Coyote Stainless Steel Pellet Grill
C2P28
Certified to UL SUBJECT 2728A
Certified to ULC/ORD-C2728
4006980
IMPORTANT: Read all instructions and warnings before using this product! This product, as with any
similar outdoor grill, will involve risks from hot temperatures and exposure to smoke and fumes.
Please exercise caution and common sense.
To Installer or Person Assembling Grill: Leave this manual with the grill for future reference.
To Consumer: Keep this manual for future reference as it contains important Warnings and
Instructions.
COYOTE OUTDOOR LIVING, INC.
www.CoyoteOutdoor.com
Use and Care Manual
C2P36
PUT SERIES NO. LABEL HERE
C2P28-FS
C2P36-FS
FOR OUTDOOR USE ONLY
Advertisement
Table of Contents
Related Manuals for Coyote C2P36
Summary of Contents for Coyote C2P36
- Page 1 Coyote Stainless Steel Pellet Grill Use and Care Manual C2P28 C2P28-FS C2P36-FS C2P36 Certified to UL SUBJECT 2728A Certified to ULC/ORD-C2728 FOR OUTDOOR USE ONLY 4006980 PUT SERIES NO. LABEL HERE IMPORTANT: Read all instructions and warnings before using this product! This product, as with any similar outdoor grill, will involve risks from hot temperatures and exposure to smoke and fumes.
- Page 2 Welcome and Congratulations! Congratulations on your purchase of a new Coyote Outdoor Living Pellet Grill. We are proud of our product, and our Customer Service Team will provide you with the best service possible. Your satisfaction is our #1 priority.
-
Page 3: Table Of Contents
Contents Safety Instructions ........................4 Limited Warranty ........................6 Models ............................. 7 Installation ..........................8 Electrical Requirements ......................11 Components ........................... 12 Storing and Loading Pellets ..................... 15 Quick Start Guide ........................17 Digital Display Instructions ...................... 18 Cooking on the Grill ........................ 24 Care and Maintenance ...................... -
Page 4: Safety Instructions
DO NOT store wood pellets in a confined area. General Safety Instructions 1. For Outdoor Use Only. Please note that Coyote grills are designed for residential use only and are not suitable for commercial purposes. The original purchaser (homeowner) should only use and maintain the grill. - Page 5 11. Burn Hazard: When using the grill, do not touch the grill rack, sear grate, or immediate surroundings, as these areas become extremely hot and can cause burns. Use the grate removal tool or hand protection. Only open the hood slowly to allow heat and steam to escape.
-
Page 6: Limited Warranty
Coyote Outdoor Living, Inc. under this warranty is limited to repair or replacement. This limited warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use of an improper fuel supply, use contrary to operating instructions, or alteration by any person other than a factory service center. -
Page 7: Models
Whether you need a slimmer 28" grill model for your patio or a larger 36" grill model that can entertain and bring style to any size party, Coyote has the grill for you! We also offer cart versions. Product Size... -
Page 8: Cutout Dimensions
If a professional installer or technician installs the grill, be sure that they show you where your electrical supply shut-off is located. Notice: We strongly recommend professional installation of your Coyote grill. These instructions provide the measurements necessary to construct a masonry structure to house your outdoor pellet grill. - Page 9 • If you plan to install your Coyote Outdoor Living Pellet Grill on an island, ensuring that the grill body and the island have proper ventilation is crucial. The island must have a minimum of 2 vents, but preferably 4, with each vent being at least 20 square inches and having access to fresh air from outside.
- Page 10 Coyote insulated jacket. The insulated jacket will act as a barrier to protect your grill island from the heat and fire of your Coyote grill. If an insulated jacket is not used in a combustible material island, the warranty on the Coyote grill will be voided immediately, and safety cannot be ensured.
-
Page 11: Electrical Requirements
Electrical equipment provided with the outdoor cooking appliance shall follow these guidelines: 1. Do not use the Coyote Outdoor Living Pellet Grill for purposes other than intended. 2. Users should never submerge the cord or plug to avoid electric shock. -
Page 12: Components
Components • ALWAYS ensure the area around the grill is clear of flammable substances such as gasoline, yard debris, wood, etc. • ALWAYS ensure there is no airflow blockage through the vent space below the unit’s face. General Rules NEVER leave the grill unattended while cooking! •... - Page 13 Igniter • Igniter inside tube shown. • Two fans blow heated air through the igniter tube to ignite the pellets in the burner pot. Burner Pot • Burner pot removed from the grill. • Always ensure the burner pot is clean and empty before each cooking session. Burner Pot Installed •...
