating the switch unit, periodically perform the tests and data check. When installing the machine initially or collecting cash, or when the machine does not function correctly, perform checking in accordance with the explanations given in this section. The following shows test and modes that should be utilized as applicable.

  • Page 35: Switch Unit And Coin Meter

    10 - 1 SWITCH UNIT AND COIN METER Never touch places other than those specified. Touching places not specified can cause electric shock and short circuit accidents. Adjust to the optimum sound volume by considering the environmental re- STOP quirements of the installation location. If the COIN METER and the game board are electrically disconnected, game play is not possible.

  • Page 36: System Test Mode

    10 - 2 SYSTEM TEST MODE STOP The contents of settings changed in the TEST mode are stored when the test mode is finished from EXIT in the menu mode. If the power is turned off before the TEST mode is finished, the contents of setting change become inef- fective.

  • Page 37: Game Test Mode

    GAME TEST MODE 10 - 3 TEST MENU SCREEN Select GAME TEST MODE from the System Menu screen to display the Game Test Menu screen as follows. THE KING OF ROUTE66 TEST MENU INPUT TEST OUTPUT TEST GAME ASSIGNMENTS VOLUME SETTING BOOKKEEPING BACKUP DATA CLEAR DEBUG SETTING...

  • Page 38: Input Test

    10- 4 INPUT TEST Selecting INPUT TEST displays the following screen and allows the status of each input device to be checked. In this mode, periodically check the status of each input devices. INPUT TEST SERVICE TEST START VIEW HORN WIPER SHIFT [D] SHIFT [R]...
  • Page 39 If the result is BAD, recognition may have failed due to a few different factors. Continue the test keeping in mind the volume of background noise, intonation of input, and reconfirm that the button is held down at the time of input. CB-MIC INPUT confirms connectivity between the microphone and other components.

  • Page 40: Output Test

    10 - 5 OUTPUT TEST Selecting OUTPUT TEST displays the following screen and allows the status of each lamp and motor to be checked. OUTPUT TEST > START LAMP [OFF] VIEW LAMP [OFF] HORN LAMP [OFF] WIPER LAMP [OFF] ROLL LEFT [OFF] ROLL RIGHT [OFF]...

  • Page 41: Game Assignments

    10 - 6 GAME ASSIGNMENTS Selecting GAME ASSIGNMENTS causes the present game setting to be displayed, allowing you to change game settings. Setting changes are not effected until Test Mode is exited. After changing settings, be sure to exit Test Mode. GAME ASSIGNMENTS GAME DIFFICULTY [NORMAL]...

  • Page 42: Volume Setting

    DEFAULT SETTING: Returns all settings to their original positions. After changing the settings, select EXIT and press the TEST Button to return to the Game Test Menu screen. 10 - 7 VOLUME SETTING Selecting VOLUME SETTING displays the following screen on the monitor. VOLUME SETTING >...

  • Page 43: Bookkeeping

    10 - 8 BOOKKEEPING Selecting BOOKKEEPING displays operating status data in 2 Pages. Press the TEST Button to proceed to the next screen. Pressing the TEST Button while the 2/2 Page is displayed causes the Game Test Menu to return on the screen. BOOK KEEPING 1/2 NUMBER OF GAMES NUMBER OF CONTINUE...

  • Page 44: Backup Data Clear

    10 - 9 BACKUP DATA CLEAR Selecting BACKUP DATA CLEAR allows the contents of BOOKKEEPING and the Ranking Data to be cleared. Note that this operation does not affect the settings of the GAME ASSIGNMENTS and the VOLUME SETTING. BACKUP DATA CLEAR >...

  • Page 45: Contol Panel (Handle Mecha)

    11. CONTROL PANEL (HANDLE MECHA) Before starting to work, ensure that the Power SW is OFF. Failure to observe this can cause electric shock or short circuit. Use care so as not to damage wirings. Damaged wiring can cause electric shock or short circuit.
  • Page 46 Take out the 4 Tamper proof screws at the center of the steering wheel to remove the HORN BUSHING and the HORN BUTTON & SPRING. Remove 5/8 -11 NYLOC NUT Pull off the STEERING WHEEL. Remove the HUB SPLINE www.seuservice.com...

