SolaX Power T-BAT Series User Manual

Triple power lithium-ion battery

Hide thumbs Also See for T-BAT Series:

User manual (21 pages)

User manual (22 pages)

page of 31

/ 31
Bookmarks

Quick Links

Download this manual

SolaX Power Network Technology (Zhejiang) Co., Ltd.

Add.: No. 288, Shizhu Road, Tonglu Economic Development Zone, Tonglu City,

Zhejiang Province, 310000 P.R. CHINA

Tel.: +86 (0) 571-5626 0011

E-mail: info@solaxpower.com

No part of this document may be reproduced or transmitted in any form or by any means without

prior written consent of SolaX Power Technology (Zhejiang) Co., Ltd. (hereinafter referred to as

SolaX). SolaX reserves the right of final interpretation.

320101034403

Triple Power Lithium-ion Battery

100 Ah

User Manual

Need help?

Do you have a question about the T-BAT Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SolaX Power T-BAT Series

Page 1 Zhejiang Province, 310000 P.R. CHINA No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of SolaX Power Technology (Zhejiang) Co., Ltd. (hereinafter referred to as Tel.: +86 (0) 571-5626 0011 SolaX).
Page 2 Contents NOTE ON THIS MANUAL..........1 1.1 SCOPE OF VALIDITY ..........1 1.2 TARGET GROUP .............1 1.3 SYMBOLS............1 SAFETY ............2 2.1 SAFETY INSTRUCTIONS ..........2 2.1.1 GENERAL SAFETY PRECAUTIONS.........2 2.1.2 EXPLANATION OF SYMBOLS ........3 2.2 RESPONSE TO EMERGENCY SITUATIONS ......4 2.2.1 LEAKING BATTERIES ..........4 2.2.2 FIRE ............4 2.2.3...
Page 3 Scope of Validity 7.1 COMMISSIONING ..........43 7.2 STATUS INDICATORS ..........44 This manual is an integral part of theT-BAT Series. It describes the assembly, 7.2.1 BMS (TBMS-MCS60060) ........44 installation, commissioning, maintenance and failure of the product. Read it 7.3 SHUTTING DOWN T-BAT SYSTEM........46 carefully prior to operation.
Page 4 2. Safety 2. Safety Safety 2.1.2 Explanation of Symbols Safety Instructions Symbol Explanation For safety reasons, installers are responsible for familiarizing themselves with the contents of this manual and all warnings before performing installation. CSA mark for UL1973 2.1.1 General Safety Precautions 272687 WARNING! CE mark of conformity...
Page 5 2. Safety 2. Safety Response to Emergency Situations Qualified Installer 2.2.1 Leaking Batteries In case the leakage of electrolyte solution occurs, please avoid direct contact with WARNING! the electrolyte solution and the gas that may be generated by it. Direct contact may All operations of T-BAT-SYS-HV relating to electrical connection and lead to skin irritation or chemical burns.
Page 6 3. Product Infromation 3. Product Information Appearance Product Information Section View of BMS Ÿ Dimensions and Weight Right A battery management system (BMS) is an electronic system that manages a rechargeable battery. A battery module is a type of electrical battery which can charge or discharge loads.
Page 7 3. Product Information 3. Product Information Basic Features Section view of battery module Ÿ 3.2.1 Features The T-BAT-SYS-HV, adopting advanced technology and having the characteristics of high reliability and convenient to control, is one of the most advanced energy storage systems in today's market, with details as below: 90% DOD Ÿ...
Page 8 3. Product Information 4. Preparation before Installation Specifications Prepration before Installation 3.4.1 T-BAT-SYS-HVConfiguration List Prerequisites Energy(kWh) Voltage (V) Model Battery Module When assembling the system, avoid touching the battery terminals with any metal TBMS-MCS60060×1 T-BAT H 10.0 TP-HS50 × 2 90-116 object or bare hands.
Page 9 4. Preparation before Installation 4. Preparation before Installation Safety Gear Inspection Installation and maintenance personnel must strictly comply with the applicable 4.4.1 Check for Transport Damage federal, state, and local regulations as well as industry standards on product installation. To avoid short circuit and personal injury, respirator, gloves, goggles and Ensure that the battery has been received in good condition.
