Rockwell Automation Allen-Bradley Guardmaster Minotaur MSR5T Installation Instructions

Installation Instructions
Original Instructions
Minotaur MSR5T Monitoring Safety Relay
Catalog Number 440R-B23020
Topic
Summary of Changes
Safety Notes
Repair
Functional Description
Specifications
Application Examples
Installation
Wiring Examples
Circuit Diagram
Approximate Dimensions
Safety Specifications
Declaration of Conformity
Summary of Changes
This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
Topic
Updated Declaration of Conformity
IMPORTANT This device is intended to be part of the safety-related
control system of a machine.
Safety Notes
IMPORTANT Before installation, perform a risk assessment to determine
whether the specifications of this device are suitable for all
foreseeable operational and environmental characteristics
of the machine to which it is to be fitted. At regular
intervals during the life of the machine, check whether the
characteristics foreseen remain valid.
ATTENTION: Danger of serious injuries. Misuse can result in
malfunction.
• Only authorized and trained personnel can start up, assemble,
or retrofit the device.
• Installation must be in accordance with the steps that are
described in Safety Specifications on page
ATTENTION: Danger of serious injuries. Incorrect installation
or manipulation can result in serious injuries.
• Do not defeat, tamper, remove, or bypass this unit.
Rockwell Automation does not accept responsibility for failure of this device if you
Page do not implement the procedures that are given in this publication, or if you use
the unit outside the recommended specifications that are listed in this publication.
1
1
IMPORTANT
1
1
2
2
2
3
3
IMPORTANT
3
4
4
Repair
Do not attempt repair if there is any malfunction or damage. Replace the unit
before machine operation is allowed.
Page
4
Functional Description
The device can connect to safety gate switches or E-stop buttons and requires a
supply voltage that is applied via the safety device to operate this relay unit. There
are three N.O. safety outputs plus one N.C. auxiliary for control indication.
If input switch is closed and supply is on A1-A2, the MSR5T safety relay is ready for
operation and the PWR status indicator is on. The MSR5T safety relay can now
activate via the reset (feed back loop) circuit X1-X2. The safety contacts 13-14 and
23-24 and 33-34 close and enable operation, signalized by the second status
indicator.
One N.C. contact respectively of the connected contactors or expanders must be
wired in series into the feedback circuit X1-X2 and is used to monitor contactor
function. This arrangement maintains that the MSR5T safety relay start is only
possible if the contactors are at rest and their N.C. contacts are closed. If X1-X2 is
closed at the time when voltage supplies at A1-A2, the unit performs an automatic
4.
reset.
The safety inputs of these products are described as
normally closed (N.C.), that is, with the guard closed,
the actuator in place (where relevant), and the machine
able to start. You must prevent exposure to shock and/
or vibration in excess of those specifications in IEC
60068 part: 2-6/7. Adherence to the recommended
inspection and maintenance instructions forms part of
the warranty.
All information complies with the state of this
publication and is subject to change without notice.
ATTENTION: Do not dismantle the unit.
