TRI tool SEVERMASTER 576AC Quick Start Manual

Maintenance
Keep the tool clean and free from
chips when not in use. During
repeated use, ensure chip build-up
does not occur. Use a chip brush to
clear chips.
All components should be clean
and coated with a light film of
oil prior to use. Use a clean,
non-detergent oil, which is
specified for air motor.
When the tool is to be stored or left
out of service for 30 days or more it
should be thoroughly cleaned and
wiped down.
Safety Precautions
Use standard safety equipment
such as hard hats, safety glasses,
protective clothes, and other
safety devices when appropriate.
Operate this tool only in accordance
with operating instructions. Only
personnel who are trained or are
being trained may operate the
equipment.
Do not use damaged tools.
Always check your tools for
damage especially if a tool has
malfunctioned, been dropped or
hit.
Store tools properly. Disconnect
tools from the power source, remove
blades/bits, and store in a safe place.
Use the right tool for the job.
Contact Tri Tool Technologies to
help with your application.
Troubleshooting
Consult Manual 92-1924 for
troubleshooting information.
Visit the Tri Tool
576AC SEVERMASTER ™
product page for manual,
demo videos and more
Notes
3041 Sunrise Blvd. • Rancho Cordova, CA 95742
+1 (916) 288-6100 • +1 (800) 345-5015
www.tritool.com
For more information on engineered solutions,
products, and trainings, visit tritool.com or
contact our engineers at +1 (916) 288-6100.
Quick Start
Guide
The Model 576AC SEVERMASTER ™ severs
2.00" (50.8mm) to 6.63" (168.3mm) diameter
tube and thin wall pipe within the size range.
The 576AC SEVERMASTER ™ is available with
pneumatic or electric drive motor options.
COLLET
CAM FEED
ADJUSTMENT NUT
KNOB
FEED
ARM
ELECTRIC
MOTOR
COLLET
LATCH
HANDLE
TRIPPER
PIN
P/N 92-2085
