  • Page 1 Coyote Stainless Steel Gas Grill Use & Care Manual For Liquid Propane and Natural Gas Models Built-in Models Coyote 2-Burner Grill (CC2LP/CC2NG) Coyote 3-Burner Grill (CC3LP/CC3NG) Coyote 36"Grill (CS36LP/CS36NG) Coyote 42" Grill (CS42LP/CS42NG) Coyote 36" Grill (CSL36LP/CSL36NG) Coyote 42" Grill (CSL42LP/CSL42NG)
  • Page 2 Welcome & Congratulations Congratulations on your purchase of a new grill! We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual carefully to understand all the instructions about how to install, operate and maintain for optimum performance and longevity.

  • Page 3: Table Of Contents

    Table of Contents Safety Instructions…..... 2 WARNING • Grill Models........4 Locating the Grill ......5 IF YOU SMELL GAS: Gas Requirements ......7 1. Shut off gas to the appliance. Using Your Burners & Grilling……13 2. Extinguish any open flame. Lighting Your Grill…………………18 3.

  • Page 4: Safety Instructions

    Safety Instructions WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. General Safety Instructions For Household Outdoor Use Only – DO NOT use indoors or in any type of enclosed area such as a garage, shed or breezeway.
  • Page 5 19. DO NOT use while under the influence of drugs or alcohol. 20. DO NOT store a spare gas cylinder under or near your grill. 21. DO NOT grill without the drip tray in place, hot grease could leak downward and produce a fire or an explosion.

  • Page 6: Grill Models

    Whether you are in need of a slimmer 2 Burner grill for your patio, or are in need of a larger 42” grill, that can entertain and bring style to any size party, Coyote has the grill for you! Coyote 2-Burner Grill (CC2LP/CC2NG) Coyote 3-Burner Grill (CC3LP/CC3NG) Coyote 36”...

  • Page 7: Locating The Grill

    Ventilation for a gas grill is absolutely mandatory to ensure that your grill performs as intended and • to ensure the safety of you and your family. The vents that are required to honor a Coyote warranty, not only ensure that any heat that is trapped inside your grill from environmental factors (such as wind) escape but they also allow any gas that has leaked from a tank or connection, to escape before a buildup of such gas can occur and possibly ignite.
  • Page 8 Nature and the effects she can have on your outdoor cooking equipment. Coyote Wind Guards: If you do run into a situation where you will have wind coming into the back of the unit, Coyote does sell "Wind Guards" that help keep your grilll from overheating due to no exhaust occuring out the back of the grill.

  • Page 9: Gas Requirements

    Cut out Dimensions Figure A WIDTH DEPTH HEIGHT 2 Burner 31” (787mm) 20 ½” (521mm) 11” (279mm) 3 Burner 32 ½” (825mm) 20 ½” (521mm) 11” (279mm) 20 ½” (521mm) 4 Burner 39 ½” (1003mm) 11” (279mm) 5 Burner 20 ½” (521mm) 25”...
  • Page 10 All pipe sealants must be an approved type and resistant to the actions of LP gas. Never use • pipe sealant on flare fittings. The installation of this appliance must conform with local codes or, in the absence of local •...
  • Page 11 prevention device. Read labels on the L.P. Gas Supply Cylinder. New cylinders are always shipped empty for safety. Allow only qualified L.P. gas dealers to fill or repair your L.P. gas supply cylinder. Inform the gas dealer if it is a new or used cylinder to be filled. After filling, have the gas dealer check for leaks and to see that the relief valve remains free to function.
  • Page 12 Before Testing DO NOT smoke while leak testing. Extinguish all open flames. Never leak test with an open flame. Mix a solution of equal parts mild detergent or liquid soap and water. Leak Testing Valves, Hose and Regulator 1. Turn all grill control knobs to OFF. 2.

  • Page 13: Lp Tank Filling

    LP grill from Coyote will meet your needs, regardless of the size. Any appliance can be installed if installed properly! That is the Coyote way!
  • Page 14 Gas Conversions – Natural Gas and Propane Coyote grills are able to be converted but you must obtain the correct conversion kit and we alwayrs recommend that any gas appliance conversion should always be performed by a Licensed Plumber or a...

  • Page 15: Using Your Burners & Grilling

    Coyote’s Customer Service Department. Any other kit or orifices used that are not of Coyote brand, will automatically void any warranty on the unit. Furthermore, it is important to understand that where ever there is a burner, there is an orifice that will need to be changed (do not forget the rotisserie or sear burner).
  • Page 16 heat and fuel consumption. An example being: Cooking on low will give you longer use out of a 20lb LP tank than will cooking on high every single time. Furthermore, the way to ignite the burners is through the valves, so please understand the importance of this piece and the position/care taken to the knobs.
  • Page 17 Now, if you are looking for an experience that will allow you to have a juicy bird, straight from the rotisserie of your grill, then Rotisserie Cooking is going to be your choice! Coyote grills utilize the same ceramic burner technology in their sear burner, as their rotisserie burner, along with a motor and spit that will hold and rotate up to 20lbs of food.
  • Page 18 Attach Motor Bracket Assembly to the side of the barbecue frame (can be mounted on either left or the right side of the frame) using two screws and two nuts. Insert Rotisserie Motor onto Motor Bracket Assembly. Assemble Key Washer, Counter-balance and handle to Spit Rod. Slide Shaft Collar with long end towards handle.
  • Page 19 Instruction for Connecting the Transformer 1. Transformer for Interior Lights - (only on CC3 and CS models) Your transformer will connect on the left side of your grill (looking at it from the front) and operates the lights inside your grill. Follow the pictures and insert the white male plug into the white female socket, on the left side of your grill and then plug the transformer into a standard 110v outlet.

