Operating Instructions
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Pro Series
Chemical Resistant Pumps
Description
Pro Series submersible chemical resistant pumps are rated for continuous duty. Pumps
are strong and dependable, and when used intermittently in a sump application, extends
the life of the pump. PSC motor design saves energy, reduces operation costs and
provides better service. Intended for pumping nonflammable fluids compatible with
pump component materials.
Specifications
C8050
HP 1/2
Motor Type PSC
Voltage 60 Hz 115 VAC
Amps 4.7
Water Flow (GPM) at Total Feet of Head
5 Ft. 74
10 Ft. 64
15 Ft. 51
20 Ft. 40
25 Ft. 27
30 Ft. 13
35 Ft. --
40 Ft. --
Max Head 36 Ft.
Max Dia Solids 1/4"
General Safety Instructions
SAVE THESE INSTRUCTIONS.
This manual contains important
SAFETY WARNINGS and OPERATING
INSTRUCTIONS for the C8050 & C8100
pumps. You will need to refer to it before
attempting any installation or maintenance.
ALWAYS keep these instructions with the
unit so that they will be easily accessible.
Failure to read and follow these warnings
and instructions could result in property
damage, serious injury, or death.
Dimensions
C8100
1 HP
PSC Pump Discharge
115 VAC
Materials of Construction
Pump Housing
11.3
Impeller
90 Motor Casing
82 Inlet Screen
69 Motor Shaft
61 Mech. Seals (2) Carbon/Ceramic/Viton
53 Fasteners
45
Overall Dimensions
37 Length
24 Width
Height
49 Ft.
3/8" Weight (lbs.)
risk, observe the following precautions.
• ALWAYS disconnect the pump from
the power source before servicing or
making adjustments.
• NEVER handle the pump or motor
with wet hands or when standing on a
wet or damp surface while the pump is
plugged into the power source.
• MAKE SURE THERE IS A PROPERLY
GROUNDED RECEPTACLE
AVAILABLE. This pump is wired with a
3-prong grounded plug. To reduce the
risk of electric shock, be certain that it is
C8050 C8100
1/2 1
2" 2"
304 SS 304 SS
304 SS 304 SS
304 SS 304 SS
304 SS 304 SS
304 SS 304 SS
304 SS 304 SS
9.1" 10.4"
6.3" 7.5"
16.3" 18.1"
23.0 46.0
Risk of electric only connected to a properly grounded,
shock. To reduce this
3-prong receptacle (preferably with
ground fault circuit interrupt). If you
have a 2-prong receptacle, have a
licensed electrician replace it with a
3-prong receptacle according to local
codes and ordinances.
• NEVER bypass grounding wires or
remove the ground prong from the
plug.
• DO NOT use an extension cord. The
electrical outlet should be within the
length of the pump's power cord, and at
least 4 feet above the floor
C8050 & C8100
