INSTALLATION and OPERATION MANUAL
Submersible Sewage Ejector
IMPORTANT:
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program, product
changes may occur. As such Crane Pumps & Systems, Inc., reserves the right to change product
without prior written notification.
PUMPS & SYSTEMS
A Crane Co. Company
420 Third Street/P.O. Box 603
Piqua, Ohio 45356-0603
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
SERIES: SE .5 HP & 1.0HP
1750 RPM & 3450RPM
SUPERSEDED
Some parts may NOT
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
be available
Form No. 088634-Rev. D
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crane Barnes SE .5HP Series
Summary of Contents for Crane Barnes SE .5HP Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems, Inc., reserves the right to change product without prior written notification.
-
Page 2: Table Of Contents
Manual Index TABLE OF CONTENTS WARNINGS AND SAFETY PRECAUTIONS ................ 3 A. PUMP SPECIFICATIONS .....................4 B. GENERAL INFORMATION ....................5 C. INSTALLATION INSTRUCTIONS..................5 - 7 D. START-UP OPERATION ......................7 - 8 E. PREVENTATIVE MAINTENANCE..................8 F. SERVICE AND REPAIR......................8 - 11 TROUBLESHOOTING ......................12 G. -
Page 3: Safety First
Manual Index SAFETY FIRST! Please Read This Before Installing Or Operating Pump. This WARNING ! Do not pump hazardous materials information is provided for SAFETY and to PREVENT EQUIPMENT (flammable, caustic, etc.) unless the pump is PROBLEMS. To help recognize this information, observe the specifically designed and designated to handle them. -
Page 4: Pump Specifications
Manual Index SECTION: A- PUMP SPECIFICATIONS DISCHARGE: 2" (51mm) NPT, Vertical UPPER BEARING: TEMPERATURE: 104°F (40°C) Continuous. Design: Sleeve VOLUTE: Cast Iron ASTM A-48, Class 30. Lubrication: MOTOR HOUSING: Cast Iron ASTM A-48, Class 30. Load: Radial SEAL PLATE: Cast Iron ASTM A-48, Class 30. LOWER BEARING: IMPELLER: Design:... -
Page 5: General Information
Inc. representative or Barnes Pumps, Inc. Service Department Congratulations! You are the owner of one of the finest pumps ® in Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps & on the market today. Barnes Pumps are products engineered Systems Canada, in Brampton, Ontario, and manufactured of high quality components. - Page 6 Manual Index Stainless Rail Package (Not Shown)- The package system 4) Plug the level control plug into the GFI receptacle, then comes complete and ready to place into the ground as outlined plug the pump into the piggyback plug. One cycle of in the project specifications.
-
Page 7: Start-Up Operation
Manual Index MODEL VOLT NEMA FULL LOCKED CORD CORD CORD EMERSON G.E. (Nom) CODE LOAD ROTOR SIZE TYPE WINDING WINDING AMPS AMPS RESISTANCE RESISTANCE MAIN/START MAIN/START SE514L 1750 11.6 22.0 14/3 SOW-A 0.560 1.18--14.25 1.34--16.88 SE524L 1750 18.0 14/3 SOW-A 0.560 2.24--9.24 2.32--9.22... -
Page 8: Preventative Maintenance
Manual Index D-4) Start-Up Report: F-1.2) Testing Oil: Included at the end of this manual are two start-up report 1. Place pump on it’s side, remove pipe plug (21) and drain sheets. These sheets are to be completed as applicable. oil into a clean, dry container. - Page 9 Manual Index If the impeller (15) needs replacing, remove nut (16).The AIR⇒ PRESSURE GAUGE impeller is threaded onto the shaft and to remove, unscrew ASSEMBLY (See impeller holding shaft with a large screwdriver. Remove Parts List) exclusion seal (14) and replace if needed. F-2.2) Reassembly: Before installing impeller (15), inspect threads on shaft and impeller to assure that they are clean.
- Page 10 Manual Index F-3.2) Replacing Bearings: F-4.2) Replacing Shaft Seal (refer to fig. 7 & 8): When replacing bearings, be careful to not damage the rotor or When replacing the shaft seal (3), remove used rotating shaft threads. Press the old bearings off the shaft with an arbor member (3c), spring (3b), and spring retainer (3a) from motor press or gear puller.
-
Page 11: Power Cable
Manual Index MOTOR, SLEEVE & F-4.3) Replacing Exclusion Seal: BULLET ROTATING BEARING The exclusion seal (14), helps to keep debris away from the RETAINING MEMBER (3c) shaft seal where it could cause damage. The exclusion seal RING (3a) should be replaced whenever the shaft seal is replaced. To replace the exclusion seal, pull the old seal off the shaft, and slide the new seal on with the thin lip towards the motor. -
Page 12: Troubleshooting
Manual Index TROUBLESHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH "CAUSE"... -
Page 13: Replacement Parts
Manual Index SECTION: G REPLACEMENT PARTS G-1 ORDERING REPLACEMENT PARTS: When ordering replacement parts, ALWAYS furnish the following information: 1. Pump serial number and date code. (Paragraph G-4) 2. Pump model number. (Paragraph G-3) 3. Pump part number. (Paragraph G-2) 4. -
Page 14: Cross-Section (Fig. 9)
Manual Index Fig. 9... -
Page 15: Exploded View (Fig. 10)
Manual Index Fig. 10... -
Page 16: Parts List
Manual Index PARTS LIST ITEM DESCRIPTION PART No. Motor SE514L 030369 SE524L 029792 SE594L, SE544L 071354 SE554L 071354F SE1024L 029792 SE1094L, SE1044L 071354 SE1054L 071354F SE512L 068926 SE522L 068927 SE532L, SE542L 067462 SE552L 088548 SE1022L 068928 SE1032L, SE1042L 071355 SE1052L 067463F Seal Plate 093067... -
Page 17: Returned Goods Policy
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A "RETURNED GOODS AUTHORIZATION". - Page 18 No rights extended under this warranty shall be assigned to any other person, whether by operation of law or otherwise, without our prior written approval. PUMPS & SYSTEMS A Crane Co. Company 420 Third Street/P.O. Box 603 83 West Drive, Brampton...
-
Page 19: Start Up Report
This report is designed to insure the customer that customer service and a quality product are the number one priority with Crane Pumps & Systems, Inc. (CP&S). Please answer the following questions completely and as accurately as possible. Mail this form to: In U.S.A. - Page 20 Manual Index CP&S Control Panel Part No. and Brand Number of pumps operated by control panel NOTE: At no time should holes be made in top of control panel, unless proper sealing devices are utilized. Control Panel Manufactured by Others: Company Name: Model No.
-
Page 21: Warranty Registration
Complete the Warranty Registration Form and returned to Crane Pumps & Systems, Inc. Warranty Service Group IMPORTANT! If you have a claim under the provision of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor. FOLD HERE ** IMPORTANT ! ** WARRANTY REGISTRATION CUSTOMER’S NAME... - Page 22 Manual Index FOLD HERE AND TAPE, DO NOT STAPLE PLACE STAMP HERE CRANE PUMPS & SYSTEMS, INC. WARRANTY SERVICE GROUP 420 THIRD STREET P.O. BOX 603 PIQUA, OHIO 45356-0603 - U.S.A.
