- Page 1 Operating instructions Ultrasonic flow meter, model FLC-UFL Ultrasonic flow meter, model FLC-UFL...
- Page 2 Operating instructions model FLC-UFL Page 3 - 44 © 08/2020 WIKA Alexander Wiegand SE & Co. KG All rights reserved. WIKA is a registered trademark in various countries. ® Prior to starting any work, read the operating instructions. Keep for later use.
-
Page 3: Table Of Contents
4.6 Front interface ..... 20 4.7 USB service interface and lock switch ... . . 21 WIKA operating instructions, ultrasonic flow meter model FLC-UFL... - Page 4 8.3 Disposal ..... . . 44 Declarations of conformity can be found online at www.wika.com. WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
-
Page 5: General Information
Supplementary documentation: ▶ Please follow all the documentation included in the scope of delivery. With versions for hazardous areas, also observe the FLC-UFL series safety instructions (additional operating instructions 81500907) and the FLC-UFL series flow meter sealing locations (operating instructions 81500906). -
Page 6: Abbreviations
1. General information The warranty provisions outlined in the terms and conditions apply to this product. ■ Euromisure WIKA Instruments (Euromisure in short) assumes no obligation if: Repair or replacement of equipment or parts is required due to normal wear ■... -
Page 7: Explanation Of Symbols
Note ... points out useful tips, recommendations and information for efficient and trouble-free operation. The last version of the referenced document is leading, unless otherwise specified. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 8: Safety
2. Safety 2.1 Intended use The FLC-UFL series ultrasonic flow meter is designed to measure the volume flow rate and velocity of gases in pipelines. Optionally, it can convert the measured gas volume flow to base conditions and record meter readings, diagnostics and additional data. -
Page 9: Improper Use
Ensure that the necessary construction is in place to properly support the instrument. The instrument must be installed in a stress-free condition. The FLC-UFL series flow meter is suitable for use in pressurised lines within the design conditions specified on the flow meter nameplate. 2.2 Improper use Any use beyond or different to the intended use is considered as improper use. -
Page 10: Labelling, Safety Markings
The labelling, safety markings must be maintained in a legible condition. Product labels (example) Nameplates and labels are placed on the FLC-UFL series flow meter for identification purposes and to provide details about the specific product, along with safety-related information. Together with the safety instructions and this manual, it provides clear guidance on the product’s intended use, design and certification. - Page 11 Do not dispose of with household waste. Ensure proper disposal in accordance with national regulations. <- - - - - - - - > Reverse (-) / Forward (+) flow direction WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
-
Page 12: Ex Marking
EPL Ga equipment is required, it must be installed so that, even in the event of rare incidents, ignition sources due to impact and friction sparks are excluded. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 13: Transport, Packaging And Storage
Regularly inspect the stored flow meter to ensure no condensation is present, as this ■ may cause corrosion and/or damage to the electronics. If other piping components and/or flow conditioners are provided with the meter, ■ apply an anti-corrosion coating to any uncoated surfaces. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... - Page 14 2. Place the instrument in the packaging and evenly pad with shock-absorbent material. 3. If stored for a prolonged period of time (more than 30 days), place a bag containing a desiccant inside the packaging. WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
-
Page 15: Design And Function
Certificate of conformity / Ex certificates ■ Safety instructions ■ Calibration certificate ■ Inspection certificate: ■ Meter configuration sheet ■ Factory acceptance test report. ■ Cross-check scope of delivery with delivery note. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 16: Description
Changes in the velocity of sound caused by pressure or temperature fluctuations do not affect the calculated velocity of gas with this measurement method. The FLC-UFL series ultrasonic gas flow meter calculates the volume flow rate based on the velocity of gas and the meter body’s internal diameter. -
Page 17: Main Board Power Supply
