Aries S223006 Installation Manual

INSTALLATION MANUAL
Parts List
1 Driver / left side bar
1 Passenger / right side bar
2 Driver / left side
mounting bracket
2 Passenger / right side
mounting bracket
16 Hex bolt, M8 x 35mm
24 Flat washer, M8
16 Lock washer, M8
8 Hex nut, M8
8 Clip nut, M8
8 Hex bolt, M10 x 30mm
8 Flat washer, M10
8 Lock washer, M10
Tools Required
Ratchet Socket, 13mm
Wrench, 13mm Socket, 17mm
Torque wrench Level
Torque Specifications
M6 bolt 3 ft.-lbs.
M8 bolt 7 ft.-lbs.
M10 bolt 16 ft.-lbs.
M12 bolt 28 ft.-lbs.
1/4" bolt 3 ft.-lbs.
5/16" bolt 7 ft.-lbs.
3/8" bolt 16 ft.-lbs.
7/16" bolt 20 ft.-lbs.
1/2" bolt 28 ft.-lbs.
Level of Difficulty
Easy
Product Image
Notes and Maintenance
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
To protect the product, wax after installing. Regular waxing is recommended to
add a protective layer over the finish. Do not use any type of polish or wax that may
contain abrasives that could damage the finish.
For gloss black finishes, mild soap may be used to clean the product.
Refer to the table to the left when securing hardware during the
installation process to help prevent damage to the product or vehicle.
PAGE 1 • S223006-INS-RB • 877.287.8634 • NEED ASSISTANCE?
S223006
Scan
for helpful
install tips
Front
• ARIESAUTOMOTIVE.COM
Rear
