- Page 1 SOL-2TA SOL-2TA Commercial Twin Alternating Water Softening System User Guide W A T E R T R E A T M E N T...
-
Page 2: Table Of Contents
Type of Salt to Use ............................38 Brine Tank Clean-Out (Yearly) ........................38 Media Replacement ............................38 Battery Replacement .............................39 Troubleshooting Guide ..........................40 Warranty ................................45 WMTS103 Licence No. WM 74593 Pro-Switch Pty Ltd Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 3: Puretec Customer Service
It will give years of reliability and trouble free operation if maintained properly. This user guide is designed for Puretec SOL-2TA Water Treatment Systems. Be careful to ensure the information and illustration is applicable to your particular unit. -
Page 4: Installation Record
___________ ppm / mg/L Manganese: ___________ ppm / mg/L ___________ TDS (Total Dissolved Salts): ___________ ppm / mg/L Conductivity: ___________ EC / uS/cm Chloride: ___________ ppm / mg/L Sodium: ___________ ppm / mg/L Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 5: Before Installation
• Install as close as possible to a drain. • Install in correct relationship to other water treatment equipment. Contact Puretec for assistance. • Install the softener in the supply line BEFORE the water heater. Temperatures above 40°C (104°F) will damage the softener and void the warranty. - Page 6 & is not covered under warranty. If chlorine exceeds this limit, we recommend a carbon pre-filter such as the WH2 or CFS Series. Please refer to Puretec for a specific recommendation. In any case, a carbon pre-filter is recommended to protect against chlorine spikes &...
-
Page 7: Dimensions
Dimensions SOL110-2TA SOL160-2TA SOL270-2TA SOL380-2TA Width (mm) (W): 406 mm 533 mm 610 mm 762 mm Height (mm) (H): 1980 mm 2040 mm 2230 mm 2170 mm 660 mm Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... -
Page 8: Model Information
Commercial 2TA User Guide UG-SOL-2TA Instruction Kit (WTI-SOL110-TA) Media Funnel WTV1600 WTV5595 Injector 4lpm Suits 2CI 18" Softener Vessel Media Filling Order (for each tank/vessel) 2 x WTM7550-15L 4 x WTM4400-25B Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... - Page 9 Commercial 2TA User Guide UG-SOL-2TA Injector Kit WTV1600 Media Funnel (WTI-SOL160-TA) WTV5600 Injector 6lpm Suits 2CI 21" Softener Vessel Media Filling Order (for each tank/vessel) 2 x WTM7550-15L 7 x WTM4400-25B Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 10 Commercial 2TA User Guide UG-SOL-2TA Injector Kit Media Funnel WTV1600 (WTI-SOL270-TA) WTV5605 Injector 8.5lpm Suits 2CI 24" Softener Vessel Media Filling Order (for each tank/vessel) 3 x WTM7550-15L 10 x WTM4400-25B 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
- Page 11 Commercial 2TA User Guide UG-SOL-2CI Injector Kit Media Funnel WTV1600 (WTI-SOL380-TA) WTV5610 Injector 12lpm Suits 2CI 30" Softener Vessel Media Filling Order (for each tank/vessel) 4 x WTM7550-15L 15 x WTM4400-25B Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 12 Fig. 1 - Exploded Diagram Valve Cover Drain Line Flow Connector Transformer Injector Valve UV Shield Top Screen Riser Pipe & Top Mount (pre-installed) Pressure Tank 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 13: Exploded Diagram
Tee Connector Brine Hose Brine Hose Herbie Clip Herbie Clip 2CI Twin Alternating Valve Herbie Clip Brine Hose Brine Tank Brine Connector (pre-installed on brine tank) Flow Meter Spanner Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... - Page 14 Fig. 2 - Installation Diagram VALVE INLET CONTROL VALVE ALTb ALTERNATING VALVE UNTREATED WATER INLET VALVE INLET CONTROL VALVE ALTA 14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 15: Installation Diagram
Installation Diagram “B” TREATED PORT WATER OUTLET FLOW METER “C” PORT “A” PORT Meter Cable Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... - Page 16 Control Valve ALTA TOP VIEW "B" Port 2" "A" Port 2" Connects to Connects to Control Valve ALTB Control Valve ALTA "C" Port 2" Connects to Flow Meter SIDE VIEW 16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 17: Installation Procedure
Note: For a detailed part listing of kit components see individual model specifications on pages 8-11. Instruction & 2 x Tank Kits Injection Kit Media Brine Tank & Valve Kit 2 x DLFC Kits Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... -
Page 18: Installation Procedure
1" Polypipe for overflow (refer to page 17) Testing & Analysis Ensure water has been tested, Input values into Table on page 4 and the analysis has been inspected by Puretec. Water Analysis Information Hardness ___________ ppm / mg/L Iron... -
Page 19: Media Installation
Top up tank with water. Screw valve onto the tank (hand tight is usually sufficient), making sure the distributor tube is properly inserted into the valve. Repeat for the second tank. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... - Page 20 Connect drain and overflow to sewer or other approved salty water disposal point as approved by your local authority. 1"DRAIN BRINE 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
- Page 21 Brine Connector Brine Connector Herbie Clip Herbie Clip Tee Connector Brine Hose Brine Hose Herbie Clip Herbie Clip Brine Hose Herbie Clip Brine Connector (pre-installed on brine tank) Brine Tank Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
-
Page 22: Connecting The Overflow
Install the flow meter on the outlet of the Twin Alternating Valve (PORT "C") using food safe metal thread glue/sealant (allow to cure) or thread seal tape. Note: Check the meter cable before assembly to make sure it reaches the control valve. 22 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... - Page 23 'COMM CABLE". Connect the drive cable from the flow meter to the 2 pin port on the ALTA REGEN CLOCK NEXT control valve labelled "MAV". DOWN DOWN Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 24 ALTA as shown in the diagram below. Plug into an uninterrupted electrical outlet. Note: All electrical connections must be connected accordingly to local codes. Proceed to ‘Programming’ section 24 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 25: Valve Configuration Programming
Use ▲ and ▼ to select 2.0. Press NEXT to go to step 3. STEP 3CS Preset to default. Press NEXT to go to step 4. STEP 3CS STEP 3CS STEP 5CS STEP 4CS STEP 5CS STEP 5CS STEP 4CS Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide STEP 4CS... - Page 26 Preset to default. Press NEXT to go to step 7. STEP 5CS STEP 10CS STEP 11CS STEP 6CS STEP 1S Preset to default to PPM. Press NEXT to go to step 8. STEP 11CS STEP 2S 26 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023 STEP 7CS...
