AudioCodes C455HD IP Phone for Microsoft® Teams™
1. Before Installing
Congratulations on purchasing your AudioCodes C455HD for Microsoft Teams IP Phone!
Before installing your phone, make sure the following items are included in the shipped box:
✓
C455HD IP Phone
✓
AC power adapter (optional)
✓
Cat 5e Ethernet cable
✓
Handset
✓
Handset cord
✓
Desktop stand
✓
Wall mount
2. Physical Description
Navigation Control
Back Key
Volume Keys
Mute Key
Headset Key
Speakerphone Key
Quick Guide
Alphanumerical Keypad
P a g e
| 1
Touch Screen
MENU
VOICEMAIL
CONTACTS
HOME
TRANSFER
HOLD
Microphone
Advertisement
Related Manuals for AudioCodes C455HD
Summary of Contents for AudioCodes C455HD
- Page 1 AudioCodes C455HD IP Phone for Microsoft® Teams™ Quick Guide 1. Before Installing Congratulations on purchasing your AudioCodes C455HD for Microsoft Teams IP Phone! Before installing your phone, make sure the following items are included in the shipped box: ✓ C455HD IP Phone ✓...
- Page 2 3. Cabling the Phone Warning: Prior to connecting power, refer to the Compliancy and Regulatory Information document at https://www.audiocodes.com/library/technical-documents. To cable the phone: [Refer to the illustration below] Connect the short, straight end of the phone cord to the handset and the longer straight end of the cord to the handset jack on the phone.
- Page 3 4. Mounting the Phone on a Desktop or Wall ✓ Desktop: Slide the L-shaped stand's short or long edge slots onto these rails. ✓ Wall: Slide the wall mount fitting onto these rails. Desk Mount P a g e...
- Page 4 Wall Mount P a g e...
- Page 5 5. Signing in To sign in to your account: Connect the device to the network. Point your browser to https://microsoft.com/devicelogin as instructed. Key in the code and click Next. P a g e...
- Page 6 Click the account. Key in your password (it's the same password as the Windows password on your PC) and then click Sign in. Close the ‘Microsoft Authentication Broker’ window; your phone returns to the initial code screen. In that screen, touch Sign in on this device. Touch the 'Email, phone or username' field;...
- Page 7 In the browser on your PC or smart phone, enter the URL and then in the phone’s Web interface that opens, perform sign-in (as noted previously, this option is recommended if using MFA). 6. Changing your Presence Status To change your presence status: Swipe right, touch the current presence status, and then select the status you require.
- Page 8 9. Enabling or Disabling Wi-Fi To enable Wi-Fi: Turn Wi-Fi on by moving the switch in the upper right corner (Wi-Fi is disabled by default). After enabling Wi-Fi, "Searching for Wi-Fi networks…" is displayed. The phone then displays the available Wi-Fi Access Points.
- Page 9 In the Settings screen, select the Bluetooth option, and then in the Bluetooth screen, move the switch to On to start Bluetooth scanning. Select the desired Bluetooth device to pair. If prompted for the Bluetooth Pairing code, enter it, and then touch Pair. Once successfully paired, the Bluetooth audio device appears under the ‘Paired devices’...
- Page 10 • We, Audiocodes Ltd., 1 Hayarden St., Airport City, Lod, Israel, declare under our sole responsibility that the C455HD IP phone complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
- Page 11 Information contained in this document is believed to be accurate and reliable at the time of printing. However, due to ongoing product improvements and revisions, AudioCodes cannot guarantee accuracy of printed material after the Date Published nor can it accept responsibility for errors or omissions. Updates to this document can be downloaded from https://www.audiocodes.com/library/technical-documents.
