AFi TWIN Assembly Instructions Manual

please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1 FOOT RAIL 1 PC
2 LEFT LEG
3 RIGHT LEG
4 SIDE RAIL
5
SLAT KIT
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3)
to foot rail (1), using
JCB M6 X 110mm (A) and
barrel nut (B).
Tighten with the Allen wrench M4 (F).
Step 2
Attach side rails (4) to the foot rail (1) as shown below using JCB M8 X 15mm (C).
Tighten with Allen wrench M6 (E).
1
C
PO:
BED FRAME
TWIN>TWIN XL
ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
instructions carefully and familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
A
JCB M6 X 110mm (4 3/8") - 2 pcs
1 PC
B
Barrel nut - 2 pcs
1 PC
2 PCS
C
JCB M8 X 15mm ( 5/8") - 4 pcs
2 SETS
A
2
C
4
Spare - 1 pc
E
Allen wrench M6 - 1pc
B
1
4
CODE
FR-OP-ISL
ASSEMBLE
HARDWARE
D
Wood screw(1 1/4") - 24 pcs
Spare - 2 pcs
F
Allen wrench M4 - 1pc
Spare - 1pc
Adult assembly
B
JCB M6 X 110mm
A
3
Barrel nut
JCB M8 X 15mm
ITEM ITEM
G-21801X G-21802X
READY
TO
A
B
C
C
Page 1 of 2
