Summary of Contents for YSI EcoSense ODO200M
- Page 1 User Manual DOCUMENT #606335REF ® EcoSense ODO200 ® EcoSense ODO200M Dissolved oxygen & temperature instrument US ER MANUAL E ng li sh...
- Page 2 Item #606335REF Rev C, December 2017 For the latest version of this manual, visit ysi.com ©2017 YSI Incorporated. The YSI logo and EcoSense are registered trademarks of YSI Incorporated.
-
Page 3: Table Of Contents
C O N T E N T S Warranty ....................i Introduction ..................1 Getting Started ..................1 Package Contents ..............1 Initial Inspection ..............2 Precautions ................2 The Probe .................2 Initial Setup ................2 Preparing the Probe ............3 Battery Installation ............4 Key Pad ..................5 Main Display ................7 Operational Procedures - Taking Measurements ......8 Measurement Modes - % or mg/L ........8... - Page 4 Sensor Maintenance - Temperature ........15 Sensor Storage ..............15 Short-term Storage ............15 Long-term Storage ............15 Troubleshooting ..............16 Error Messages on Display ...........16 Opening the Data File with Excel® ......17 Specifications ..................19 Accessories / Part Numbers .............20 Contact Information and Service .............21 Ordering and Technical Support ........21 Service Information ..............21 Recycling ................22...
-
Page 5: Warranty
Limitation of Warranty This Warranty does not apply to any YSI product damage or failure caused by: (i) failure to install, operate or use the product in accordance with YSI’s written instructions; (ii) abuse or misuse of the product; (iii) failure to maintain the product in accordance with YSI’s written instructions or... - Page 6 T H I S P A G E L E F T I N T E N T I O N A L L Y B L A N K...
-
Page 7: Introduction
This instrument uses one 9V battery. Key differences between the YSI ODO200 and ODO200M include: • ODO200 can store 50 data sets, while the ODO200M can store 250 data sets. -
Page 8: Initial Inspection
Carefully unpack the instrument and accessories and inspect for damage. Compare received parts with items on the packing list. If any parts are damaged or missing, contact YSI Customer Service at 800- 897-4151 (+1 937 767-7241) or the authorized YSI distributor where the instrument was purchased. -
Page 9: Preparing The Probe
Sensor Cap Sensor Probe Figure 1 PREPARING THE PROBE Each sensor cap has unique calibration coefficients associated with it. These coefficients are labeled on the instruction sheet included with each EcoSense cable/probe assembly and replacement sensor cap. Remove the probe/cable assembly from the shipping container and locate the sensor cap instruction sheet. -
Page 10: Battery Installation
6. Connect the cable to the instrument by aligning the connectors, pushing them together and then screwing down the retainer clockwise. Figure 2 Figure 3 BATTERY INSTALLATION To install (or replace) the battery, remove the two battery cover screws and battery cover. -
Page 11: Key Pad
Number Description Power key. Turns the unit on or off. Meas. Effic. Mode Mode EcoSense YSI EcoSense Handheld Overlay ODO20 EcoSense ODO20 ® Up/Recal key. Used to scroll thru saved data ® 12/19/2016 in Recall mode; select the data deletion... - Page 12 7482 C power symbol changed. 130 C logo Enter key. Used to confirm calibration, rse white all other imagery to save data from run screen, to YSI EcoSense Handheld Overlay select data mode (rCL/dEL), and INPUT INPUT 1/26/2016 confirm coefficient entries.
-
Page 13: Main Display
MAIN DISPLAY Figure 6 Number Description BAT: Low battery indicator. Recal Timer indicator (ODO200M only) CAP: Displayed when the sensor cap coefficients are being adjusted by the user. Main display for dissolved oxygen measurements in either % or mg/L. USB/PC connection indicator (ODO200M only) Continuous or Manual sampling mode indicator. -
Page 14: Operational Procedures - Taking Measurements
When the unit is not in use, turn it off to save battery life. It is not necessary to recalibrate the instrument after turning it off and back on. YSI EcoSense Handheld Overlay The instrument has a 30 minute auto shut off feature when not in use. -
Page 15: Saving, Viewing And Deleting Data
Manual mode: the instrument will update the DO reading until reaching a stable measurement. The stable measurement will ‘lock’ on the display until the user initiates a new measurement by pressing the Sample/Mode key. Manual mode conserves battery power. SAVING, VIEWING AND DELETING DATA The ODO200 can save 50 data records, while the ODO200M can save 250 data records. - Page 16 electrochemical sensors. This increased stability means the instrument can hold its calibration for many months; however, calibration should be verified regularly for highest data accuracy. To verify the instrument’s calibration, place the sensor in its calibration environment and check to see that the DO% is reading its calibration value based on the barometric pressure.