Page 10 4. Preparation before Installation 4. Preparation before Installation All Accessories Required for Two Installation Modes 4.4.3 Accessory BMS (TBMS-MCS60060): Accessories included are shown as follows: Item Description Quantity User Manual Safety Instructions OneBattery Module (TP-HS50×1): Accessories included are shown as follows: Item Description Quantity...
Page 11 5. Installation 5. Installation Installation Floor Mounting 5.1 Installation Environment Requirements 5.3.1 Overview There are three schemes available for users. ● Ensure that the equipment is installed in a well ventilated environment. Scheme A ● To prevent fire due to high temperature, ensure that the ventilation vents or heat dissipation system are not blocked when the equipment is running.
Page 12 5. Installation 5. Installation Scheme B Scheme C 4 * Wall Bracket 4 * Expansion Bolt 4 * Wall Bracket Battery Battery 4 * Tapping Screw 4 * Expansion Bolt 4 * Gasket Battery 4 * Tapping Screw Battery 20 * M5*10 Screw 4 * Gasket 4 * Platen (3 holes) Battery...
Page 13 5. Installation 5. Installation 5.3.2 Step Step 2: Locate the Base 1.57 in./40 mm away from the wall, accurately mark the location of the Base on both sides with a pen. Please reserve enough distance from the equipment to the ceiling/ground for capacity expansion.
Page 14 5. Installation 5. Installation (3) Fix the Platen (2 holes) using M5 * 10 Phillips-head screw, and secure M5*10 Step 5: screws (2) to connect Base and Battery Module (Torque: 1.0 N·m). (1) Attach M5 * 10 screw to Wall Bracket but be sure not to tighten; (2) Place such Wall Bracket to the wall, align its holes to the holes on the Battery Module, and use a spirit level to measure the Wall Bracket to ensure it's even;...
Page 15 5. Installation 5. Installation Step 8: Place the fourth battery module. Step 6: Place Expansion Bolts into the two holes (the Expansion Bolt is not required in case of solid wood wall). Let the Platen down Step 7: Place the Wall Bracket on the wall where the mark is drawn previously, and then secure the Wall Brackets on the wall using Tapping Screws and Gaskets.
Page 16 5. Installation 5. Installation Step 10: (2) Place the BMS, fix the Platen (3 holes) on both sides of Battery Module using M5 (1) Attach M5 * 10 screw to Wall Bracket but be sure not to tighten; * 10 Phillips-head screw, and then tighten M5*10 screws (Torque: 1.0 N·m). Refer to (2) Place such Wall Bracket to the wall, align its holes to the holes on the Battery Step 9.
Page 17 5. Installation 5. Installation Scheme B Wall Mounting 4 * Wall Bracket 5.4.1 Overview There are three schemes available for users. 4 * Expansion Bolt Battery Scheme A 4 * Tapping Screw 4 * Gasket 2 * Wall Bracket Battery 20 * M5*10 2 * Expansion Bolt 4 * Platen (3 holes)
Page 18 5. Installation 5. Installation Scheme C 5.4.2 Step Please reserve enough distance from the equipment to the ceiling/ground for capacity expansion. Take Scheme C as an example. 4 * Wall Bracket Battery 4 * Expansion Bolt Step 1: There are two ways to install Transverse Plate to Base Support due to 4 4 * Tapping Screw kinds of Stub Spacing, with details as follows: (a) 28 in./711.20 mm or 32 in./812.80 Battery...
Page 19 5. Installation 5. Installation Step 2: Step 3: (1) Place the assembled Transverse Plate and Base Support on the wall, look the (1) Place the assembled Transverse Plate and Base Support to the wall (or solid cylindrical plastic bubble spirit level on the Transverse Plate. If the bubble isn't in the wood wall);...
Page 20 5. Installation 5. Installation Step 4: Place the base. (3) Fix the Platen (2 holes) using M5 * 10 Phillips-head screw, and secure M5*10 (1) Remove the dust cover. screws (2) to connect Base and Battery Module (Torque: 1.0 N·m). (2) Place Base on the Base Support and secure both left and right sides with screws (4 ×...