-
Page 14: Heat Shield
Heat Shield • Heat shield removed from the grill to show the opening where the smoke/grill or sear grate is inserted. • The heat shield is designed for heat to go around for indirect cooking. • Do not allow grease to build up on the heat shield. You can use a small scraper to clean. Smoke/Grill Grate •... -
Page 15: Storing And Loading Pellets
3-in-1 Versa-Rack Single Rack Installed Double Rack Installed Versa-Rack Setup includes two different sets of brackets • First set includes shorter brackets and one rack. • The second set includes longer brackets and two additional racks. • To remove the brackets, lift from the front and slide forward. •... - Page 16 • Mesquite: Mesquite wood pellets have a strong, smoky flavor that pairs well with beef, lamb, and seafood. • Oak: Oak wood pellets have a mild, smoky flavor that pairs well with chicken, pork, beef, and lamb. • Pecan: Pecan wood pellets have a mild, nutty flavor that pairs well with chicken, pork, and beef.
-
Page 17: Quick Start Guide
Quick Start Guide Always ensure the burner pot is clear of pellets before each use and you are loading fresh pellets into the hopper. Install the burner pot under the lip of the chute, as shown on page 15 of this manual. -
Page 18: Digital Display Instructions
Digital Display Instructions The Coyote Outdoor Living Pellet grill uses an electric auger to feed wood pellets from the hopper into the burner pot, where a heating element and dual fans ignite them. The resulting smoke and heat are circulated throughout the grill to cook the food, giving it a unique smoky flavor. - Page 19 Grill Modes The Coyote Outdoor Living Pellet Grill has three different grilling modes depending on the type of food you will be cooking Smoke Mode, Grill Mode, and Sear Mode. Grill and Smoke modes change when setting the target temperatures. The grill will automatically feed pellets using the smart drop technology to maintain your target temperature.
- Page 20 2. Press the power button on the left side of the control panel to turn the grill on. The screen will light up, and the Coyote Logo will appear. 3. The grill will go into Startup mode. The display is locked by default. To unlock the display, press the red lock button for 3 seconds.
-
Page 21: Using The Timer
Shutdown Once you have finished cooking your food, it is time to shut down your Coyote Outdoor Living Pellet Grill. 1. First, press the red stop icon. This will stop the auger and will increase the fan speed. A dialog box on the screen indicates that the grill has gone into the Cooldown mode. - Page 22 Halogen Lights The Coyote Outdoor Living Pellet Grill comes equipped with two interior halogen lights. To turn the lights ON/OFF, press the lights button on the right side of the display. The button will be green while the lights are on. The lights turn off automatically on a 10-minute timer. The time can be adjusted in the setting menu.
- Page 23 Settings Menu There is a setting button on the right side of your grill display. To access the settings menu, you must enter a system password. The default password is 1234. Once the menu is unlocked, several grill settings that can be adjusted. 1.
-
Page 24: Cooking On The Grill
Cooking on the Grill Preparing Food for the Grill The table below shows general guidelines for using your new Coyote Outdoor Living Pellet Grill. We recommend experimenting with times and temperatures to get the flavor you desire. You can speed up the cooking process at a higher temperature, but this could result in a less tender product. -
Page 25: Grilling Tips
Grilling Tips • If you pre-cook meat or poultry, do so immediately before grilling. • Refrigerate leftovers within 2 hours of taking food off the grill. • Use a meat thermometer to be sure food has reached a safe internal temperature. •... -
Page 26: Care And Maintenance
Care and Maintenance Always wait until the grill has cooled down and turn off the power before cleaning. Drip Trays To prevent the accumulation of grease and debris, it is essential to regularly clean the drip trays beneath the grill. NOTE: Allow the drip trays to cool before attempting to clean. - Page 27 Coyote Care Recommendations 1. Purchase a Coyote grill cover for your pellet grill. This will ensure that your cover is a correct fit and breathable while providing the protection needed to keep contaminants off the surface.
- Page 28 (as mentioned before) and a dry towel for a final wipe-down. Follow all directions on any third-party stainless steel scratch kits. Coyote does not ensure or guarantee such products' performance or results. Cleaning of the Grill Housing 1.
-
Page 29: General Troubleshooting
Troubleshooting the Grill General Troubleshooting Pellet Jams It is common for all pellet grills to run into pellet jams. Pellet jams occur when the wood pellets get stuck in the auger or chute and do not fall into the burner pot. Wet pellets or incorrect burner pot placement are typical causes of pellet jams. - Page 30 Pellet Chute Auger Cover Jammed Auger Clear Auger ** Note: If you continue to have multiple pellet jams after clearing, please contact customer support. ** Burner Pot Placement Improper placement of the burner pot can cause ignition issues and pellet jams, preventing the grill from working properly.
- Page 31 Adjust the low temp alarm in the setting menu. (Default is 5 Grill Shuts Off minutes) • Remove all contents from the grill and check the burner pot placement. • Check for a pellet jam. • If the problem still exists, contact our Coyote Customer Support at 855-520-1559.
-
Page 32: Parts Listing
Parts Listing Exploded Parts List... - Page 33 39 Circuit Board Box – C2P36 1 C2P36039 1 C2P28040 1 C2P36040 40 Drip Tray Drawer Left – C2P28 40 Drip Tray Drawer Left – C2P36 41 Drip Tray Drawer Right – C2P28 1 C2P28041 41 Drip Tray Drawer Right – C2P36 1 C2P36041...
-
Page 34: Wiring Diagram
Wiring Diagram...
