Page 1
DEL: PRO INSERT 28 inch, 34 inch, 48 inch IMPORTANT SAFETY INSTRUCTIONS Carefully read the following important information regarding installation safety and maintenance. Keep these instructions for future reference. 07/08/2017 MAAN1365-02...
Page 2
IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE The installation in this manual is intended for qualified installers, service technicians or persons with ● similar qualified background. Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction.
Page 3
IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE WARNING: TO REDUCE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite.
Page 4
Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding the optimal type of mounting screws and wall anchors to suit your home’s construction.
Page 5
HEIGHT & CLEARANCE: VENTING REQUIREMENTS: Vent system must terminate to the outside (Roof or • side wall). • DO NOT terminate the vent system in an attic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall caps. •...
Page 6
IMPORTANT: • A minimum of 6” round or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. •...
Page 7
VENTING METHODS: • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, •...
Page 8
ELECTRICAL REQUIREMENTS: IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility to contact a qualified electrical installer. If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line.
Page 9
PREPARATIONS: Advanced Preparations: Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 14. • • Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (120-Volt, 60Hz, AC only) and turn on the range hood.
Page 10
INSTALLATION: Installations (refer to Page 4 for parts): NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting the hood on wall studs or lumbars is highly recommended. Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material.
Page 11
INSTALLATION: Step 5: Remove Knock-Out Opening • From inside the power pack, remove the wiring cover by removing 2 retaining screws and set aside. Punch out the electrical knockout hole on top of the power pack. Install the wire clamp (included in parts bag). Fig#7 Fig#6 Fig#5...
Page 12
INSTALLATION: Step 7: Connect Wiring Fig#11 • Position the power pack below the installed custom hood. Insert the house wiring cable through the wire clamp previously installed in step 7. Tighten the wire clamp to secure the cable. • Using the provided wire connectors, connect power pack wires to power cable into wiring box •...
Page 13
INSTALLATION: Step 8: Reinstall Baffle Filter CAUTION: Remove plastic film covering filters before installing them. NOTE: Assemble the metal handles to the filters, using provided no. 8-32 x 1/4" screws, before installing them in the power pack. It is recommended to install side filters first and finish with center one(s). 1 Insert one end of the filter into the upper channel of the power pack.
Page 15
CONTROL PANEL OPERATION: This range hood is equipped with six electronic controls, two stainless steel baffle filters, and two or three bright LED lights. The six electronic buttons control the intensity of the Lights, Speeds (Quiet, Low, Medium and High) and Power (On/Off).
Page 16
TROUBLE SHOOTING: 1) If the range hood or LED light does not • Check if the range hood has been plugged in, operate after installation: make sure that all power has been turned back ON, fused not blown and all electrical wiring are properly connected.
Page 17
Description Description Bottom Panel Power Cable Lights Hood Casing Hood Mounting Bracket Baffle Filter Handle Top Panel Baffle Filter (28-34in: 2pcs / 48in: 3pcs) Motor Electrical Box Control Capacitor...
Page 18
SPECIFICATIONS Specifications: Body Design Stainless Steel 430 120V / 60Hz (USA & Canada standard) cETLus Power Rating 308 W General Input Power 302 W Motor Input Power Ampere 2.69 A 4 Levels Levels Of Speed Control Number Of Motors Single Motor Motor Type Single Chamber Quiet Fan Type...
Page 19
BLOWER ASSEMBLY: Description Motor Air Chamber Squirrel Cage Locknut Safety Screen ELECTRICAL ASSEMBLY: Description Description Screws (3/16” x 3/8”) Electrical Panel Electrical Box Cover Capacitor Screws (3/16” x 3/8”) Processor Board LED Light Transformer Screws (3/16” x 3/8”) Electrical Box Base...
Page 20
USE AND CARE INFORMATION: Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing.
