PELLEt StovES USER MANUAL
UK
MARIELLA - MARIELLA PLUS
MADE
IN
ITALY
design & production
004321363 - Rev 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MARIELLA and is the answer not in the manual?

Questions and answers

Related Manuals for Extraflame MARIELLA

Summary of Contents for Extraflame MARIELLA

  • Page 1 PELLEt StovES USER MANUAL MARIELLA - MARIELLA PLUS MADE ITALY design & production 004321363 - Rev 000...
  • Page 2 APPLY TECHNICAL DATA LABEL ENGLISH...

  • Page 3: Table Of Contents

    MarieLLa detaiLs ......................................10 MarieLLa PLus detaiLs ....................................11 buLb therMostat reset (MarieLLa) ................................ 12 fuse ............................................12 hot air ducting (MarieLLa PLus) ................................12 coMbustion air ....................................... 12 stove Positioning ......................................13 note for correct oPeration ................................... 13 PeLLets and Loading ....................................14 PeLLet hoPPer .........................................

  • Page 4: English

    We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner...
  • Page 5 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.

  • Page 6: Routine Maintenance

    THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE.

  • Page 7: Installation

    INsTAllATION GENERAl The support surfaces and/or points must have a suitable load-bearing capacity to support the weight of the appliance, of the accessories and coatings. The generator must be on the level for correct operation. The flue extraction and hydraulic connections must be carried out by qualified personnel who must issue documentation of conformity according to the regulations of the country of installation.

  • Page 8: Ventilation And Aeration Of The Installation Premises

    VENTIlATION ANd AERATION Of ThE INsTAllATION PREMIsEs Ventilation, in the case of a non-watertight generator and/or non-watertight installation, must be carried out respecting the minimum area indicated below (considering the largest of the values suggested: Percentage of the Minimum net opening value of the Appliance categories Reference standard net opening section with respect to the...
  • Page 9 shAREd ChIMNEY fluE Check on the CE Technical Data Sheet whether the product is suitable for installation in a shared chimney flue (i.e. with multiple connection). Suitable devices can be installed in shared flue systems provided that: Š installation in a shared chimney flue (i.e. with multiple connection) is allowed in the place of installation; Š...

  • Page 10: Mariella Details

    MARIELLA DEtAILs Room air outlet Room probe On/Off Access to combustion chamber Bulb thermostat reactivation fuse and ash drawer Display Additional thermostat input 230 V power supply Upper fumes exhaust Rear flue gas outlet Pellet hopper Combustion air inlet ENGLISH...

  • Page 11: Mariella Plus Details

    MARIELLA PLUs DEtAILs Room air outlet Room probe On/Off Access to combustion chamber Additional thermostat input fuse and ash drawer Display Ducting outlet 230 V power supply Upper fumes exhaust Rear flue gas outlet Pellet hopper Combustion air inlet ENGLISH...

  • Page 12: Bulb Thermostat Reset (Mariella)

    (B) checked by a qualified technician. HOt AIR DUCtING (MARIELLA PLUs) The pipe used for ducting the hot air must have an internal diameter of 80 mm and it must also be insulated or at least be protected against heat dispersion.

  • Page 13: Stove Positioning

    stOvE POsItIONING To ensure the stove works correctly, it should always be positioned so that it is perfectly level, using a spirit level. NOtE FOR CORRECt OPERAtION Pellet hopper lid The following indications must be respected for correct pellet stove operation: Both during stove operation and when it is not used, all hatches (pellet hopper, door, ash drawer) must remain closed at all times.

  • Page 14: Pellets And Loading

    Pellets and loading Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin.

  • Page 15: Remote Control (Option)

    Remote contRol (oPtIon) The remote control can be used to adjust the main stove functions. Transmitter Select air mode Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch-off delay.

  • Page 16: Remote Control Icons

    Remote contRol Icons Air mode selected: Enable chrono Flashing QUIET Light on = activated REGULAR Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level.

  • Page 17: Control Board

    Control Board ViewiNg OF VariOus tO aCCess ON/OFF text messages tHe meNu ON/OFF OPeratiNg POwer temPerature ICon key indicates the presence of an alarm. indicates the status of the weekly programming Off: indicates that there are no alarms Off: deactivated. On: indicates the presence of an alarm On: activated.

  • Page 18: General Menu

    General menu go back - exit scroll parameters: next (3); previous (2) Change settings data: increase (4); decrease (5) Confirm - access menu MODES VENTILATION *AIR DUCTING **TEMPERATURE *AIR ZONE CONTROL EASY SETUP CHRONO ENABLING CHRONO MODE PRG1 SETTINGS DATE-TIME PRG2 LANGUAGE PRG3...

  • Page 19: First Ignition Settings

    FIrst IGnItIon settInGs after connecting the power cord at the back of the generator, turn the switch (if any) to position (i). the switch is used to power the heat generator board. date-tIme this menu allows the date and time to be set. CONtrOLs PrOCeDure Š...

  • Page 20: Operation And Logic

    PartitiON It Is ProHIBIted to use tHe aPPlIanCe wItHout tHe PartItIon and/ or Flame Guard (see FIGure on sIde). removal wIll ComPromIse tHe saFety oF tHe ProduCt and result In tHe ImmedIate nullIFICatIon oF tHe warranty PerIod. In tHe Case oF wear or deterIoratIon, request aFter-sales assIstanCe to rePlaCe tHe Part (rePlaCement Is not Covered By tHe warranty as tHe ComPonent Is suBjeCt to wear).

  • Page 21: Mode

    (marIella Plus) this feature uses the PRO AIR SETUP which allows for the ventilation to be adjusted according to 4 levels: OFF, Quiet, reguLar, BOOst.