4. Design and function 1.1.2 Main board power supply The FLC-UFL series flow meter requires an external intrinsically safe power supply. Signal Function PWR - Power supply PWR + WARNING! The power supply interfaces of the FLC-UFL flow meters are reverse polarity protected up to max. -
Page 18: Slot 2 - P/T Option Board
Digital output + 1.1.5 Slot 2 – P/T option board The FLC-UFL series flow meter can be equipped with an optional pressure/temperature board, enhancing the system with pressure and temperature measurement capabilities. This allows the instrument to calculate base volume using PTZ conversion. Pressure and temperature sensors are supplied by Euromisure. -
Page 19: Slot 2 - 4
When equipped with this option board, a passive (externally powered) mA output is available. The output can be configured via WIKA Flow Manager software for any parameter required; however, normally it is used for flow rate, velocity of gas etc. Using the PC tool WIKA Flow Manager, it can be configured and calibrated. -
Page 20: Front Interface
USB connector Keys Lock switch The front of the FLC-UFL electronics features a 128x128 dot matrix LCD graphic display. Four navigation keys are positioned at the corners of the display for operation of the local user interface. Two LEDs are provided on the front panel: Green LED = Power indication ■... -
Page 21: Usb Service Interface And Lock Switch
(laptop or computer). It should only be used in a safe area or with appropriate precautions such as gas detection. Refer to the FLC-UFL series safety instructions for further details. The parameter lock switch is located below the USB connector and provides a way to lock all relevant parameters. -
Page 22: Commissioning And Operation
WARNING! To avoid possible strain, ensure your lifting equipment is suitable for the weight of the FLC-UFL series flow meter. Always use the lifting eye bolts provided on the meter body and make sure to use approved lifting equipment and that the equipment shows no damage or wear. -
Page 23: Configurations
5. Commissioning and operation The FLC-UFL series flow meter is shipped in a wooden crate. ▶ To open the crate, remove the top panel nails or screws and disassemble the box. Remove the transport fixtures and then move the flow meter to the mounting location using the lifting eye bolts provided on the flow meter. -
Page 24: Wiring
1.1.7 Option board identification To identify the option boards installed in the FLC-UFL series flow meter, locate the electronics model number on the SPU label. Refer to the table in the control drawing to determine the installed option boards. -
Page 25: Slot 1 - Rs-485 Option Board
Connections to the resistive-bridge pressure sensor (factory default = voltage-mode sensor). Refer to the PRESS2 Signal + safety instructions for approved pressure sensors PRESS3 Signal - or contact the manufacturer Euromisure for more information PRESS4 Bridge - WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 26: Slot 2 - 4
Digital output + D4_B RS-485 B Differential RS-485 2-wire communication port, galvani- cally isolated D1_A RS-485 A 1.1.14 Galvanic isolation If galvanic isolation is required, an external isolator must be used on frequency output WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 27: Switching On
1.1.15 USB service port connection setup To connect to the FLC-UFL series via the USB service port on older revisions (firmware 1.x.x and 2.x.x) of the flow meter hardware, it may be necessary to set the instrument to USB service mode. -
Page 28: Commissioning
Stop bits Modbus address The FLC-UFL flow meter has a built-in 120 Ω termination resistor in case the RS-485 network needs to be terminated at this point. The switch shown in in the following picture can be used for this purpose. -
Page 29: Local User Interface Operation
5. Commissioning and operation 5.6 Local user interface operation 1.1.17 LED indicators The FLC-UFL flow meter has two LED indicators, located underneath the LCD. LED indicator functions LED status Interval Description Power LED green Power off Green, flashing Power on, system running... -
Page 30: Normal Operating Mode Screens
5. Commissioning and operation 1.1.19 Normal operating mode screens During normal operation, the FLC-UFL series flow meter provides essential information on the LCD. Both the upper and lower sections can display various parameters, which can be selected using the keypad. - Page 31 5 – USB service mode (unavailable in “console” mode) ■ System info The system info menu provides information about the FLC-UFL flow meter software and hardware. After a few seconds the display will exit to the operating mode. Display test When “Display test”...
