Summary of Contents for Nibe COMPACT 100
- Page 1 User and Installer manual Water heater NIBE COMPACT IHB EN 2517-1 M13734...
- Page 3 Safety information 2 For the User Regular checks Emptying Disturbances in comfort 3 For the Installer General Transport Assembly Handling panels Component positions Pipe connections Filling and venting Electrical connection Service Technical data Contact information NIBE COMPACT Table of Contents...
- Page 4 Always give the product's serial number when re- porting a fault. This is an original manual. It may not be translated without the approval of NIBE. RECOVERY Rights to make any design or technical Leave the disposal of the packaging to the installer modifications are reserved.
- Page 5 5. The sacrificial anode (FR2) is unscrewed using a 27 mm, or 24 mm, socket wrench. Only replacement parts supplied by NIBE may be used. For replacement of anodes in confined spaces, a chain anode is available that only requires approx. 185 mm space above the water heater.
- Page 6 20-55 mm 30 - 50 mm The area where the Compact is located must be frost-proof and equipped with a floor drain. 0 mm Chapter 3 | For the Installer NIBE COMPACT...
- Page 7 Type plate (on the base frame, behind the front cover) QM35 Shut-off valve cold water Serial number plate (on the base frame, behind the front cover) Designations in component locations according to standard IEC 81346-1 and 81346-2. NIBE COMPACT Chapter 3 | For the Installer...
- Page 8 3. Open a hot water tap in the house. 4. When the water that comes out of the hot water tap is no longer mixed with air, the water heater is full and the tap can be closed. QM35 Chapter 3 | For the Installer NIBE COMPACT...
- Page 9 ELECTRICAL CIRCUIT DIAGRAM 3 phase 3/6 kW 1 phase 1 kW/2 phase 3 kW NIBE COMPACT Chapter 3 | For the Installer...
- Page 10 1-phase/2-phase installation 3-phase installation Reconnecting sensors Reconnection of sensors for thermostat and temperature limiter. Check that the sensors are at the bottom of the submerged tube. Temperature limiter Thermostat 1-phase/2-phase installation 3-phase/ installation Chapter 3 | For the Installer NIBE COMPACT...
- Page 11 *The lower section of the side panels on Compact 150, 200 and 300 can be re- moved during installation, which facilitates access from the sides. The side panels can also be reinstalled in confined spaces. Compact 100 has no lower side panels. NOTE! Pipes must not be run in the area indicated by dots!
- Page 12 6 kW Part no. 018 288 Steatite immersion heater The accessory is used with calcareous water. Steatite copper Steatite enamel 2.08 kW 2.08 kW Part no. 418 565 Part no. 060 074 Chapter 3 | For the Installer NIBE COMPACT...
- Page 15 Tel: +48 (0)85 66 28 490 Hannabadsvägen 5, 285 21 Markaryd Tel. +41 (0)58 252 21 00 biawar.com.pl Tel: +46 (0)433-27 30 00 info@nibe.ch info@nibe.se nibe.ch nibe.se For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
- Page 16 WS version: a1241 (working edition) Publish date: 2025-04-23 15:51 This is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this publication.