  • Page 22: Air Zone Control (Mariella Plus)

    Zone Control (marIella Plus) this menu allows you to enable the air ZONe CONtrOL mode range: (ON, OFF) when ON is selected, the stove will optimise the settings so that heat is sent to the ducting when the set temperature for the main room has been reached.

  • Page 23: Enabling

    enaBlInG allows the chrono and the different stove time slots to be enabled/disabled. CONtrOLs PrOCeDure Š Press key 6. Š Press 3 until CHrONO appears and confirm by pressing key 6. Š Confirm eNaBLiNg by pressing 6. Š use keys 4 -5 to enable (ON) or disable (OFF) Š...

  • Page 24: Example

    eXamPle CHrono tIme slot 02:00 08:00 16:30 23:00 MANUAL 02:00 08:00 16:30 23:00 Power start 02:00 time slot 1 Power 5 stop 23:00 02:00 08:00 16:30 23:00 start 08:00 time slot 2 Power 1 02:00 08:00 16:30 23:00 stop 16:30 22°...

  • Page 25: Settings

    settInGs • DATE-TIME • LANGUAGE See chapter: firSt ignition SettingS • DEGREES dIsPlay this menu allows you to adjust the brightness of the display. the values range from OFF, 1 to 20. if set to OFF, the display backlighting is set to maximum brightness and turns off after a 60 second delay.

  • Page 26: Delta-T

    delta-t this function allows the hysteresis thresholds to be set for stove ignition (DeLta-t ON) and switch-off (DeLta-t OFF), used as a room temperature adjustment interval if not managed by an external thermostat. the possible values for DELTA-T go from: 0.5 - 5°C CONtrOLs PrOCeDure Š...

  • Page 27: Additional Functions

    Š Connect the power to the stove again. Š set the set mODe to aux. MarieLLa MarieLLa pLUS pLeaSe note: the terMinaL can be foUnd in the bag inSide the Stove. InstallatIon must Be PerFormed By qualIFIed staFF and/or tHe manuFaCturer's servICe teCHnICIans oPeratIon In aIr duCtInG wItH tHermostat or ProBe (oPtIonal) the factory setting is for the ducting to emit hot air into the ducted room without managing the temperature.
  • Page 28 WITH AMBIENT THERMOSTAT (OPTIONAL) remove the jumper and connect the ambient thermostat in the room that needs to be temperature-controlled through air ducting 1. 4 control modes: OPERATION IN AIR DUCTING WITH AMBIENT THERMOSTAT (OPTIONAL) set on OFF the ducted motor will remain off unless the fumes temperature exceeds the normal (the temperature setting is not visible) operating temperature or the user sets the appliance to power 5 Once the specific activation threshold has been reached and exceeded, at temperature...

  • Page 29: Delay Switch-Off

    delay swItCH-oFF You can program a delayed switch-off for the stove. For example, if it is 8 pm and the delayed switch-off is set to 1h, the stove will automatically switch off at 9 pm. if you press and hold keys 2 + 4 at the same time, the screen “DeLaY switCH-OFF” will appear, (this setting can only be configured if the stove is in the PreParatiON or wOrK phase).

  • Page 30: Cleaning And Maintenance

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions in Complete safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on.
  • Page 31 burn pot and Combustion Chamber: Š Vacuum the residue in the burn pot Š Remove the burn pot completely from the relevant compartment; Š Vacuum the ash from the burn pot slot, ignition plug pipe holder and combustion chamber. Š Clear/clean all the holes in the burn pot. Š...
  • Page 32 removable ash drawer: Š Remove the ash drawer and empty it in a dedicated container. PARTS FREQUENCY IN DAYS 1 - 2 BURN POT (USER) COMBUSTION CHAMBER (USER) REMOVABLE ASH DRAWER (USER) T-SHAPED FITTING / SMOKE DUCT (QUALIFIED TECHNICIAN) One day means an average use of 8h at the rated power. How often the ash drawer is emptied depends on a number of factors: the type of pellets, the stove output, the use of the stove and the type of installation.

  • Page 33: Routine Maintenance Performed By Qualified Technicians

    TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe performed by Qualified teChniCians routine maintenance must be performed at least once a year. Since the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualified technician, using only original spare parts.
  • Page 34 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM mariella THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (dismantle and clean the smoke duct and "T"), new seal where required Gaskets, pellet hopper, inspections, ash drawer and door (replace and apply silicone where indicated)
  • Page 35 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM mariella plus THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (dismantle and clean the smoke duct and "T"), new seal where required Gaskets, pellet hopper, inspections, ash drawer and door (replace and apply silicone where indicated)

  • Page 36: Displays

    Displays Display Reason Generator off sTaRT The start-up phase is in progress pelleT loaDinG Continuous pellet loading is in progress during the ignition phase iGniTion The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress MoDulaTion The generator is working at minimum final cleaninG...

  • Page 37: Disposal

    Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product.

  • Page 38: Symbol En 16510-1

    Symbol EN 16510-1 EN 16510-1 EXPLANATION Symbol Nominal heat output part Part load heat output CON / INT Appliance operation, Continuos (CON) or Intermittent (INT) / CO Carbon dioxide emission 2 nom 2 part / CO Carbon monoxide emission part Minimum distances to combustible materials - bottom Minimum distances to combustible materials - ceiling Minimum distances to combustible materials - floor in front...
  • Page 39 ENGLISH...
  • Page 40 CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products. 02/04/2025 004321363-000 MAN.UT. MARIELLA- MARIELLA PLUS [E271]...
