instructions carefully and familiarize yourself with the different parts.
please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
LEFT POST
1 PC
1
2
RIGHT POST
1 PC
3
TOP RAIL
1 PC
4
MID RAIL
1 PC
6
BOTTOM RAIL
1 PC
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Insert all wooden dowels (D) into the locator holes on (3)(4) and(5)
as shown below.
Step 2
Lay the left post (1) bracket face down on smooth surface. Connect top rail (3), mid rail (4)
and bottom rail (5) as shown below, using JCB M6 X 110mm (A) and barrel nut (B).
Tighten with the Allen wrench (E).
B
A
PO:
HEADBOARD
ASSEMBLY INSTRUCTIONS
Before assembling your headboard, please read through these
ATTENTION! If you receive a damaged or defective item,
Instructions apply for bed sizes
TWIN > FULL > QUEEN
A
JCB M6 X 110mm - 4 pcs
Spare - 1 pc
B
Barrel Nut - 4 pcs
Spare - 1 pc
C
JCB M8 X 15mm ( 5/8") - 4 pcs
Assembly headboard to open bed frame
D
D
D
5
5
D
Wood Dowel - 10 pcs
Spare - 1 pc
E
Allen wrench - 1pc
Spare - 1pc
3
4
3
4
B
1
CODE
HB-ISL-WRN G-11902X G-11903X G-11904X
HARDWARE
HARDWARE FOR METAL BED FRAME
F
JCB M6 X 25mm (1") - 4 pcs
G
Flat washer - 4 pcs
H
Split washer - 4 pcs
D
D
D
B
A
A
ITEM
ITEM
ITEM
READY
TO
ASSEMBLE
Spare - 1 pc
Spare - 1 pc
Spare - 1 pc
Adult assembly
Adult assembly
D
Wood Dowel
Adult assembly
Adult assembly
A
JCB M6 X 110mm
B
Barrel Nut
Page 1 of 3