Page 21 5. Installation 5. Installation Step 7: Step 8: Place Expansion Bolts into the two holes (the Expansion Bolt is not required (1) Attach the M5 * 10 screw to Wall Bracket but be sure not to tighten; in case of solid wood wall). (2) Place such Wall Bracket to the wall, align its holes to the holes on the Battery Module, and use a spirit level to measure the Wall Bracket to ensure it's even;...
Page 22 5. Installation 5. Installation Step 10: Place the fourth battery module. Step 12: (1) Attach the M5 * 10 screw to Wall Bracket but be sure not to tighten; (2) Place such Wall Bracket to the wall, align its holes to the holes on the Battery Module, and use a spirit level to measure the Wall Bracket to ensure it's even;...
Page 23 5. Installation 6. Wiring (2) Place the BMS, fix the Platen (3 holes) on both sides of Battery Module using M5 6 Wiring * 10 Phillips-head screw, and then tighten M5*10 screws (Torque: 1.0 N·m). Refer to Step 11. 6.1 Making a BMS communication cable To ensure normal operation of BMS and inverter, a BMS communication cable is required to be made before wiring.
Page 24 6. Wiring 7. Commissioning Commissioning 6.2 Wiring Commissioning Note! Before wiring, the guards (if any) shall be removed from connectors. The parts Verify the model number of each battery module to ensure thatthey are allthe where BMS needs to wire are as follows: same model.
Page 25 7. Commissioning 7. Commissioning Status Indicators SOC power indicator Fault Fault code 7.2.1 BMS (TBMS-MCS60060) Secondary cell voltage (overvoltage & undervoltage of cell and pack) Temperature fault of secondary cell (overtemperature and The power indicators show the current battery percentage, with details as show in undertemperature during charge and discharge) the figure below.
Page 26 7. Commissioning 8. Troubleshooting Troubleshooting Shutting Down T-BAT System To shut down the system, follow the steps described below: Troubleshooting Step Description Check the previous indicators to determine the status of the T-BAT system. Press the right side door panel In case of the following circumstances, e.g.
Page 27 8. Troubleshooting 8. Troubleshooting Description Diagnosis & Solution Description Diagnosis & Solution Error Error The temperature of BMS is too high. Different type of BMS. BMS type High • Let BMS cool down to normal • Restart BMS; BMS_Type_Unmatch matching error BMS_TemHigh temperature of temperature and restart;...
Page 28 8. Troubleshooting 9. Decommissioning Decommissioning Description Diagnosis & Solution Error BMS sampling fault. Dismantling the Battery Disconnection Restart BMS; • BMS_Break fault of BMS Contact the Company's after-sales • Shutting down the battery unit personnel. Disconnect the cables betweenthe BMS and inverter Ÿ...
Page 29 10. Maintenance 11. Disclaimer Maintenance Disclaimer -If the ambient temperature for storage is -4℉~122℉/-20℃~50℃, recharge the Triple Power will service the warranty when it is installed and used as described in batteries at least once every 3 months. the Manual. Otherwise, it will not be covered by warranty. In case there is any direct or indirect damage or defect caused by the following -If the ambient temperature for storage is 32°F~104°F/0℃~40℃, recharge the circumstances, Triple Power will not assume any warranty responsibility.
Page 30 Warranty 11. Disclaimer Registration Form WARNING This equipment has been tested and found to comply with the limits for a Class B For Customer (Compulsory) digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is Country Name...
Page 31 PLEASE REGISTER THE WARRANTY IMMEDIATELY AFTER INSTALLATION! GET YOUR WARRANTY CERTIFICATE FROM SOLAX! KEEP YOUR INVERTER ONLINE & WIN SOLAX POINTS! Open your Wait for the camera app camera to and point recognize your device the QR code at the QR code Notiﬁcation Click the notiﬁcation banner...
