Introduction
T M
ORing's Transporter
series managed Ethernet switches are designed for
industrial applications, such as rolling stock, vehicle, and railway
applications. The
TES-3080-M12 series
Ethernet switch with 8x10/100Base-T(X) ports which is compliant with
EN50155 request. With completely support of Ethernet Redundancy
protocol, O-Ring (recovery time < 10ms over 250 units of connection), O-
Chain, MRP
*NOTE
and MSTP/RSTP/STP (IEEE 802.1s/w/D) can protect
your mission-critical applications from network interruptions or temporary
malfunctions with its fast recovery technology. It is specifically designed for
the toughest industrial environments.
Ethernet switch use M12 connectors to ensure tight, robust connections, and
guarantee reliable operation against environmental disturbances, such as
vibration and shock.
TES-3080-M12-BP2
bypass ports protect the network from failures and Network maintenance by
ensuring network integrity during power loss. Each of these bypass ports
includes Network ports and Monitor ports. The Network ports are used for
connection to main-network connections and provide protection mechanism,
and the Monitor ports are used for down-link local networking device. When
the power is on, the operating mode of the Bypass ports is set to Normal ,
and the local networking device is connected with main-network. When
power failure occurs, the Bypass ports is swiftly set to bypass mode to
isolate the main-network from the local networking device. TES-3080-M12
series can be managed centralized and convenient by a powerful windows
utility ~ Open-Vision. In addition, the wide operating temperature range from
-40°C to 70°C can satisfy most of operating environment. Therefore, the
switch is one of the most reliable choices for rolling stock and highly-
managed Ethernet application.
*NOTE: This function is available by request only.
Package Contents
The device is shipped with the following items. If any of these items is missing
or damaged, please contact your customer service representative for
assistance.
Contents
Pictures
TES-3080-M12 or
TES-3080-M12-BP2 or
TES-3080-M12-BP2-MV or
TES-3080-M12-BP2-HV
QIG
CD
Preparation
Before you begin installing the device, make sure you have all of the package
contents available and a PC with Microsoft Internet Explorer 6.0 or later, for
using web-based system management tools.
Q I G
TES-3080-M12 Series
TES-3080-M12 Series
G
uide
Safety & Warnings
Elevated Operating Ambient: If installed in a closed environment, make sure the
is a managed Redundant Ring
operating ambient temperature is compatible with the maximum ambient temperature
(Tma) specified by the manufacturer.
Reduced Air Flow: Make sure the amount of air flow required for safe operation of the
equipment is not compromised during installation.
Mechanical Loading: Make sure the mounting of the equipment is not in a hazardous
condition due to uneven mechanical loading.
Circuit Overloading: Consideration should be given to the connection of the equipment to
TES-3080-M12 series
EN50155
the supply circuit and the effect that overloading of the circuits might have on overcurrent
protection and supply wiring. Appropriate consideration of equipment nameplate ratings
should be used when addressing this concern.
included dual bypass ports, These
Dimension
15.0
65.0
TES-3080-M12/ TES-3080-M12-BP2
Number
Panel Layouts
Front View
1
TES-3080-M12-BP2
PWR1
PWR2
R.M.
Ring
Fault
1
1 2
3 4 5
6
Console
RXD
TXD
1
Power
N.C.
Failure
Bypass
N.C.
GND
RS-232, 9600bps, 8, N, 1
V1+
V2+
V1-
V2-
7
Power
1907-200-S3080M12X2-FX010
Unit =mm (Tolerance ±0.5mm)
86.0
56.5
Ø8.0
Relay
N.C.
Relay Output
3A@24VDC
TES-3080-M12-BP2
TES-3080-M12-BP2-MV
PWR1
PWR2
R.M.
Ring
Fault
PWR1
LNK/ACT
DPX/COL
P4
P8
LNK/ACT
Console
RXD
TXD
Power
DPX/COL
N.C.
Failure
Bypass
P3
P7
N.C.
GND
RS-232, 9600bps, 8, N, 1
LNK/ACT
V1+
V2+
V1-
V2-
DPX/COL
P2
P6
LNK/ACT
DPX/COL
Tx+
Rx+
P1
P5
Power
Rx-
Tx-
15.0
125.0
65.0
Reset
TES-3080-M12-BP2-MV/ TES-3080-M12-BP2-HV
1. Power1 status LED
2. Power2 status LED
Relay
N.C.
Relay Output
3. R.M. status LED
3A@24VDC
4. Ring status LED
8
5. Fault LED
LNK/ACT
6. Console port
DPX/COL
7. Power input port
P4
P8
8. Relay output
LNK/ACT
9. LNK/ACT LED for LAN ports
DPX/COL
10. Duplex/Collision LED for LAN ports
P3
P7
9
LNK/ACT
11. Ethernet ports
(P1-P4 of TES-3080-M12-BP2 is bypass ports)
DPX/COL
P2
P6
10
LNK/ACT
11
DPX/COL
Tx+
Rx+
P1
P5
Rx-
Tx-
PRINTED ON RECYCLED PAPER
EN50155 8-port managed
Ethernet switch
Bottom View
1. Reset button
1
Reset
Installation
Wall-mount
The device can be fixed to the wall. Follow the steps below to install the device on the wall.
Step 1: Hold the
d
evice upright against the wall
Step 2: Insert four screws through the large opening of the keyhole-shaped apertures at the
top and bottom of the unit and fasten the screw to the wall with a screwdriver.
116.0
86.5
Step 3: Slide the
d
evice downwards and tighten the four screws for added stability.
Ø8.0
Relay
N.C.
Relay Output
3A@24VDC
PWR2
R.M.
Ring
Fault
LNK/ACT
DPX/COL
P4
P8
LNK/ACT
Console
RXD
TXD
Power
DPX/COL
N.C.
Failure
Bypass
P3
P7
N.C.
GND
RS-232, 9600bps, 8, N, 1
LNK/ACT
V1+
V2+
V1-
V2-
DPX/COL
P2
P6
LNK/ACT
DPX/COL
Tx+
Rx+
P1
P5
Power
Rx-
Tx-
155.0
Reset
Wiring
For pin assignments of power, console and relay output ports, please refer to the following tables.
Grounding
Grounding and wire routing help limit the effects of noise due to electromagnetic interference
(EMI). Run the ground connection from the grounding pin on the power connector to the grounding
surface prior to connecting devices.
Power port pinouts
The device supports two sets of power supplies and uses the M23 5-pin
female connector on the front panel for the dual power inputs.
Step 1: Insert a power cable to the power connector on the device.
Step 2: Rotate the outer ring of the cable connector until a snug fit is
achieved. Make sure the connection is tight.
Console port pinouts
RXD
TXD
N.C.
N.C.
GND
RS-232, 9600bps, 8, N, 1
Relay output port pinouts
The switch uses the M12 A-coded 5-pin female connector
on the front panel for relay output. Use a power cord with an
M12 A-coded 5-pin male connector to connect the relay.
The relay contacts will detect user-configured events and
form an open circuit when an event is triggered.
Version 2.0
Instead of screwing the screws in all the way, it is
advised to leave a space of about 2mm to allow room for
sliding the switch between the wall and the screws.
V1+
V2+
V1-
V2-
Relay
N.C.
3A@24VDC
Quick Installation Guide
