Aries P205041 Installation Manual

INSTALLATION MANUAL
Parts List
1 Driver / left side bar
1 Passenger / right side bar
1 Driver / left
front mounting bracket
1 Passenger / right
front mounting bracket
2 Mounting bracket, rear
2 Bolt plate, M8
5 Hex bolt, M8
7 Flat washer, M8
7 Lock washer, M8
2 Hex nut, M8
2 Plastic retainer, M8
4 Hex bolt, M10
4 Flat washer, M10
4 Lock washer, M10
4 Bolt / nut plate, M12 stud
4 Hex bolt, M12
4 Flat washer, M12 x 32mm
4 Flat washer, M12
8 Lock washer, M12
4 Hex nut, M12
4 Plastic retainer, M12
Tools Required
Torque wrench Socket, 13mm
Utility knife Socket, 16mm
Level Socket, 18mm
Torque Specifications
M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.
Level of Difficulty
Easy
Product Image
Brackets
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
For black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
PAGE 1 • P205041-INS-RA • 800.798.0813 • NEED ASSISTANCE?
P205041
Scan
for helpful
install tips
Front
• ARIESAUTOMOTIVE.COM
Rear