-
Page 17: Downloading Data To A Computer - Odo200M Only
DOWNLOADING DATA TO A COMPUTER - ODO200M ONLY The ODO200M features a micro USB connection that allows the instrument to be connected to a computer with Windows 7 or Windows 10 as the operating system. Once connected, data saved to the meter can be downloaded to the computer. -
Page 18: Maintenance And Troubleshooting
Mode Stand Slope Recal EcoSense pH100M Press and hold the Down/ key for 3 seconds to set date and time ® information. Use the arrow keys to adjust Hour, Minute (Min) and Second (Sec). Press Enter to confirm each selection. After adjusting Meas. - Page 19 The replacement ODO sensor cap is shipped in a humidified container. The package should not be opened until ready for use. Once the sensor cap has been installed on the sensor as described below, it is important to keep the sensor in a 100% humid environment. Therefore, the sensor should be stored in either the gray calibration/storage sleeve with a moistened sponge or immersed in water, see Sensor Storage for more information.
-
Page 20: Entering Sensor Cap Coefficients Into The Ecosense Odo200/Odo200M
clean the clear surface of the sensor on the end of the probe with lens cleaning tissue. 6. Using clockwise motion, thread the new sensor cap onto the probe assembly until it is finger-tight. The o-ring should be compressed between the sensor cap and probe. Do not over-tighten the sensor cap and do not use any tools for the installation process. -
Page 21: Rehydrating The Sensor Cap
F, 0, 1, 2, 3, 4, 5, 6, 7, 8, and 9. If you continue to get an error message after several entry attempts, contact YSI Technical Support for assistance. REHYDRATING THE SENSOR CAP The Sensor Cap must remain in a moist environment; see Sensor Storage for storage recommendations. -
Page 22: Troubleshooting
If you are still getting erroneous dissolved oxygen readings, try replacing the sensor cap, enter the new coefficients and then recalibrate. If the erroneous readings continue, contact YSI Technical Support to help determine the next step. ERROR MESSAGES ON DISPLAY... -
Page 23: Opening The Data File With Excel
DO mg/L. DO sensor not properly calibrated, recalibrate the sensor. Check sensor cap. Clean, rehydrate or replace as necessary. Recalibrate. Contact YSI Tech Support. Dissolved Oxygen Sample dissolved oxygen concentration values display is more than 20 mg/L or 200%, or Over or Undr on less than 0.0 mg/L or 0.0%. - Page 24 4. Under Step 1 of the Text Import Wizard, choose Delimited. 5. Under Step 2 of the Text Import Wizard, choose Semicolon. 6. Under Step 3, click on the column with the incorrectly formatted data. This column should be highlighted in black. Choose Text under Column data format.
-
Page 25: Specifications
S P E C I F I C A T I O N S These specifications represent typical performance and are subject to change without notice. For the latest product specification information, please visit YSI’s website at ysi.com or contact YSI Tech Support. Parameter Range... -
Page 26: Accessories / Part Numbers
Real-Time Clock (RTC) for Date/ ODO200M only Time Stamp of Saved Data Waterproof USB for ODO200M only Downloading Data to PC Conforms to the following: Directives: EMC 2014/30/EU RoHS 2011/65/EU WEEE 2012/19/EU Harmonized Standards: EN61326-1:2013 (IEC 61326-1:2012) IEC 61000-3-2:2005 IEC 61000-3-3:2008 IEC 61000-4-2:2008 IEC 61000-4-3:2006 IEC 61000-4-4:2004... -
Page 27: Contact Information And Service
When returning a product for service, include the Product Return form with cleaning certification. The form must be completely filled out for a YSI Service Center to accept the instrument for service. The form may be downloaded from ysi.com by clicking on the ‘Support” tab, then the... -
Page 28: Recycling
RECYCLING YSI is committed to reducing the environmental footprint in the course of doing business. Even though materials reduction is the ultimate goal, we know there must be a concerted effort to responsibly deal with materials after they’ve served a long, productive life-cycle. YSI’s... -
Page 29: Appendix A-Do% Calibration Values
A P P E N D I X A - D O % C A L I B R A T I O N V A L U E S Calibration Pressure Value D.O. % in Hg mmHg mbar 101% 30.22 767.6 102.34... - Page 30 Item # 606335REF Rev C December 2017 ©2017 YSI Incorporated.