  • Page 20: Lighting Your Grill

    Take Down the Knob Bezel The LED Plastic Bezel Pull Out the Wires Disconnect the Wire and Change New LEDs Do the opposite to assemble the LEDs. WARNING: These two transformer should be kept away from the heat of the BBQ. Lighting the Grill DANGER Failure to open the lid while igniting the barbecue’s burners, or not waiting 5 minutes to allow...

  • Page 21: Lighting Instructions

    GENERAL RULES Do not leave the grill unattended while cooking! Make sure the grill has been leak tested and is properly located. Check the end of each burner tube is properly located over each valve orifice. Light the grill burners using the instructions provided in this manual. Adjust heat settings to your desired cooking temperature.

  • Page 22: Operation And Features

    Main Burner Lighting Infrared Back Burner Lighting 1. Push and hold the igniter, then push in Push and hold the igniter, then turn the and turn the last Right knob to HIGH back burner knob to HIGH position 3-5 position 3-5 seconds to light burner. seconds to light the back burner.

  • Page 23: Care & Maintenance

    cooked food. Always wash all vegetables, seafood and poultry before cooking. Always leave uncooked foods in the refrigerator until you are ready to start cooking. Always marinate meat in the refrigerator. Dispose of the excess marinade, and never reuse it. Grilling Tips: If you pre-cook meat or poultry, do so immediately before grilling.

  • Page 24: Cooking Grates

    tray is not cleaned after use and the grill is left uncovered, the drip tray will fill with water causing grease and water to spill into the grill cart. We recommend cleaning and storing the drip tray after every use. COOKING GRATES The cooking grates can be cleaned immediately after cooking is completed and after turning off the grill.
  • Page 25 steel that is exposed to the environment will require attention and care throughout its life to ensure that it keeps its shine and structural integrity. Cleaning the Stainless Steel and Polishing 1. To clean the stainless steel you will want to wash off all dirt and debris from the steel with warm water.
  • Page 26 Ways to Avoid Rust on your Grill: 1) Always purchase a Coyote Grill cover for your unit. This will ensure that your cover is correct fit and breathable, while providing the protection needed to keep all other contaminants off of the surface.
  • Page 27 Check electrode. Reinstall flavorizers, cooking grids, and warming rack. Reconnect to gas source and observe burner flame for correct operation. IMPORTANT: You should NOT line the bottom of the grill housing with aluminum foil, sand or any other grease absorbent substance. Grease will not be able to drip into the drip tray and a grease fire may occur.

  • Page 28: Troubleshooting Your Grill

    Troubleshooting Your Grill GENERAL TROUBLE SHOOTING You should inspect the burners at least once a year or immediately if any of the following conditions occur: • The smell of gas. • Flames appearing mostly yellow. (Some yellow at the tips is OK) •...
  • Page 29 Note: You will need to remove your cooking grates and flavorizers to see the electrodes. The electrodes should have a 1/8” to ¼” gap between the electrode and contact point. • Check your igniter battery and replace if needed. • Check for loose wire connections to the igniter or electrodes.

  • Page 30: Limited Warranty

    Limited Warranty LIMITED WARRANTY Coyote Outdoor warrants to the original purchaser at the original site of delivery with proof of purchase of each Outdoor Gas grill/Side burner that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. This warranty excludes grills used in rental and commercial applications.
  • Page 31 does not cover scratches, dents, corrosion or discoloration caused by weather, heat, abrasive and chemical cleaners, pool or spa chemicals, and/or any tools used in the assembly or installation of this unit. This warranty does not cover paint loss, surface rust, corrosion or stainless steel discoloration which is considered normal wear and tear.

  • Page 32: Parts Listings

    Parts List COYOTE 2B NG/LP...
  • Page 33 COYOTE 2B NG/LP PARTS LISTING Name Description2 Part No. Hood Hood -2B C2B00005 Thermometer Thermometer C0000022 Handle Fixing Handle Fixing C0000007 Hood Handle Hood Handle -2B C2B00006 Rubber Stopper on Hood Rubber Stopper on Hood C0000032 Lower Hood Lower Hood-2B...
  • Page 34 COYOTE 3B NG/LP...
  • Page 35 COYOTE 3B NG/LP PARTS LISTING Name Part No. Hood Hood -3B C3B00005 Thermometer Thermometer C0000022 Handle Fixing Handle Fixing C0000007 Hood Handle Hood Handle -3B C3B00006 Rubber Stopper on Hood Rubber Stopper on Hood C0000032 Light Light Bulb C0000014 Warming Rack Bracket...
  • Page 36 COYOTE 4B w/ Sear Burner & IR NG/LP...
  • Page 37 COYOTE 4B w/ Sear Burner & IR NG/LP PARTS LISTING Name Part No. Hood Hood -36 C3600005 Thermometer Thermometer C0000022 Handle Fixing Handle Fixing C0000007 Hood Handle Hood Handle-36 C3600006 Rubber Stopper on Hood Rubber Stopper on Hood C0000032 Warming Rack Bracket...
  • Page 38 COYOTE 5B w/ Sear Burner & IR NG/LP...
  • Page 39 COYOTE 5B w/ Sear Burner & IR NG/LP PARTS LISTING Name Part No. Hood Hood - 42 C4200005 Thermometer Thermometer C0000022 Handle Fixing Handle Fixing C0000007 Hood Handle Hood Handle - 42 C4200006 Rubber Stopper on Hood Rubber Stopper on Hood...
