Adult assembly
CODE
DB-AM-ACA
G-11312X
DB-FP-ACA
G-11412X
PO :
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
A
Wood dowel - 4 pcs
Spare - 1 pc
B
JCB M6 X 2 1/2"( 65mm ) - 4 pcs
C
JCB M8 X 5/8"( 15mm ) - 8 pcs
ASSEMBLY INSTRUCTIONS
Before assembling your Daybed, please read through these
instructions carefully. Familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
ITEM
HARDWARE
D
Spare - 1 pc
E
DAYBED
Wood Screw - 24 pcs
Spare - 1 pc
Barrel Nut - 4 pcs
Spare - 1 pc
F
Allen wrench M6 - 1 pc
G
Allen wrench M4 - 1 pc
READY
Allen wrench
Page 1 of 3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AFi G-11312X
Summary of Contents for AFi G-11312X
- Page 1 ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Allen wrench Adult assembly CODE ITEM DB-AM-ACA G-11312X DB-FP-ACA G-11412X PO : HARDWARE NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY. Wood dowel - 4 pcs...
- Page 2 PARTS LIST HARDWARE 1 BOX G-11412X LEFT DAYBED ARM 1 PC G-11312X 1 BOX RIGHT DAYBED ARM 1 PC BACK PANEL 1 PC FRONT / BACK RAIL 2 PCS G-11412X 1 BOX SLAT KIT 2 SET Step 1 Attach the back panel (04) to the left and right daybed arm (02)(03), using wood dowels (A), JCB M6 X 2 1/2”(B) and barrel nut (E).
- Page 3 Step 2 Attach the front and back rail (05) to the Daybed arms as shown, using JCB M8 X 5/8” (C). Tighten with the Allen wrench (F). Adult assembly JCB M8 X 5/8” Allen wrench Step 3 Lay the slat kit (06) onto the rail assembly as shown, using wood screw (D).Tighten with the Phillips head screw driver (Customer supplied).
- Page 4 TRUNDLE BED TWIN ASSEMBLY INSTRUCTIONS READY Before assembling your Trundle bed, please read through these instructions carefully. Familiarize yourself with the different parts. Adult assembly ATTENTION! If you receive a damaged or defective item, please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726 Phillips screwdriver Customer supplied CODE...
- Page 5 TWIN PARTS LIST HARDWARE 1 BOX LEFT, RIGHT, MID RAIL 3 PCS SLAT KIT WITH WEBBING 2 SETS FRONT PANEL 1 PC FRONT RAIL 1 PC BACK RAIL 1 PC Step 1 Attach the left, right and mid rails (05) to the front rail (03) using L bracket (C) and JCB M6 X 1 5/8”(A).
- Page 6 TWIN Step 2 Attach the front panel (02) to the front rail (03) as shown, using JCB M6 X 5/8” (B). Tighten with the Allen wrench (E). Adult assembly JCB M6 X 5/8” Allen wrench Step 3 Lay the slat kits (06) webbing side down onto the rail assembly as shown. Attach using wood screw (D) and tighten with the Phillips head screw driver.
- Page 7 TWIN Congratulations! Your Trundle bed is now ready for use. We recommend that you periodically check that all screws are tight and all parts are secure to ensure lasting safety.