  • Page 47: Control Panel Cover

    Take out the screws to remove the CONTROL PANEL COVER. Wiring connection is inside the CONTROL PANEL COVER. Use care so as not to damage wiring. Disconnect the 2 connectors inside the CONTROL PANEL COVER, and remove the CONTROL PANEL COVER. TAMPER PROOF SCREW CONTROL PANEL COVER HORN BUTTON...

  • Page 48: Shift Lever

    12. SHIFT LEVER Before starting to work, ensure that the Power SW is OFF. Failure to observe this can cause electric shock or short circuit. Use care so as not to damage wirings. Damaged wiring can cause electric shock or short circuit. If the Shift Lever operation is not satisfactory, remove the Shift Lever in the following procedure and replace the microswitch.

  • Page 49: Switch Replacement

    12 - 2 SWITCH REPLACEMENT Each Microswitch is secured with 2 screws. Remove the 2 screws and replace he Microswitch. After replacing the Switch, check its status in the Test Mode. www.seuservice.com...

  • Page 50: Accelerator And Brake

    13. ACCELERATOR & BRAKE Before starting to work, ensure that the Power SW is OFF. Failure to observe this can cause electric shock or short circuit. Use care so as not to damage wirings. Damaged wiring can cause electric shock or short circuit. Do not touch undesignated places.

  • Page 51: Adjusting Or Replacing The Volume

    13 - 2 ADJUSTING OR REPLACING THE VOLUME The appropriate value for both ACCEL. Volume and Brake Volume is under 30H when released and over C0H when stepped on. Check Volume values in the TEST mode. Since work is performed inside the energized cabinet, be very careful so as not to touch undesignated places. Touching places not specified can cause electric shock or short circuit.

  • Page 52: Greasing

    REPLACEMENT TRUSS SCREW(2) M4 X 8 Turn the power off. Take out the 2 screws and remove POTENTIOCOVER the Potentiocover (FIG. 13. 2 c). Disconnect the connector of the volume to be replaced. Remove the screw which secures the Potentiobase (FIG. 13. 2 b). Remove the Potentiobase together with the volume as is attached.

  • Page 53: Coin Selector

    14. COIN SELECTOR HANDLING THE COIN JAM If the coin is not rejected when the REJECT button is pressed, open the coin chute door and open the selector gate. After removing the jammed coin, put a normal coin in and check to see that the selector correctly functions.
  • Page 54 OPTIONAL DOLLAR BILL ACCEPTOR THE COIN DOOR ASSEMBLY USED ON THE KING OF ROUTE 66 STANDARD COMES EQUIPPED TO ACCEPT A DOLLAR BILL ACCEPTOR. ALL NEEDED WIRING CONNECTIONS ARE CONVIENENTLY LOCATED INSIDE THE GAME FOR THIS APPLICATION. THE COIN DOOR CAN ACCCOMMODATE THE FOLLOWING...
  • Page 55 www.seuservice.com...

  • Page 56: Specifications

    THE KING OF ROUTE 66 STANDARD. This manual is intended for the owners, personnel and managers in charge of op- eration of the product.
  • Page 57 DEFINITION OF LOCATION MAINTENANCE MAN AND SERVICEMAN Non-technical personnel who do not have technical knowledge and expertise should refrain from performing such work that this manual requires the location's maintenance man or a serviceman to carry out, or work which is not explained in this manual.
  • Page 58 General Precautions Follow Instructions: All operating and use instructions should be followed. Attachments: Do not use attachments not recommended by the product manufacturer as they may cause hazards. Accessories: Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, caus- ing serious injury to a child or adult, and serious damage to the product.

  • Page 59: Installation Precautions

    Safety Check: Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition. Heat: The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.
  • Page 60 www.seuservice.com...

