Coyote Stainless Steel Pellet Grill
C2P28
Certified to UL SUBJECT 2728A
Certified to ULC/ORD-C2728
4006980
IMPORTANT: Read all instructions and warnings before using this product! This product, as with any
similar outdoor grill, will involve risks from hot temperatures and exposure to smoke and fumes. Please
exercise caution and common sense.
To Installer or Person Assembling Grill: Leave this manual with the grill for future reference.
To Consumer: Keep this manual for future reference as it contains important Warnings and
Instructions.
COYOTE OUTDOOR LIVING, INC.
2615 E Beltline Rd. Carrollton, TX, 75006
Use and Care Manual
C2P28-FS
C2P36
FOR OUTDOOR USE ONLY
PUT SERIES NO. LABEL HERE
0
C2P36-FS
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Coyote C2P28
Summary of Contents for Coyote C2P28
- Page 1 Coyote Stainless Steel Pellet Grill Use and Care Manual C2P28-FS C2P36-FS C2P28 C2P36 Certified to UL SUBJECT 2728A Certified to ULC/ORD-C2728 FOR OUTDOOR USE ONLY 4006980 PUT SERIES NO. LABEL HERE IMPORTANT: Read all instructions and warnings before using this product! This product, as with any similar outdoor grill, will involve risks from hot temperatures and exposure to smoke and fumes.
- Page 2 1. Download a replacement at www.CoyoteOutdoor.com 2. Contact Customer Support at 855-520-1559 for assistance. Thank you for choosing Coyote Outdoor Living. We are confident you will enjoy cooking with your new pellet grill for years! Welcome to the Coyote family!
-
Page 3: Table Of Contents
Contents Safety Instructions ..........................3 Limited Warranty ..........................5 Models ............................... 7 Installation ............................8 Electrical Requirements ........................12 Components ............................. 13 Storing and Loading Pellets ......................16 Quick Start Guide ..........................18 Digital Display Instructions....................... 19 Cooking on the Grill ......................... 24 Care and Maintenance ........................ -
Page 4: Safety Instructions
DO NOT store wood pellets in a confined area. General Safety Instructions for Coyote Grills Intended Use Coyote grills are designed exclusively for outdoor use and must not be used indoors or in • enclosed garages, sheds, or breezeways. - Page 5 Grease Fires: Never attempt to extinguish a grease fire with water. • Use an ABC fire extinguisher to put out flames. • Handling Grease: Allow grease to cool before handling or disposing. • Regularly clean the drip tray to prevent grease buildup. •...
-
Page 6: Limited Warranty
Electric/Plastic Components Coyote's Obligations Coyote Outdoor Living, Inc. will repair or replace defective components at its discretion during the warranty period. Replacement or repair is the exclusive remedy under this warranty. Liability under this warranty is limited to the cost of the replacement part or repair. Labor and labor-related charges are not covered, and customers are responsible for shipping and handling fees for replacement parts. - Page 7 Coyote Outdoor may require defective parts to be returned for examination. Customers are responsible for prepaying shipping charges. If the part is deemed defective, Coyote Outdoor will approve the claim and issue replacement parts at no charge. Shipping and handling costs for replacement parts remain the customer's responsibility.
-
Page 8: Models
Whether you need a slimmer 28" grill model for your patio or a larger 36" grill model that can entertain and bring style to any size party, Coyote has the grill for you! We also offer cart versions. Product Size... -
Page 9: Installation
If a professional installer or technician installs the grill, be sure that they show you where your • electrical supply shut-off is located. Notice: We strongly recommend the professional installation of your Coyote grill. These instructions provide the measurements necessary to construct a masonry structure to house your outdoor pellet grill. -
Page 10: Cutout Dimensions
Qty 1 Ventilation Requirements for Proper Operation of Your Coyote Pellet Grill Ensuring proper ventilation is essential for your Coyote Pellet Grill's safe and efficient operation. Poor ventilation can lead to performance issues, pose safety hazards, and void the manufacturer's warranty. -
Page 11: Combustible Materials
3. Insulated Jackets If the grill is installed within 12 inches of combustible material, use a Coyote insulated jacket to protect the grill island from heat. Failure to use an insulated jacket will void the warranty and compromise safety. -
Page 12: High Elevation Installation
Open Island (Note: Island Ventilation is not shown in photos.) High Elevation Installation Optimal Performance: Coyote grills operate efficiently at altitudes of 0–2000 feet above sea • level. Moderate Elevations: Performance changes are minimal at 2000–4000 feet, but cooking times •... -
Page 13: Electrical Requirements
IMPORTANT: Electrical supply cords should be kept away from any heated surfaces. Electrical Grounding Instructions To ensure your safety, the Coyote outdoor cooking appliance has a three-prong (grounding) plug to protect against electrical shock hazards. Always plug it into a properly grounded three-prong outlet. -
Page 14: Components
Components • ALWAYS ensure the area around the grill is clear of flammable substances such as gasoline, yard debris, wood, etc. • ALWAYS ensure no airflow blockage through the vent space below the unit’s face. General Rules NEVER leave the grill unattended while cooking! •... - Page 15 Burner Pot The burner pot, when removed from the grill, is a critical area for maintenance. • Before each cooking session, ensure the burner pot is clean and debris-free to maintain • consistent performance and prevent issues during operation. Burner Pot Installed Once installed, the burner pot sits directly above the heating element, ready to receive pellets.
