Summary of Contents for Mean Well RCP-2000
- Page 1 RCP-2000 / RKP-1U I n s t r u c t i o n M a n u a l...
- Page 2 0.Safety Guidelines 1.Introduction of Series Models 1.1 Introduction 1.2 Features 1.3 Order Information 1.4 Main Specification 2.Mechanical Specification and Input / Output Terminals 2.1 Mechanism of Single Unit 2.2 Mechanism of Whole Rack System 3.Functions 3.1 Input Voltage Range 3.2 Inrush Current Limiting 3.3 Output Power 3.4 Power Factor Correction (PFC 3.5 Output Voltage Adjustment...
- Page 3 RCP-2000 or RKP-1U by yourself! Please do not change any component on the RCP-2000 series by yourself or make any kind of modification on it. Please do not install the RCP-2000 series in places with high moisture, high ambient temperature or under direct sunlight.
- Page 4 100A AC-OK (C) AC-OK (C) 50/60Hz 50/60Hz C-OK C-OK Use only RCP-2000 series power supplies of the Use only RCP-2000 series power supplies of the P.V (C) P.V (C) same output voltage rating same output voltage rating T-ALARM (C) T-ALARM (C)
- Page 5 5. Derating may be needed under low input voltages. Please check the derating curve for more details. 6. Output of all the RCP-2000 modules are connected in parallel in the rack. 7. Under parallel operation of more than one rack connecting together, ripple of the output voltage may be higher than the SPEC at light load condition.
- Page 6 Input / Output Connector Pin No. Assignment(CN501) : Postronic PCIM34W13M400A1 Pin No. Assignment Pin No. Assignment Pin No. Assignment Pin No. Assignment Pin No. Assignment Pin No. Assignment Mating Housing ON/OFF T-ALARM 1,2,3,4 5,6,7,8 FAN-FAIL AC/L Postronic -V(signal) +5V-AUX AC/N PCIM34W13F400A1 +V(signal) AC-OK...
- Page 7 Connector Pin No. Assignment of CN500 Pin No. Assignment Pin No. Assignment Pin No. Assignment Pin No. Assignment Pin No. Assignment ON/OFF-A FAN FAIL-A T-ALARM-B ON/OFF-C FAN FAIL-C AC-OK-A ON/OFF-B FAN FAIL-B AC-OK-C DC-OK-A AC-OK-B +5V-AUX DC-OK-C PV-A DC-OK-B +12V-AUX PV-C T-ALARM-A PV-B...
- Page 8 3.5.1 Adjustment of single unit Output voltage of one RCP-2000 is adjustable through the potentiometer (SVR1, can be found under the small circular hole on top of the unit). Please use a cross-screwdriver with isolated holder to make the adjustment.
- Page 9 In the mean time, there will be a "High" signal (4.5~5.5V) between "FAN FAIL" and "GND-AUX" on CN500 connector. Please switch off the AC source and send back to our local distributor or MEAN WELL for repair. 3.13 Remote Control Built-in remote ON/OFF control circuit.
- Page 10 Internal parallel operation in single rack is only suitable for using the same RCP-2000 unit (single unit with the same output voltage and current). Each rack (RKP-1U ) have the built-in parallel connection / wiring. Once the RCP-2000 unit insert in the rack then the parallel connection is done.
- Page 11 Higher output voltage can be acquired by connecting different racks in series. The racks (RKP-1U ) connected in series should have the same single unit (RCP-2000- ) in each rack. Please refer to Figure 3-9 for the reference connection method.
- Page 12 DIP switch position Table 3-1 3.19.2 PMBus Command List Table 3-2 shows the command list of RCP-2000. It is compliant with industry standard PMBus protocol Rev. 1.1. For more details about the information, you can refer to PMBus official web ( http://pmbus.org/specs.html...
- Page 13 Command Command Transaction # of data Description Code Name Type Bytes Output voltage trimming value VOUT_TRIM R/W Word (format: Linear, N= -9) Output overcurrent setting value IOUT_OC_FAULT_LIMIT R/W Word Define protection and response when an IOUT_OC_FAULT_RESPONSE R Byte output overcurrent fault occurred STATUS_WORD R Word Summary status reporting...
- Page 14 Don't care 00h (OFF) Table 3-6 2.If RCP-2000 is restarted, the parameters of output voltage and output current you have set will return to initial default values. 3.If PMBus is offline(such as RCP-CMU-1 shutdown),the parameters of OPERATION, VOUT_TRIM, and IOUT_OC_ FAULT_LIMIT you have set will return to initial default values.
- Page 15 This is a power supply with built-in DC fan and please make sure the ventilation is not blocked. It is suggested that there should be no barriers within 10cm of the ventilation holes. Connect AC source to the AC input for A, B, C. module position respectively depending on the RCP-2000 units assembled into the RKP-1U rack.
- Page 16 Three years of global warranty is provided for RCP-2000 series/ RKP-1U under normal operation. Please do not change any component or modify the unit by yourself or MEAN WELL may reserve the right not to provide the complete warranty service.