  • Page 61: Monitor

    (plug) before starting work. Proceeding the work without following this instruction can cause electric shock of malfunctioning. Using the monitor by converting it without obtaining a prior permission is not allowed. SEGA shall not be liable for any malfunctioning and accident caused by said conversion.
  • Page 62 For the purpose of static prevention, special coating is applied to the CRT face of this prod- uct. To protect the coating, pay attention to the following points. Damaging the coating film can cause electric shock to the customers. For the caution to be heeded when clearing, refer to the Section of Periodic inspection Table.
  • Page 63 SANWA Monitor: 998-0156 (31K Mode) CONTRAST BRIGHT H SIZE H POSI V SIZE V POSI CONTRAST ....Adjust image contrast. BRIGHT ...... Controls screen brightness. H. SIZE ......Controls horizontal screen size. H. POSI ......Controls horizontal display position on screen. V. SIZE ......Controls vertical screen size.

  • Page 64: Replacing The Fluorescent Lamp

    16. REPLACING THE FLUORESCENT LAMP When performing work, be sure to turn power off. Working with power on can cause electric shock and short circuit hazards. The Fluorescent Lamp, when it gets hot, can cause burn. Be very careful when replacing the Fluorescent Lamp. Be sure to use lamps of the designated rating.
  • Page 65 Remove the MARQUEE PLATE. MARQUEE PLATE PHOTO 16 c Replace the fluorescent lamp inside the BILLBOARD. PHOTO 16 d FLUORESCENT LAMP 18” F15T8CW Local Purchase www.seuservice.com...

  • Page 66: Periodic Inspection Table

    17. PERIODIC INSPECTION TABLE The items listed below require periodic check and maintenance to retain the performance of this machine and to ensure safe business operation. Be sure to check once a year to see if Power Cords are damaged, the plug is securely inserted, dust is accumulated between the Socket Outlet and the Power Plug, etc.

  • Page 67: Troubleshooting

    18. TROUBLESHOOTING In order to prevent electric shock and short circuit, be sure to turn power off before performing work. Be careful so as not to damage wirings. Damaged wiring can cause electric shock or short circuit. After removing the cause of the functioning of the Circuit Protector, reinstate the Circuit Protector.

  • Page 68: Game Board

    19. GAME BOARD Ensure that the DIP SW setting is performed as designated. Failure to observe this may cause functioning not suitable for the actual operation, or malfunctioning. 16 - 1 COMPOSITION OF GAME BOARD GAME BOARD ASSY NAT RTS USA(840-0087D-01):USA SCREW (4) M3 X 30 ROM CASE NAO PTR...

  • Page 69: Design Related Parts

    20. DESIGN RELATED PARTS (D-1/2) For the Warning Display stickers, refer to Section 1. www.seuservice.com...
  • Page 70 20. DESIGN RELATED PARTS (D-2/2) ITEM NO. PART NO. DESCRIPTION NOTE 999-1404 MARQUEE RTE 66 MACHINED 999-1405 OVERLAY CNTRL PNL RTE66 STD 999-1406 DECAL SIDE CAB Left RTE66 STD 999-1407 DECAL SIDE CAB Right RTE66 STD 999-1408 DECAL SEAT Left RTE66 STD 999-1409 DECAL SEAT Right RTE66 STD 999-1410...

