Mean Well RST-10000 Series Manual

1
10000W Power Supply with Single Output
Dimension
L * W * H
540 * 424 * 83.5 (2U)
21.3 * 16.7 * 3.29
UL62368-1
■ Features ■ Features
3 ψ 3-wire / △ 196~305VAC or 3
wide input range
Built-in active PFC function
High efficiency up to 90.5%
Forced air cooling by built-in DC fan
Output voltage and constant current level programmable
Active current sharing up to 20000W (1+1)
Built-in remote ON-OFF control / Remote sense
/ Auxilary power / Alarm signal
Protections: Short circuit / Overload / Over voltage /
Over temperature / Fan fail
5 years warranty
■ Description
RST-10000 is a 10KW single output enclosed type AC/DC power supply. This series operates for the wide
range three phase AC input (3 phase 3 wire /
the models with the DC output mostly demanded from the industry. Each model is cooled by the built-in
fan with fan speed control, working for the temperature up to ,70 . Moreover, RST-10000 provides vast
design flexibility by equipping various built-in functions such as the output programming, active current
sharing, remote ON-OFF control, auxiliary power, etc.
■ Model Encoding
RST - 10000 24
mm
(2U) inch
Bauar t gepruft
Sicherheit
egel ma ge
od o s
be wac g
www. tuv.com
ID 2000000000
BS EN/EN62368-1 TPTC004 IEC62368-1
ψ 4-wire / Y 340~530VAC
-
Output voltage (24V/36V/48V)
Output wattage
Series name
R S T- 1 0 0 0 0
IS 13252
THOMAS SAMUEL THOMAS SAMUEL
■ Applications
Factory control or automation apparatus
Test and measurement instrument
Laser related machine
Burn-in facility
RF application
Electric scooter or vehicle charger station
Constant current source
■ GTIN CODE
MW Search:
△ 196~305VAC or 3 phase 4 wire / Y 340~530VAC) and offers
℃
RST-10000_1680-21407-0839-E-0125
s e r i e s
User's Manual
https://www.meanwell.com/serviceGTIN.aspx
File Name:RST-10000-SPEC 2024-09-04
