AFi HBFB-ISL-OXD Assembly Instructions Manual

Before assembling your headboard and footboard, please read through these
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1 HEADBOARD PANEL BOARDS 4 PCS
2 LEFT LEG
3 RIGHT LEG
4 HEADBOARD SUPPORT
5 FOOTBOARD PANEL BOARDS
6 LEFT FOOTBOARD LEG
7 RIGHT FOOTBOARD LEG
8 FOOTBOARD SUPPORT
Attach left leg (2) and right leg (3) to headboard
Step 1
panel boards (1) using JCB M6 X 35mm (A).
Tighten with the Allen wrench M4 (D).
1
A
3
Step 3
Attach left footboard leg (6) and right footboard leg(7)
to footboard panel boards (5) using JCB M6 X 35mm (A).
Tighten with the Allen wrench M4 (D).
A
7
PO:
HEADBOARD & FOOTBOARD
ASSEMBLY INSTRUCTIONS
instructions carefully and familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
1 PC
A
1 PC
JCB M6 X 35mm - 28 pcs
1 PC
3 PCS
B
JCB M8 X 15mm ( 5/8") - 8 pcs
1 PC
1 PC
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
1 PC
A
A
5
FULL > QUEEN
C
Wood screw ( 1 1/4") - 7 pcs
Spare - 1 pc
Step 2
4
2
Step 4
B
6
8
HBFB-ISL-OXD
HARDWARE
Spare - 1pc
D
Allen wrench M4 - 1pc
E
Allen wrench M6 - 1pc
Attach headboard support (4) to
headboard panel boards using wood
screw 1 1/4" (C) Tighten with the
Phillips head screw driver.
(Customer supplied)
C
Attach footboard support (8) to
footboard panel boards using wood
screw 1 1/4" (C). Tighten with the
Phillips head screwdriver.
(Customer supplied)
C
CODE ITEM
G-12833X
READY
TO
ASSEMBLE
Spare - 1pc
Adult assembly Adult assembly
A
C
JCB M6 X 35mm
C
Wood Screw
ITEM
G-12834X
Page 1 of 2
