  • Page 1 2023-04 New as of: Heliodent Plus Operating Instructions English...

  • Page 2: Table Of Contents

    Table of contents Dentsply Sirona Heliodent Plus Table of contents General data....................Preface ........................General information about this operating manual ............Contact information ..................... Warranty and liability ....................Intended use........................ 1.5.1 Indication and contraindication ..............Structure of the document ...................
  • Page 3 Dentsply Sirona Table of contents Heliodent Plus Exposure times......................4.9.1 Possible exposure times in seconds............. 4.9.2 Pre-programmed exposure times for films of sensitivity class E and with a 200 mm (8") FHA cone ................. 4.9.3 Pre-programmed exposure times for films of sensitivity class E and with a 300 mm (12") FHA cone ................
  • Page 4 Table of contents Dentsply Sirona Heliodent Plus Dismantling and disposal ................Dismantling and reinstallation ..................Disposal........................8.2.1 Disposal of the X-ray tube assembly ............Dose area product (DFP) ................Brief Operating Instructions................66 03 588 D3507 D3507.201.01.24.02    2023-04...

  • Page 5: General Data

    General data Preface Dear Customer, Thank you for purchasing the Heliodent Plus X-ray system. This system can be used to take intraoral X-rays. Please familiarize yourself with the unit by reading through these Operating Instructions before taking any X-rays of patients.

  • Page 6: Contact Information

    1 General data Dentsply Sirona 1.3 Contact information Heliodent Plus Contact information Customer Service Center In the event of technical queries, please use our online contact form at the following address: http://srvcontact.sirona.com Manufacturer's address Sirona Dental Systems GmbH Fabrikstrasse 31...

  • Page 7: Intended Use

    Heliodent Plus 1.5 Intended use Intended use The Heliodent Plus is an X-ray device for established dental surgeries and clinics intended to be used for intraoral radiography for examination and diagnosis of diseases of the teeth, jaw, and oral structures.

  • Page 8: Structure Of The Document

    1 General data Dentsply Sirona 1.6 Structure of the document Heliodent Plus Structure of the document 1.6.1 Identification of danger levels To prevent personal injury and material damage, please observe the warning and safety information provided in this document. All such...

  • Page 9: Safety Information

    Dentsply Sirona 2 Safety information Heliodent Plus 2.1 Basic safety information Safety information Basic safety information NOTICE This unit must not be operated in areas subject to explosion hazards. Information on the unit Accompanying documents This symbol can be found next to the rating plate on the unit.

  • Page 10: Hygiene

    Dentsply Sirona 2.7 Hygiene Heliodent Plus order to reduce radiation exposure, Dentsply Sirona recommends using bismuth or lead shields or aprons, especially for pediatric patients. During the exposure, the operator is required to remove themselves as far from the X-ray tube assembly as the coiled cable of the release button permits.

  • Page 11: Modifications To The Product

    The accuracy of the radiation parameters and the repeatability of the dose values in particular may be affected. Operate only units approved by Dentsply Sirona at a distance of < 30 cm from the X-ray unit. The Dentsply Sirona intraoral sensors are approved for this.

  • Page 12: Technical Description

    3 Technical description Dentsply Sirona 3.1 Technical data Heliodent Plus Technical description Technical data Nominal voltage: 120  V , 200 V– 240  V Permissible fluctuation: ± 10% Nominal current: at 120 V: 10 A at 200 – 240 V: 6 – 5 A Nominal frequency: 50 Hz / 60 Hz...
  • Page 13 Air pressure: 500 hPa – 1060 hPa Operating conditions: Ambient temperature +10°C – +35°C (50°F – 95°F) With room temperatures > 35°C (> 95°F) Dentsply Sirona recommends the use of an air conditioning system. Relative humidity: 30% - 85% (no con- densation) Operating altitude: ≤...

  • Page 14: Diagrams

    3 Technical description Dentsply Sirona 3.2 Diagrams Heliodent Plus Diagrams Cooling curve of tube housing Joule x10 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 t (min) Cooling curve of X-ray tube...

