PARTS LIST
1
TOP / BOTTOM RAIL
2 PCS
2
SLAT
6 PCS
3
WIDE SLAT
1 PC
4
LEFT LEG
1 PC
5
RIGHT LEG
1 PC
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the slat (2) and wide slat (3) to the top and bottom rail (1) as shown.
A
B
A
B
4
FOR BED FRAME ASSEMBLY follow assembly instructions included with your bed frame.
If you purchased a wood headboard to attach to metal bed frame, please refer to page 2.
HEADBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
A
JCB M6 X 110mm - 4 pcs
Spare - 1 pc
B
Barrel Nut - 4pcs
C
JCB M8 X 15mm ( 5/8") - 4 pcs
Assembly headboard to open bed frame
Step 2
B
5
TWIN
D
Allen wrench - 1pc
Spare - 1pc
2
3
1
Attach the left leg (4) and right leg (5) to the rail assembly
as shown. Using JCB (A) and barrel nut (B). Tighten with
Allen wrench (D).
B
BACK VIEW
A
A
A
HB-ISL-TAH
PO:
HARDWARE
HARDWARE FOR METAL BED FRAME
E
JCB M6 X 25mm (1") - 4 pcs
F
Flat washer - 4 pcs
G
Split washer - 4 pcs
1
B
CODE
ITEM
G-11892X
READY
TO
ASSEMBLE
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Adult assembly
Adult assembly
A
JCB M6 X 110mm
B
Barrel nut
Page 1 of 2