- Page 27 STEP 6S STEP 6S STEP 11CS STEP 6S STEP 6S STEP 6S 12. Press ▲ or ▼ until End appears. Press NEXT and NEXT again to return to normal mode. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
-
Page 28: Softener System Setup
Default is 60 minutes. Press NEXT to go to step 5. STEP 10S STEP 10S STEP 10S STEP 10S STEP 5S STEP 10S STEP 5S STEP 5S STEP 5S STEP 5S 28 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... - Page 29 Press NEXT to go to step 8. STEP 13S STEP 8S Using ▲ or ▼ select volume capacity to "AUTO". Press NEXT to go to step 9. STEP 9S Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide STEP 14S...
- Page 30 The start of a regeneration is defined as the first backwash cycle RETURN TO NORMAL MODE or Dn brine cycle, whichever comes first. Ranges from 1 second to 200 minutes. 30 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
- Page 31 STEP 15S or during a regeneration and deativates after a set period of time or after the meter stops registering flow, whichever comes first. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 32 Ranges from 1 second to 20 minutes. RETURN TO NORMAL MODE Press NEXT to go to step 16. RETURN TO NORMAL MODE RETURN TO NORMAL MODE 32 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 33: Installer Display Setup
STEP 3I STEP 3I Set Hardness 2 : set to 0ppm using ▲ or ▼. Press STEP 3I NEXT to go to step 4. STEP 4I STEP 4I STEP 4I Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... - Page 34 Installer Display Setup STEP 5CS STEP Note: When performing the valve configuration programming for the Alt b valve ensure "Alt b" has been selected in place of Alt A. STEP 34 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
-
Page 35: User Display Settings
Viewed only when delayed rinse and fill is set to on. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... -
Page 36: Regeneration Mode
Note: For softeners, if the brine tank does not contain salt, fill with salt and wait at least two hours before regenerating. STEP 3U RETURN TO NORMAL MODE RETURN TO NORMAL MODE 36 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 37: Set Time Of Day
Allow to run for 5 - 10 minutes. 5. Close the opened tap and check for leaks. 6. Conduct a full manual regeneration. 7. Your system is ready for use. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide... -
Page 38: Regeneration
1. Unscrew and remove the valve from the pressure tank. 2. Use a wet/dry vac to remove old media. 3. Follow Media Installation on page 19 . 4. Follow Start-Up on page 37. 38 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... -
Page 39: Replace The Backup Battery
The backup battery (CR2032 coin) keeps the time in case of a power outage. The battery should be replaced annually or after extended periods without power. Replacement batteries can also be ordered using code: BA-CR2032 through your local Puretec dealer. 1. Turn off the power to the unit and remove the valve cover. -
Page 40: Troubleshooting Guide
Verify meter cable wires are is flowing. into three pin connector. installed securely into three pin connector labelled METER. Defective meter. Replace meter. Defective PC board. Replace PC board. 40 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023... - Page 41 Check drain line for restrictions or debris and or un-kink drain line. Plugged backwash flow controller. Remove backwash flow controller and clean or replace. Missing refill flow controller. Replace refill flow controller. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 42 Drain line too long or too high. Shorten length and or height. Low water pressure. Check incoming water pressure – water pressure must remain at minimum of 25 psi. 42 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
- Page 43 Drive bracket not snapped in Snap drive bracket in properly then properly. conduct a dry reset. Control valve motor ran too long and timed out trying to reach home position. Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 44 Troubleshooting Problem Solution 18. Err - 1006, Err - 106, Contact Puretec 1300 140 140 (Australia) 0800 130 140 (New Zealand). Err 116 Motor ran too long and unable to find the proper park position. 19. Err – 1007, Err – 107, Contact Puretec 1300 140 140 (Australia) 0800 130 140 (New Zealand).
-
Page 45: Warranty
All costs relating to a warranty claim must be approved by Puretec prior to any work being carried out. 1 year warranty is 1 year parts and labour. Excludes consumables. - Page 46 46 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023...
- Page 47 Copyright © Puretec Pty Ltd 2023 SOL-2TA Commercial Series User Guide...
- Page 48 MAY2023...