  • Page 15: Certification, Registration And Standards

    Dentsply Sirona 3 Technical description Heliodent Plus 3.3 Certification, registration and standards Certification, registration and standards The dental X-ray equipment for intraoral radiography Heliodent Plus complies with the following standards: ● IEC 60601-1 ● IEC 60601-1-3 ● IEC 60601-2-65 Original language: German...

  • Page 16: Controls And Functional Elements

    4 Controls and functional elements Dentsply Sirona 4.1 Operating and Display Elements Heliodent Plus Controls and functional elements Operating and Display Elements Main ON/OFF switch Readiness for operation indicator (LED) Optical radiation indicator for X-ray Plus/minus keys for exposure time...

  • Page 17: Meaning Of The Icons

    Dentsply Sirona 4 Controls and functional elements Heliodent Plus 4.2 Meaning of the icons Meaning of the icons Patient symbol Adult Child Plus key Minus key Exposure release button Maxillary front tooth Maxillary canine/premolar Maxillary molar Bite-wing exposure Mandibular front tooth...

  • Page 18: Display Structure

    4 Controls and functional elements Dentsply Sirona 4.3 Display structure Heliodent Plus Display structure The background lighting of the display indicates the current status of the unit. Background color Meaning Blue Ready for radiation Yellow Radiation White Service Error Wall model version...

  • Page 19: Mobile Stand Variant

    Dentsply Sirona 4 Controls and functional elements Heliodent Plus 4.6 Mobile stand variant Ceiling combination with LEDview Plus Mobile stand variant Mounting of the wall model with round or angular support arm (only support arm length M possible) on a mobile stand for mobile use.
  • Page 20 4 Controls and functional elements Dentsply Sirona 4.6 Mobile stand variant Heliodent Plus CAUTION Always apply the brakes (C) before setting up the X-ray tube assembly. The mobile stand can be fitted with a tray (D). CAUTION This tray may hold a maximum of 5 kg.

  • Page 21: Version Unit Model

    4 Controls and functional elements Heliodent Plus 4.7 Version Unit model Version Unit model Heliodent Plus at a treatment center, only possible with angular support arm system. Rotation option of the angular support arm is 180°. 66 03 588 D3507...

  • Page 22: Accessories

    4 Controls and functional elements Dentsply Sirona 4.8 Accessories Heliodent Plus Accessories IMPORTANT Not all of the accessories listed here are included in the scope of supply. Only required in countries in which the constancy test is mandatory. Phantoms for constancy tests for conventional imaging technology Order no.

  • Page 23: Exposure Times

    Dentsply Sirona 4 Controls and functional elements Heliodent Plus 4.9 Exposure times Radiation field limitation black size 1 (2 x 3 cm) with rotary handle for Xios XG size 1 sensor, Xios Plus/ Xios size 1 sensor and conventional imaging technology Order no.

  • Page 24: Pre-Programmed Exposure Times For Films Of Sensitivity Class E And With A 300 Mm (12") Fha Cone

    4 Controls and functional elements Dentsply Sirona 4.9 Exposure times Heliodent Plus 4.9.3 Pre-programmed exposure times for films of sensitivity class E and with a 300 mm (12") FHA cone Upper jaw Lower jaw Upper jaw Lower jaw Exposure time in sec-...

  • Page 25: Pre-Programmed Exposure Times For Xios Xg Sensors With 200 Mm (8") Fha Cone

    Dentsply Sirona 4 Controls and functional elements Heliodent Plus 4.9 Exposure times 4.9.4 Pre-programmed exposure times for Xios XG sensors with 200 mm (8") FHA cone Possible exposure times in seconds The recommended exposure times are limited to the following values selected from the possible exposure times: 0.01...

