- Page 1 Henny Penny Heated Holding Cabinet Model HHC-901 Model HHC-904 TECHNICAL MANUAL...
-
Page 3: Table Of Contents
Model HHC-901/904 TABLE OF CONTENTS Section Page Section 1 TROUBLESHOOTING ....................... 1-1. Introduction ........................1-2. Safety .......................... 1-3. Test Instrument ......................1-4. Troubleshooting ......................1-5. Error Codes ......................... Wiring Diagrams ......................Section 2. PARTS INFORMATION ..................... 2-1. Introduction ........................2-2. Genuine Parts ...................... -
Page 4: Section 1. Troubleshooting
Model HHC-901/904 SECTION 1. TROUBLESHOOTING 1-1. INTRODUCTION This section provides troubleshooting information in the form of an easy to read table. If a problem occurs during the first operation of a new cabinet. 1-2. SAFETY Where information is of particular importance or is safety related, the words NOTICE, CAUTION, or WARNING are used. -
Page 5: Test Instrument
Model HHC-901/904 You may use two test instruments to check the electrical 1-3. TEST INSTRUMENTS components. 1. A voltmeter 2. An ohmmeter. When the manual refers to the circuit being closed, the ohmmeter should read zero unless otherwise noted. When the manual refers to the circuit being open, the ohmmeter will read infinite resistance. -
Page 6: Operation
Model HHC-901/904 1-4. TROUBLESHOOTING (Continued) PROBLEM CAUSE CORRECTION OPERATION A.Product not • Doors are left open • Keep doors closed except to holding load and unload product temperature • Temperature set too low • Increase temperature per instructions in Operator’s Manual •... - Page 7 Model HHC-901/904 1-4. TROUBLESHOOTING (Continued) PROBLEM CAUSE CORRECTION HEATING SYSTEM (Continued) B.Unit will not • Faulty blower • Check blower and replace if needed heat to desired temperature • Display not indicating • Check probe calibration and true temperature change calibration or offset if necessary •...
-
Page 8: Error Codes
Model HHC-901/904 1-5. ERROR CODES DISPLAY CAUSE PANEL BOARD CORRECTION “E-4” Control board Turn switch to OFF position, then turn switch back to overheating ON; if display shows “E-4”, the control board is getting too hot; make sure unit is not overheating; if control board is not overheating and “E-4”... -
Page 9: Wiring Diagrams
Model HHC-901/904 WIRING DIAGRAMS CDT CONTROLS - 120V 1209... -
Page 10: Simple Controls - 120V
Model HHC-901/904 WIRING DIAGRAMS SIMPLE CONTROLS - 120V 1209... - Page 11 During this time, any frypot that fails due to manufacturing or workmanship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.
-
Page 12: Section 2. Parts Information
Model HHC-901/904 SECTION 2. PARTS INFORMATION 2-1. INTRODUCTION This section lists the replaceable parts of the Henny Penny HHC-901 & HHC-904 units. 2-2. GENUINE PARTS Use only genuine Henny Penny parts in your cabinet. Using a part of lesser quality or substitute design may result in damage to the unit, or personal injury. - Page 13 Model HHC-901/904 1209...
- Page 14 Item No. Part No. Description Quantity 67472 ASSY-POWER CORD 120/20A STR 79906 DECAL-REAR CONT 13CDT 901 81963 DECAL-REAR CONTROL 6CDT 904 77741 ASSY-DOOR RH SS 2B HC901/904 83742 ASSY-DOOR LH SS 2B HC901/904 81927 ASSY-DOOR FLIP LH HC904 79997 ASSY-DOOR FLIP RH HC904 81921 ASSY-DOOR FLIP LH HC901 77742...
- Page 15 Item No. Part No. Description Quantity 79500 DECAL- CONTROL PANEL 13CDT 901 81960 DECAL- CONTROL PANEL 6CDT 904 77755 DECAL - CONTROL PANEL - SIMPLE √ √ √ √ √ 2 72277 SWITCH - POWER - SPLASH PROOF √ √ √ √ √ 3 29523 ASSEMBLY - RTD PROBE √...
- Page 16 Item No. Part No. Description Quantity √ √ √ √ √ 1 63363 BLOWER - MOTOR - 120V √ √ √ √ √ 2 51278 HEATER - COIL - 750W - 120V √ √ √ √ √ 3 18201 SENSOR - HIGHT LIMIT - 335 DEG 63360 FAN BLADE *not shown...
- Page 17 Item No. Part No. Description Quantity 77774 ASSY - AIR DUCT - LOWER - 901 77776 ASSY - AIR DUCT - UPPER - 901 80044 ASSY - AIR DUCT - 904 77768 GASKET - DOOR - 901/904 1/DOOR 71478 WATER BOX ASSEMBLY 70381 WATER BOX &...
