Elecom V custom M-VM510 User Manual page 6

⑥ and ⑦ Additional buttons
Any function can be assigned to these buttons.
* At the time of purchase, nothing is set.
⑧ DPI stage switch button
Count number (pointer movement speed) can be changed between 5 levels.
●DPI1: 400 dpi
●DPI2: 800 dpi (default)
●DPI3: 1600 dpi
●DPI4: 2400 dpi
●DPI5: 3200 dpi
The count number for each stage can be adjusted. To adjust it, please install the EG Tool from our website.
For more information, see "Setting up the ELECOM GAMING Tool (EG Tool)" -
You can assign the function for all the buttons from ① to ⑧. To configure the button assignment, please install the EG
Tool from our website.
For more information, see "Setting up the ELECOM GAMING Tool (EG Tool)" -
⑨ Notification LED
When the power is turned ON, the LED will light up for 3 seconds in the color corresponding to the current DPI stage. (The
default is ● DPI2: purple.)
When the remaining charge is low, the LED will blink quickly in the color corresponding to the current DPI stage. (The
default is ● DPI2: purple.)
During charging, the LED will blink continuously in the color corresponding to the current DPI stage. (The default is
purple.)
When the device is fully charged, the LED will light up in the color corresponding to the current DPI stage. (The default is
DPI2: purple.)
When the DPI stage switching button is pressed, the LED will light up for 3 seconds in the color corresponding to the
current DPI stage.
●DPI1: Red
●DPI2: Purple
●DPI3: Indigo
●DPI4: Green
●DPI5: Yellow
To adjust the DPI stage, please install the EG Tool from our website.
For more information, see "Setting up the ELECOM GAMING Tool (EG Tool)" -
⑩ USB Type-C port
Port to connect the supplied charging cable.
⑪ Optical sensor
This sensor will detect mouse movements when you move the mouse.
* The sensor uses invisible (transparent) light. Please note that direct viewing of the light source may hurt the eyes.
⑫ Power switch
When using it with wireless connection, turn the power on / off on the mouse body.
⑬ Receiver unit storage part
The receiver unit can be stowed here when it is not being used with the mouse or it is being wirelessly connected.
"Setting the DPI Stage".
"Setting the function of the
"Setting the DPI Stage".
buttons".
● DPI2:
●
