Submersible Sump & Sewage Ejectors
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
BARNES
INSTALLATION MANUAL
Series: SE411HT .4Hp
1750 RPM, 60 Hz.
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Form No. 107027A-Rev. D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Barnes SE411HT and is the answer not in the manual?

Questions and answers

Summary of Contents for Crane Barnes SE411HT

  • Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
  • Page 2: Table Of Contents

    SEAL TOOL KIT (see parts list) PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc. 3/2006, 9/06 Alteration Rights Reserved...
  • Page 3: Warnings And Safety Precautions

    Crane Pumps & Systems, Inc. is not responsible for WARNING ! Do not pump hazardous materials losses, injury, or death resulting from a failure to observe (fl...
  • Page 4: Pump Specifications

    PUMP SPECIFICATIONS SERIES: DISCHARGE ......2” NPT, Female, Vertical CORD ENTRY ......15 ft. (5m) Cord with plug On 115 LIQUID TEMPERATURE ..200°F (93°C) Continuous volt and Stainless Wire Mesh VOLUTE ........Cast Iron ASTM A-48, Class 30 Strain Relief, Pressure Gromment MOTOR HOUSING ....Cast Iron ASTM A-48, Class 30 for sealing and strain relief SEAL PLATE ......Cast Iron ASTM A-48, Class 30 SPEED ........1750 RPM (nominal)
  • Page 5: General Information

    Figure 2 shows a typical installation for any submersible & Systems, Inc., Service Department in Piqua, Ohio, pump using a level control mounted to the discharge piping telephone (937) 778-8947 or Crane Pumps & Systems with a piggy-back plug. Canada, Inc., Bramton, Ontario, (905) 457-6223.
  • Page 6 C-4) Electrical Connections: WARNING ! - Pump must be used in a circuit protected by a ground fault interrupter. WARNING ! - All model pumps and control panels must be properly grounded per THE NATIONAL ELECTRIC CODE or CANADIAN ELECTRIC CODE and STATE, PROVINCE and LOCAL electric codes.
  • Page 7: Start-Up Operation

    MODEL NO VOLT/ NEMA FULL LOCKED CORD CORD CORD WINDING (Nom) START LOAD ROTOR SIZE TYPE RESISTANCE CODE AMPS AMPS inch (mm) MAIN - START SE411HT 115/1 1750 26.0 14/3 SOOW 0.560 (14.2) 1.37 - 15.2 Winding Resistance ± 5%. Pump rated for operation at ± 10% voltage at motor. SECTION: D START-UP OPERATION SECTION E: PREVENTATIVE MAINTENANCE D-1) Check Voltage and Phase:...
  • Page 8 F-1.2) Testing Oil: Pressure Gauge Assembly 10 PSI 1. Place pump on it’s side, remove pipe plug (22) and (See Parts List) drain oil into a clean, dry container. 2. Check oil for contamination using an oil tester with a Remove Pipe range to 30 kilovolts breakdown.
  • Page 9 FIGURE 6 FIGURE 5 Loosen motor screws and pull motor (1) straight up and off seal plate (2). Inspect all parts for signs of wear and check motor resistance values. Check capacitor (6) with an Ohm F-4) Shaft Seal Service meter by grounding the capacitor by placing a screwdriver F-4.1) Dissassembly and Inspection: across both terminals and then removing the screwdriver.
  • Page 10: Replacement Parts

    Motor, Sleeve & 1. Pump serial number and date code. (Paragraph G-4) 2. Pump model number. (Paragraph G-3) Bearing Seal Pusher 3. Pump part number. (Paragraph G-2) Spring 4. Part description. 5. Item part number. 6. Quantity required. 7. Shipping instructions. 8.
  • Page 11: Trouble Shooting

    TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”...
  • Page 12: Cross-Section (Fig. 10)

    FIGURE 10...
  • Page 13: Parts List

    PARTS KITS Pressure Gauge Kit..P/N: 085343 PARTS LIST ITEM PART No. DESCRIPTION 085584 Motor & Sleeve 093063 Seal Plate Cast Iron 068988 Shaft Seal, (Standard) Carbon/Ceramic/Buna-N 068988SB Tungsten/Tungsten/Buna-N 068988SD Silicon/Silicon/Buna-N 068988SF Carbon/Ceramic/Viton 068988SH Tungsten/Tungsten/Viton 068988SK Silicon/Silicon/Viton 068988SM Silicon/Tungsten/Buna-N 068988SN Carbon/Ni-Resist/Buna-N 017414 Bearing 017415...
  • Page 14 Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state.
  • Page 15: Return Goods Policy

    Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
