Triple Power Lithium-ion Battery
User Manual
45Ah/63Ah
Solax Power Network Technology(Zhe jiang) Co,. Ltd.
Copyright Declaration
The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,. Ltd. Any
corporation or individual should not plagiarize, partitially or fully copy (including software,etc.),
and no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX
Power Network Technology (Zhe jiang) Co.,Ltd. reserves the right of final interpretation.
614.00331.03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SolaX Power T-BAT Series
Summary of Contents for SolaX Power T-BAT Series
- Page 1 Solax Power Network Technology(Zhe jiang) Co,. Ltd. Copyright Declaration The copyright of this manual belongs to Solax Power Network Technology(Zhe jiang) Co,. Ltd. Any corporation or individual should not plagiarize, partitially or fully copy (including software,etc.), and no reproduction or distribution of it in any form or by any means. All rights reserved. SolaX Power Network Technology (Zhe jiang) Co.,Ltd.
-
Page 2: Table Of Contents
CONTENTS NOTE ON THIS MANUAL...............1 SCOPE OF VALIDITY..................1 TARGET GROUP....................1 SYMBOLS USED....................1 SAFETY....................2 SAFETY INSTRUCTIONS..................2 2.1.1 GENERAL SAFETY PRECAUTIONS...............2 2.1.2 EXPLANATION OF SYMBOLS.................3 RESPONSE TO EMERGENCY SITUATIONS..........5 2.2.1 LEAKING BAT TERIES..................5 2.2.2 FIRE...........................5 2.2.3 WET BAT TERIES AND DAMAGED BAT TERIES..........5 QUALIFIED INSTALLER..................6 PRODUCT INTRODUCTION..............7 PRODUCT OVERVIEW..................7... -
Page 3: Note On This Manual
CABLE CONNECTION..................19 Scope of Validity 4.5.1 CONNECTING POWER CABLES..............19 This manual is an integral part of T-BAT Series. It describes the assembly, 4.5.2 CONNECTING RS485 COMMUNICATION CABLE.........23 installation, commissioning, maintenance and failure of the product. Please read 4.5.3 CONNECTING CAN COMMUNICATION CABLE........24 it carefully before operating. -
Page 4: Safety
Ingress Protection: IP 55 – Do not dispose of the battery module in a fire. Operating Temperature: 0~+45℃ Storage Temperature: -20~+50℃ SolaX Power Network Technology (Zhejiang) Co., Ltd Risks of fire Ÿ ADD: No.288 Shizhu Road, Tonglu Economic Development Zone, Made in China Dongxing District, Tonglu City, Zhejiang Province, China. -
Page 5: Response To Emergency Situations
Response to Emergency Situations Symbol Explanation 2.2.1 Leaking Batteries If the battery leaks electrolyte which is corrosive, avoid contact with the leaking liquid or gas. Direct contact may lead to skin irritation or chemical burns. If one is exposed to the leaked substance, do these actions: TUV mark for IEC62619 Accidental inhalation of harmful substances: Evacuate people from the contaminated area , and seek medical attention immediately. -
Page 6: Qualified Installer
3. Product Introduction Product Introduction Qualified Installer Product Overview Triple power battery is a series of High Voltage Lithium-ion battery. It is designed WARNING! for residential and commercial energy storage system. All operations of T-BAT SYS-HV relating to electrical connection and installation must be carried out by qualified personnel. -
Page 7: Appearance
3. Product Introduction 3. Product Introduction Section view of HV10045/HV10063 Ÿ 3.1.2 Appearance Section view of MC0500 Ÿ Ⅲ’ Ⅳ’ Ⅰ’ Ⅱ’ Ⅳ’Ⅴ’ Ⅵ’ Ⅸ Ⅰ Ⅱ Ⅲ Ⅳ Ⅴ Ⅵ 100% Status Status Capacity Ⅶ Ⅷ Object Mark Description Ⅰ... -
Page 8: Basic Features
3. Product Introduction 3. Product Introduction Basic Features Specifications 3.2.1 Features 3.3.1 T-BAT SYS-HV Configuration List The T-BAT SYS-HV is one of the advanced energy storage systems on the market Model Battery Module Energy(kWh) Voltage (V) today, incorporating state-of-the-art technology, high reliability, and convenient MC0500x1 control features shown as below: T-BAT H4.5... -
Page 9: Installation
4. Installation 4. Installation Installation Tools These tools are required to install the T-BAT system. Installation Prerequisites Make sure that the installation location meets the following conditions: The building is designed with resistance to earthquakes Ÿ The location is far away from the sea, to avoid sea water and humid air Ÿ... -
Page 10: Accessories
4. Installation 4. Installation 4.4.3 Accessories Battery Module (T45/T63): BMS (Master Box): Object Description Quantity Power cable between battery modules (400mm) The table below lists the number of each component. RS485 communication cable (400mm) Object Description Quantity Wall mounting bracket Battery Power cable (+) Floor mounting bracket Battery Power cable (-) -