  • Page 26: Pre-Programmed Exposure Times For Xios Xg Sensors With 300 Mm (12") Fha Cone (Round Or Square Cone)

    4 Controls and functional elements Dentsply Sirona 4.9 Exposure times Heliodent Plus 4.9.5 Pre-programmed exposure times for Xios XG sensors with 300 mm (12") FHA cone (round or square cone) Possible exposure times in seconds The recommended exposure times are limited to the following values selected from the possible exposure times: 0.03...

  • Page 27: Pre-Programmed Exposure Times For Xios Ae Sensors With 200 Mm (8") Fha Cone

    Dentsply Sirona 4 Controls and functional elements Heliodent Plus 4.9 Exposure times 4.9.6 Pre-programmed exposure times for Xios AE sensors with 200 mm (8") FHA cone Possible exposure times (in seconds) 0.01 0.02 0.03 0.04 0.05 0.06 0.08 0.10 0.12 0.16...

  • Page 28: Pre-Programmed Exposure Times For Xios Ae Sensors With 300 Mm (12") Fha Cone

    4 Controls and functional elements Dentsply Sirona 4.9 Exposure times Heliodent Plus 4.9.7 Pre-programmed exposure times for Xios AE sensors with 300 mm (12") FHA cone Possible exposure times (in seconds) 0.03 0.04 0.05 0.06 0.08 0.10 0.12 0.16 0.20 0.25...

  • Page 29: Operation

    Dentsply Sirona 5 Operation Heliodent Plus 5.1 General Operation General Heliodent application ● Recommendations for cone length. – The cone length to be used varies depending on the exposure technique, X-ray unit and radiation protection. In Germany, for example, the 20 cm standard cone is used primarily.

  • Page 30: Preparing The Exposure

    5 Operation Dentsply Sirona 5.2 Preparing the exposure Heliodent Plus Preparing the exposure 5.2.1 Switch the unit on Switch on the unit with the main switch (A) (Position I). During this process none of the keys of the operating panel must be pressed.

  • Page 31: Selecting The Patient Symbol

    Dentsply Sirona 5 Operation Heliodent Plus 5.2 Preparing the exposure 5.2.3 Selecting the patient symbol Press the button with the adult patient icon if you wish to take an X-ray of an adult. The programmed exposure time is indicated. Press the button with the child patient icon if you wish to take an X-ray of a child.

  • Page 32: Positioning The Patient/X-Ray Tube Assembly

    5 Operation Dentsply Sirona 5.3 Positioning the patient/X-ray tube assembly Heliodent Plus Positioning the patient/X-ray tube assembly Ask the patient to take a seat on the chair. The operating elements of the unit should be out of reach of the patient.

  • Page 33: Releasing The Exposure

    Dentsply Sirona 5 Operation Heliodent Plus 5.4 Releasing the exposure Releasing the exposure CAUTION Comply with the radiation protection provisions. NOTICE When using a digital sensor system, establish exposure readiness in Sidexis before you release the exposure, see Sidexis User Manual.
  • Page 34 5 Operation Dentsply Sirona 5.4 Releasing the exposure Heliodent Plus If you are taking a digital X-ray, ensure that the unit is ready to perform exposures. NOTICE Error message If an error is detected during the exposure, the exposure is automatically canceled.

  • Page 35: Adapting Basic Settings

    Dentsply Sirona 5 Operation Heliodent Plus 5.5 Adapting basic settings Adapting basic settings Exposure times for the use of films with the sensitivity class E are factory pre-set, as well as the XIOS XG sensors. IMPORTANT The exposure times for sensor and film images are programmed separately.
  • Page 36 5 Operation Dentsply Sirona 5.5 Adapting basic settings Heliodent Plus 4. The base value can now be adjusted by pressing the plus or minus buttons. Each level corresponds to about a 25% extension or reduction in exposure time. 5. The entry can be confirmed by pressing the button with the adult patient icon.

  • Page 37: Hygiene And Maintenance

    Dentsply Sirona 6 Hygiene and maintenance Heliodent Plus 6.1 General notes on cleaning and care Hygiene and maintenance General notes on cleaning and care IMPORTANT If necessary, suitable protective clothing must be worn and suitable protective equipment used at all times.

