- Page 1 KAVA 9686 ™ DRESSER USER MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 2 Congratulations on the purchase of your KAVA dresser from BDI. Your dresser has been designed to provide a lifetime of enjoyment. This manual will provide assembly instructions and other helpful information to ensure you get the most out of your product.
- Page 3 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface, such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. For all other concerns, please contact your BDI retailer.
- Page 4 HARDWARE AND COMPONENTS HARDWARE AND COMPONENTS Cabinet (C1) QTY: 1 Drawer Pull (C2) QTY: 6 Drawer Tray (C3) QTY: 1 KLEET (C4) QTY: 2 Anchor Strap (C5) QTY: 1 4 | BDIUSA.COM KAVA 9686...
- Page 5 STEP 1. ATTACH DRAWER PULLS ASSEMBLY After unpacking the Cabinet (C1), open one NOT INCLUDED row of drawers at a time, cut the ribbon off the PHILLIPS SCREWDRIVER drawer, and install the 6 Drawer Pulls (C2) using 12 Screws (H1). Tighten with Phillips Head Screwdriver (not included).
- Page 6 4 Wood Screws (H2). Tighten with Phillips Head Screwdriver. Carefully move your Dresser close to the wall and attach the loose end of the Anchor Strap (C5) to the back edge of the top panel with the Thumb Screw (H3). 6 | BDIUSA.COM KAVA 9686...
- Page 7 LEVEL DRESSER FINE TUNING Once the unit is completely assembled and in its final position, adjust the levelers using the LEVELER WRENCH – T1 Leveler Wrench (T1). Using a level (not provided), level your cabinet first side to side, and then front to back. If your cabinet is on carpeting, check your front to back level after loading the cabinet and opening the heaviest drawers.
- Page 8 Snapper Wing is in the forward position, no other drawers can be opened. NOTE: There is one inactive Snapper Wing, small circle above, and it must always remain in the vertical position. 8 | BDIUSA.COM KAVA 9686...
- Page 9 INTERLOCK SYSTEM HOW TO REMOVE THE DRAWERS 3. Open the next drawer, release it from the 2. Use your hand to push back the activated slides, and carefully lift it up and off of the wing of the Snapper to return it to the slides.
- Page 10 1. Use your hand to pull forward the 3. Use your hand to pull Wing that corresponds with the forward the Wing that drawer being installed. corresponds with the drawer being installed. 10 | BDIUSA.COM KAVA 9686...
- Page 11 While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please avoid positioning your BDI cabinet in any area with ample direct sunlight.
- Page 12 Select chairs carry coverage for five (5) years from the date of the product delivery, based on an 8-hour daily use pattern. BDI reserves the right to refine or update its warranty from time to time. See the complete and latest warranty document at www.bdiusa.com/warranty.