  • Page 71: Parts List

    21. PARTS LIST ITEM NO. PART NO. DESCRIPTION NOTE ASSY BILLBOARD 998-0156 29” SANWA MONITOR ASSY CONTROL PANEL COIN CHUTE REFER TO PAGE 48-51 SPG-2200 ACCELERATOR & BRAKE LOCAL PURCHASE DIAMOND FLOOR PLATE LEFT GP#S182-100-000 LOCAL PURCHASE DIAMOND FLOOR PLATE RIGHT GP#S182-100-001 999-1419 PLEXIGLASS CLR RTE66 STD 999-1400...
  • Page 72 ASSY BILLBOARD ITEM NO. PART NO. DESCRIPTION NOTE 999-1404 MARQUEE RTE66 STD MACHINED LOCAL PURCHASE ASSY FLOURESCENT FIXTURE 999-0926 LENS COVER YELLOW 999-0925 LENS COVER RED LOCAL PURCHASE 14 V LAMP BULB (#293 IMPERIAL) 999-0928 14 V SOCKET FOR LAMP BULB 999-0927 LIGHT STRIP PLATE 999-0963...
  • Page 73 ASSY CONTROL PANEL ITEM NO. PART NO. DESCRIPTION NOTE ASSY STEERING WHEEL 999-1382 ASSY CB-MIC LOCAL PURCHASE WINDSHIELD WIPER BUTTON - HAPP #54-0006-21 LOCAL PURCHASE START BUTTON - HAPP #54-0006-25 LOCAL PURCHASE VIEW BUTTON - HAPP #54-0006-42 LOCAL PURCHASE SHIFTER - HAPP #50-8110-16 EX www.seuservice.com...
  • Page 74 ASSY STEERING WHEEL www.seuservice.com...
  • Page 75 www.seuservice.com...
  • Page 76 ASSY MIC & CABLE ITEM NO. PART NO. DESCRIPTION NOTE 999-1382 ASSY MICROPHONE & CABLE 999-1402 S/A:MIC RETAINER 999-1403 BRACKET HOLDER MIC www.seuservice.com...
  • Page 77 ASSY SHIFTER - HAPP CONTROLS www.seuservice.com...
  • Page 78 ASSY ACCEL&BRAKE (SPG-2200) (D-1/2) www.seuservice.com...
  • Page 79 ASSY ACCEL&BRAKE (SPG-2200) (D-2/2) ITEM NO. PART NO. DESCRIPTION NOTE SPG-2201 BASE SPG-2202 ACCEL PEDAL SPG-2203 BRAKE PEDAL SPG-2204 ACCEL SPRING SPG-2205 BRAKE SPRING SPG-2206 SHAFT SPG-2207 ACCEL GEAR SPG-2208 BRAKE GEAR SPG-2209 NEUTRAL STOPPER SPG-2210 VR PLATE ACCEL SPG-2211 VR PLATE BRAKE SPG-2212 AMPL GEAR...
  • Page 80 SW UNIT ITEM NO. PART NO. DESCRIPTION NOTE LOCAL PURCHASE VOLUME KNOB - MOUSER #45KN015 LOCAL PURCHASE SWITCH TEST/SVC.5 AMP - MOUSER #104-0015 999-1222 VOL CONT B-5K OHM (CONNECTED TO VOLUME KNOB) www.seuservice.com...
  • Page 81 SUB WOOFER ITEM NO. PART NO. DESCRIPTION NOTE 999-0929 SUB WOOFER 8” 4OHM 25W * * PICTURE MAY DIFFER FROM ACTUAL ITEM www.seuservice.com...
  • Page 82 ASSY AC UNIT ITEM NO. PART NO. DESCRIPTION SPG5-0401 AC BRKT Local Purchase BUSHING STRAIN RELIEF 6N34 Local Purchase FUSE 5000 MA UL Local Purchase SW ROCKER J8 V-B www.seuservice.com...
  • Page 83 ASSY MAIN BD NOTE: Make sure that there is no wiring, etc. in the slash mark portions. ITEM NO. PART NO. DESCRIPTION 400-5397-01 POWER SUPPLY 840-0087D-01 ASSY CASE NAT RTS USA www.seuservice.com...
  • Page 84 ASSY AMP BD ITEM NO. PART NO. DESCRIPTION NOTE 838-13683-01 I/O BOARD JAMMA 839-1132-01 MAPLE /LM CONVERT BD W/VM SKT LG 998-0147 TRANSFORMER 12VAC 4A MCI-4-06-7012 998-0158 TRANSFORMER 120VAC 60HZ 14V 6.3 PNP-1488 998-0159 FILTER LINE 10 AMP YK10TI LOCAL PURCHASE FUSES LOCAL PURCHASE FUSE HOLDERS...

  • Page 85: Wire Color Code Table

    21. WIRE COLOR CODE TABLE THE WIRE COLOR CODE is as follow: PINK SKY BLUE BROWN PURPLE LIGHT GREEN Wires other than those of any of the above 5 single colors will be displayed by 2 alphanumeric characters. BLUE YELLOW GREEN WHITE ORANGE...
  • Page 86 Warranty Your new Sega Product is covered for a period of 90 days from the date of shipment. This certifies that the Printed Circuit Boards, Power Supplies and Monitor are to be free of defects in workman- ship or materials under normal operating conditions. This also certifies that all Interactive Control Assemblies are to be free from defects in workmanship and materials under normal operating condi- tions.