Page 11: Install Bms To Battery Module
4. Installation 4. Installation 4.4.4 Install BMS to Battery Module 4.4.5 Mounting Steps Install the BMS on the battery module. Fix it with M5 screws on holes shown as below with L-type Wrench(J). Please pay attention to the correct direction of BMS It is recommended that the space between battery modules is more than and battery modules, and put the same side of BMS and battery modules at front. -
Page 12: Cable Connection
4. Installation 4. Installation Wall mounting: Cable Connection Make sure the wall is strong enough to withstand the weight of battery modules. Step 1: Fix the wall mounting bracket (C1) on the wall 4.5.1 Connecting Power Cables ·Use the wall bracket as a template to mark the position of the 5 holes. For one battery module: ·Drill holes with a φ10 drill bit, make sure the holes are deep enough(at least The color at both end of the power cable©... - Page 13 4. Installation 4. Installation Notes for Unplugging Power Cables For 2~4 battery modules: The power cable between battery modules (A1) is different from the one that CAUTION! between BMS and battery module ©. The other end of the power cable is black, DO NOT plug/unplug power cables when the T-BAT system is not turned off, and this color is connected to YPLG (Ⅴ’), which is on the right side of the battery otherwise there will be an arc discharge that could cause serious injury!
-
Page 14: Connecting Rs485 Communication Cable
4. Installation 4. Installation 2. After all the battery modules were correctly connected, plug the short-circuit 4.5.2 Connecting RS485 Communication Cable plug (F) at YPLUG (Ⅴ’) of last battery module to make a complete circuit. For one battery module: 1. There's a protective cap for the RS485 connector, unscrew the cap and plug one end of the RS485 communication cable to the RS485 connector on BMS. -
Page 15: Connecting Can Communication Cable
4. Installation 4. Installation 4.5.3 Connecting CAN Communication Cable 4.5.4 Connecting Ground Wire It is required for the BMS to communicate with the inverter for proper operation. For one battery module: Unscrew the ground terminal with hexagon wrench on BMS and battery module at either side of the ground port as marked at the following figure. - Page 16 4. Installation 4. Installation Ø Connecting Battery Power Cables between Inverter and BMS: 4.5.5 Connecting Battery Power Cables This step is to connect battery power cables between Inverter and T-BAT system. 1. Connect the battery power cables between Inverter and BMS. Please pay attention to connect the cables (+,-) to the correct BAT port on both the Inverter and BMS.
-
Page 17: Overview Of Installation
4. Installation 5. Commissioning Overview of Installation Commissioning The following diagram is a complete T-BAT system installation with four battery Configuring Battery System modules. The DIP switch is used to configure the number of battery modules which are communicating to Inverter. The detailed configuration information is shown as follows: Configuration activated by inverters Matching one battery module (default) -
Page 18: Commissioning
5. Commissioning 5. Commissioning Commissioning Verify the model number of each battery module to make sure that they are all NOTE! the same model. When powering on the BMS, the system will start self-test. If the If all the battery modules are installed, follow these steps to put it in operation. buzzer bips, it means DIP configuration fault or communication failure 1. -
Page 19: Status Indicators
5. Commissioning 5. Commissioning 5.3.2 Battery Module (T45/T63) Status Indicators The LED indicators on the front panel of the BMS and battery modules are showing the operating status. 5.3.1 BMS (Master Box) S1 and S2 represent independent status indicators. The status of S1 and S2 have the same meaning for battery module in the following table. -
Page 20: Troubleshooting
6. Troubleshooting 6. Troubleshooting Troubleshooting Warning Messages Description Troubleshooting Troubleshooting Wait till the temperature of cells go Battery over BMS_TemHigh Check the indicators on the front to determine the state of the T-BAT system. A back to the normal state. temperature warning state is triggered when a condition, such as with voltage or temperature, is beyond design limitations. -
Page 21: Decommissioning
7. Decommissioning Decommissioning Dismantling the Battery Shutting down T-BAT system Disconnect the cables between BMS and Inverter Disconnect the short-circuit plug on the last battery module Disconnect the other cables. Packing Please pack the BMS and battery modules with the original packaging. If it is no longer available, you can also use an equivalent carton that meets the following requirements.