- Page 32 LCD until acknowledged by the user. Alarms and warnings can be acknowledged through main menu option 4 – Clear alarms. If the error condition persists, the alarm or warning cannot be cleared. WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
-
Page 33: Changing Communication Mode Parameters
When “USB Svc. Mode” is highlighted and selected using the <DOWN> and then <ENT>, the FLC-UFL series flow meter will enter the USB service mode, enabling communication via the USB port. The message “USB service mode” will appear on the display. -
Page 34: Sealing
5. Commissioning and operation 5.7 Sealing For the sealing locations refer to document 81500906.01 FLC-UFL ultrasonic flow meter sealing locations. CAUTION! Damage to property due to electrostatic discharge (ESD) When working on open circuits (PCBs) there is a danger of damaging sensitive electronic components due to electrostatic discharge. -
Page 35: Faults
For contact details, see chapter 1 „General information“” or the back page of the operating instructions. In the event of any faults, first check whether the instrument is mounted correctly, mechanically and electrically. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 36: Diagnostic Codes
0x00001000 4096 TestMode Meter is in test mode 0x00002000 8192 DigOutOverflow LF pulse output overflow 0x00004000 16384 TotalStorageInitError Totaliser storage error – no valid flash record found on startup WIKA operating instructions, ultrasonic flow meter model FLC-UFL... - Page 37 0x00000020 PressureOutofRan- Pressure sensor geError error or value out of range 0x00000040 PTReadTimeOu- No response tError from P/T option board 0x00000080 PTZInputsOutof- PTZ inputs out RangeError of range WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
- Page 38 (cycle skip) 0x00000800 2048 EnvPeakSkip Envelope peak skip (packet) 0x00001000 4096 Spare 0x00002000 8192 Spare 0x00004000 16348 Spare 0x00008000 32786 Spare 0x00010000 65536 VOSRange Velocity of sound out of range WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
- Page 39 VoS 0x00080000 524288 WetGasVOG Wetgas filter triggered substitution based on VoG 0x00100000 1048576 Substitution Path being substituted based on historical data 0x00200000 2097152 Spare 2) Values set per transducer AB or BA WIKA operating instructions, ultrasonic flow meter model FLC-UFL...
-
Page 40: Maintenance And Cleaning
7.1 Maintenance The FLC-UFL series ultrasonic flow meter has no moving parts, and its sensors and electronics require minimal maintenance. However, periodic inspection is recommended. To monitor the meter’s health status, collect a short log file of measurement and diagnostic data under known and repeatable conditions. - Page 41 Velocity of sound ratio (VoS ratio) The velocity of sound ratio is a good indicator of problems, either in the process or in the FLC-UFL series signal detection. During normal condition the ratios should be very close to 1.0. Path status (PathStatus AB and PathStatus BA) The path status diagnostic values provide a more detailed indication of the health of each path in each direction of transmission using an 8-digit number.
-
Page 42: Cleaning
1. Before cleaning, correctly disconnect the instrument from the pressure supply, switch it off and disconnect it from the mains. 2. Only clean the FLC-UFL series ultrasonic flow meter with a damp cloth. Do not use solvents for cleaning. Do not expose the electrical connections to moisture. -
Page 43: Dismounting, Return And Disposal
For these media, in addition to all standard regulations, the appropri- ate existing codes or regulations must also be followed. 8.1 Dismounting Dismounting must only be carried out by personnel authorised by the manufacturer. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... -
Page 44: Return
Hand in old instruments for environmentally friendly disposal at a ■ designated collection point for the disposal of electrical and electronic equipment. Ensure proper disposal in accordance with national regulations and ■ observe the currently applicable regulations. WIKA operating instructions, ultrasonic flow meter model FLC-UFL... - Page 45 WIKA-Betriebsanleitung, Typ...
- Page 46 WIKA operating instructions, model...
- Page 47 WIKA operating instructions, model ...
- Page 48 WIKA subsidiaries worldwide can be found online at www.wika.com. Importer for UK Euromisure WIKA Instrument s.a.s. di WIKA Instruments Ltd WIKA Italia S.r.l. Unit 6 and 7 Goya Business Park via Borghisani 4 The Moor Road 26035 Pieve San Giacomo • Italy Sevenoaks info@wika.it...