  • Page 38: Reprocessing Of The Sensor And Film Holder Systems

    If you do not have access to the Internet, you can order the list (REF 59 70 905) in one of the following two ways: ● Order from your local dental depot ● Order from Dentsply Sirona: Phone: +49 (0) 62 51 / 16-16 70 Fax: +49 (0) 62 51 / 16-18 18 6.1.3...

  • Page 39: Preparation For Manual Reprocessing Of The Radiation Field Limitation

    X-ray unit. Dentsply Sirona does not define a maximum number of uses based on many years of experience with these reprocessable parts.

  • Page 40: Inspection And Maintenance

    Please note the legally required regular checks of the image quality of your X-ray device as stipulated in your country (e.g. the German Radiation Protection Ordinance). Dentsply Sirona provides you with the Sidexis software for easy implementation of this constancy test and for its documentation.
  • Page 41 Radiation Protection Ordinance in accordance with DIN 6868-157. To easily implement the necessary legal requirements, Dentsply Sirona provides the Simocon 2 software. You can find this software and the operating instructions that belong to it on your Sidexis CD under the "Tools"...

  • Page 42: Error Messages

    7 Error messages Dentsply Sirona 7.1 List of error messages Heliodent Plus Error messages Errors during the self-test are indicated by a five-digit number lighting up. The background color of the display is red. CAUTION If an error re-occurs after the unit has been switched off and switched on again, please call your service engineer.
  • Page 43 Dentsply Sirona 7 Error messages Heliodent Plus 7.1 List of error messages Error code Reason and measures E1 04 51 Safety circuit - the door switch may not be closed properly Switch the device OFF and then ON again, check the door...

  • Page 44: Dismantling And Disposal

    8 Dismantling and disposal Dentsply Sirona 8.1 Dismantling and reinstallation Heliodent Plus Dismantling and disposal Dismantling and reinstallation When dismantling and reassembling the unit, proceed according to the installation instructions for new installation in order to guarantee its functioning and stability.

  • Page 45: Disposal Of The X-Ray Tube Assembly

    Dentsply Sirona 8 Dismantling and disposal Heliodent Plus 8.2 Disposal 8.2.1 Disposal of the X-ray tube assembly The X-ray tube assembly in this device contains a tube which can implode, a lead lining and mineral oil. 66 03 588 D3507...

  • Page 46: Dose Area Product (Dfp)

    ) for every available kV level, cone length and aperture in the tables below. Furthermore, the Heliodent Plus also permits the dose area product to be displayed immediately after exposure. The DFP appears on the display together with the exposure time used.
  • Page 47 Dentsply Sirona 9 Dose area product (DFP) Heliodent Plus Tables with typical values for the dose area product (DFP) 1st round cone 200 mm Round cone: with radiation field limitation 200 mm (8") Size 2 (3x4 cm) Size 0 (1.8x2.4 cm) and size 1...
  • Page 48 9 Dose area product (DFP) Dentsply Sirona Heliodent Plus 2nd round cone 300 mm Round cone: with radiation field limitation 300 mm (12") Size 2 (3x4 cm) Size 0 (1.8x2.4 cm) and size 1 (2x3 cm) 60kV 70kV 60kV 70kV...

  • Page 49: Brief Operating Instructions

    Dentsply Sirona 10 Brief Operating Instructions Heliodent Plus Brief Operating Instructions Heliodent Plus 70kV 60kV 70kV 60kV D3507.202.01.03.09 02.2018 __________________________________________________________________________________________________________________________________ 62 14 881 D3507 66 03 588 D3507 D3507.201.01.24.02    2023-04...
  • Page 50 We reserve the right to make any alterations which may be required due to technical improvements. © SIRONA Dental Systems GmbH Sprache: englisch Printed in Germany D3507.201.01.24.02      2023-04 Ä.-Nr.:  133 024 SIRONA Dental Systems GmbH 66 03 588 D3507 Fabrikstraße 31 Order No   ...