- Page 16 Smoke/Grill Grate Lift Tool Smoke/Grill Grate Removal Tool with Bottle Opener • The pellet grill includes a lift tool to remove the smoke/grill grate. • The sear grate has handles for easy removal. • The end of the lift tool can be used as a bottle opener. 3-in-1 Versa-Rack Single Rack Installed Double Rack Installed...
-
Page 17: Storing And Loading Pellets
Storing and Loading Pellets Pellet Selection and Usage Always use 100% natural, food-grade BBQ wood pellets to achieve optimal grilling performance. These pellets: Are no thicker than the eraser on a pencil. • Burn cleanly, producing approximately 8000 BTUs per pound. •... - Page 18 Filling the Hopper and Auger Before cooking, the hopper must be filled with pellets to supply the grill's heating system. Dual Auger and Pellet Hopper The pellet drawer at the front of the grill slides out on glides for easy access and ensures a •...
-
Page 19: Quick Start Guide
Quick Start Guide Always ensure the burner pot is clear of pellets before each use, and you are loading • fresh pellets into the hopper. Starting and Operating the Grill 1. Prepare the Grill Plug in the power cord. Install the heat shield and cooking grates, then close the lid. 2. -
Page 20: Digital Display Instructions
Digital Display Instructions Coyote Outdoor Living Pellet Grill: Operation and Settings The Coyote Pellet Grill features an electric auger system that feeds wood pellets from the hopper into the burner pot. A heating element and dual fans ignite them, circulating smoke and heat throughout the grill to infuse food with a unique smoky flavor. - Page 21 Grill Modes The Coyote Pellet Grill offers Smoke, Grill, and Sear Modes. These modes adjust based on the target temperature, and the grill automatically feeds pellets using smart drop technology to maintain the set temperature. Smoke Mode • Target Temp: 175°F - 300°F Ideal for slow cooking and smoking with moderate smoke production.
- Page 22 IMPORTANT: Only use the sear grate while the grill is in sear mode. Using it in smoke or grill mode will cause the grill to overheat. Sear Grate Setting the Temperature 1. Press the target area on the display screen to bring up the temperature keypad. 2.
-
Page 23: Timer Button
Igniter Icon Stop Icon Start Icon Using the Timer To use the timer, press the timer button in the top-right corner of the display. • Enter your desired cooking time and press the blue checkmark. • Note: The timer does not affect the grill’s temperature or automatically stop the •... -
Page 24: Changing The Password
Enter the current password and then set a new 4-digit code. Change Password Following these detailed instructions, you can enjoy a seamless grilling experience with your Coyote Outdoor Living Pellet Grill, whether smoking, grilling, or searing your favorite dishes. -
Page 25: Cooking On The Grill
Cooking Guidelines for Your Coyote Outdoor Living Pellet Grill The table below provides general guidelines for cooking with your Coyote Pellet Grill. While these are useful starting points, we encourage you to experiment with times and temperatures to achieve your desired flavor and texture. - Page 26 2. Avoid Cross-Contamination Use separate plates and utensils for handling raw and cooked food. Never place cooked food on a plate or surface used for raw food. 3. Clean All Utensils and Surfaces Thoroughly wash all plates, cutting boards, and utensils used for raw food before reusing them for cooked food.
-
Page 27: Care And Maintenance
Care and Maintenance Cleaning and Maintenance Guidelines Proper cleaning and maintenance of your Coyote Pellet Grill ensures its longevity and optimal performance. Follow these instructions for safe and effective cleaning: General Cleaning Tips Always allow the grill to cool completely before cleaning. -
Page 28: Cleaning Process
5. Inspect and clean burners for insect nests or blockages to prevent fires beneath the grill. Avoiding Rust and Scratches Rust Prevention: Use a Coyote Grill cover for protection against contaminants. • Keep the grill covered during masonry work or near splashing pool chemicals. -
Page 29: Troubleshooting The Grill
Troubleshooting the Grill General Troubleshooting Pellet Jams: Causes, Prevention, and Clearing Instructions Pellet jams are a common issue with pellet grills and occur when wood pellets become stuck in the auger or chute, preventing them from reaching the burner pot. Common causes include wet pellets or incorrect burner pot placement. - Page 30 3. Identify and Clear the Jam If pellets are visible under the auger cover, you likely have a jam. Jammed Auger Use a screwdriver or pliers to loosen the jammed pellets. Remove the dislodged pellets and debris with a vacuum cleaner, ensuring the auger and chute are clear.
-
Page 31: Troubleshooting Guide
If the grill does not function properly, use the chart below to assist in diagnosing the problem. Troubleshooting is for general purposes only. ALWAYS ERR ON THE SIDE OF SAFETY. If the problem still exists, contact our Coyote Customer Support line at 855-520-1559. Problem: Flare-ups... - Page 32 Remove all grill contents and ensure the burner pot is correctly positioned. Correct Placement Incorrect Placement Pellet jam: • Check for a pellet jam and clear it if needed. Persistent issues: • If the problem continues, contact Coyote Customer Support at 855-520-1559 for assistance.
-
Page 33: Parts Listing
Parts Listing Exploded Parts List... - Page 34 Inlet Shield Inlet Shield Circuit Board Box – C2P28 1 C1P28039-HS Circuit Board Box – C2P36 1 C1P36039-HS Drip Tray Drawer Left – C2P28 C1P28040 Drip Tray Drawer Left – C2P36 C1P36040 Drip Tray Drawer Right – C2P28 C1P28041 Drip Tray Drawer Right – C2P36...
-
Page 35: Wiring Diagram
Wiring Diagram...
