  • Page 1 Magnum 10RX Configurable Router Security Appliance Hardware Installation and User Guide www GarrettCom com...
  • Page 2 GarrettCom, Inc. reserves the right to change specifications, performance characteristics and/or model offerings without notice. Warranty: Refer to current Belden Americas Terms & Conditions for warranty information. Contacting GarrettCom, Inc Please use the mailing address, phone and fax numbers and email address listed below: GarrettCom, Inc.

  • Page 3: Compliance Statements

    Magnum 10RX Installation and User Guide 01/13 Compliance Statements FCC Part 15 This equipment generates, uses and can radiate frequency energy and if not installed and used properly in strict accordance with the manufacturer's instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.
  • Page 4 Magnum 10RX Installation and User Guide 01/13 Electrical Safety requirements: This product is to be installed Only in Restricted Access Areas (Dedicated Equipment Rooms, Electrical Closets, or the like). All products shall be installed with a readily accessible disconnect device in the building installation supply circuit to the product.

  • Page 5: Table Of Contents

    Magnum 10RX Installation and User Guide 01/13 Table of Contents Page     SPECIFICATIONS ................... 1     Technical Specifications ................. 1     Ordering Information ................4     INTRODUCTION ..................8     Inspecting the Package and Product ............8  ...
  • Page 6 Magnum 10RX Installation and User Guide 01/13     When Calling for Assistance ..............32     Return Material Authorization (RMA) Procedure ........ 32     Shipping and Packaging Information ............ 33   APPENDIX A: DC Power Input................ 34   APPENDIX B: Removal / Installation of the Hot-Swap power supply ..

  • Page 7: Specifications

    Magnum 10RX Installation and User Guide 01/13 SPECIFICATIONS Technical Specifications Serial Protocols: TCP/IP to serial/reverse terminal server, Serial Multipoint & Multimaster Topologies Performance: Serial DB9 Ports: RS232 only or RS232/RS485/RS422 software selectable DB9 interface. Serial data rate from 300 bps to 230.4 kbps. Serial RJ45 Ports: Same functionality as DB-9 ports (RJ45 pinout conforms to EIA-561 DTE standard) RJ45 Ports: 10/100/1000 Mbps speed, full- or half-duplex mode, per port,...
  • Page 8 Magnum 10RX Installation and User Guide 01/13 Fiber Multimode connector types supported: Fiber Port, 100BASE-FX, SFP modules Fiber Port, 1000BASE-SX, SFP modules Fiber Singlemode connector types: Fiber Port, 100BASE-FX, SFP modules Fiber Port, 1000BASE-LX, SFP modules Serial LEDs: Per DB-9 or RJ45 port (see section 5.1.1 for detailed LED configurations) One LED/port indicating active connection Ethernet LEDs: Per RJ45 or Fiber port...
  • Page 9 See also Note for Power Substations in Section 3.2.1 and 5.1.5 IEC 61850-3 EMC and Operating Conditions Class C for Power Substations NEMA TS-2 for Traffic Control EN50155 for Railways Warranty: Refer to current Belden Americas Terms & Conditions for warranty information. info@GarrettCom.com Email for additional information.

  • Page 10: Ordering Information

    Magnum 10RX Installation and User Guide 01/13 Ordering Information 10RX – Fan cooled base units MODEL DESCRIPTION 10RX-AC-F: Magnum 10RX router, Front-mount in rack, with an auto-sensing worldwide AC power type power supply (100-240V AC only) using a UL-registered recessed-male IEC 320 power connector suitable for worldwide AC power cords. May be factory-configured with a variety of auto media (RJ45/SFP), serial, and T1/E1 WAN ports.
  • Page 11 Magnum 10RX Installation and User Guide 01/13 10RX – Thermal Fin cooled base units MODEL DESCRIPTION 10RX-H-TF: Magnum 10RX router, Front-mount in rack, with integral 90-250V AC/DC Power Supply. May be factory-configured with a variety of auto media (RJ45/SFP), serial, and T1/E1 WAN ports. Configure up to 34 ports. Heavy-duty case with convection cooling through thermal fins.
  • Page 12 Magnum 10RX Installation and User Guide 01/13 “HSP” Hot-Swap power supply options: HSPM-H: AC or DC power (90-250V) HSPM-L: 24/48V DC power (22-60V) *HSPM-HF: AC or DC power (90-250V) with internal cooling fan *HSPM-LF: 24/48V DC power (22-60V) with internal cooling fan HSPM-BLNK: Blank cover for one hot-swap power supply slot * Fan-cooled bases must use power supplies with internal cooling fan Following module can be configured in Slots A and/or B only...
  • Page 13 Magnum 10RX Installation and User Guide 01/13 Slot locations: Options & Extras: CONSOLE-CBLQD: Console attachment cable. Serial null modem (aka: crossover) cable with RJ45 connector for the 10RX on one end and a DB-9 connector on other end. CONSOLE-CBLQU: Same as above, but with USB connector CONFORM05-RMOD: Conformal coating, heavy duty silicone at 5 mil thickness, for interior PCBs, PS and modules (for moisture protection) CONFORM08-RMOD: Conformal coating, heavy duty silicone at 8 mil thickness, for...

  • Page 14: Introduction

    Magnum 10RX Installation and User Guide 01/13 INTRODUCTION Inspecting the Package and Product Examine the shipping container for obvious damage prior to installing this product; notify the carrier of any damage that you believe occurred during shipment or delivery. Inspect the contents of this package for any signs of damage and ensure that the items listed below are included.

  • Page 15: Product Description

    Magnum 10RX Installation and User Guide 01/13 Product Description Magnum 10RX Configurable Router The Magnum 10RX is a configurable router and security appliance offering traditional T1/E1 WAN routing, interoperation with MPLS-based carrier VPN services and advanced serial or terminal server functionality. The Magnum 10RX complies with IEC 61850 and is ideal for large substation installations or similar applications where hardness, performance, security, quality of service or diverse protocols are required.

  • Page 16: Features And Benefits

    Magnum 10RX Installation and User Guide 01/13 Features and Benefits Dual Hot-swappable power supplies The Magnum 10RX offers configurable Dual Hot-Swappable power supplies for redundancy and increased reliability. Available for “H” AC/DC and “L” 24/48VDC. Configurable Configurable WAN Router with up to 10 Gigabit Ethernet ports, 16 T1/E1 ports, or 32 serial connections.

  • Page 17: Installation

    Magnum 10RX Installation and User Guide 01/13 INSTALLATION Before installing the equipment, it is necessary to take the following precautions: 1.) If the equipment is mounted in an enclosed or multiple rack assembly, the steady-state long-term environmental temperature around the equipment must be less than or equal to 60 2.) If the equipment is mounted in an enclosed or multiple rack assembly, adequate airflow must be maintained for proper and safe operation.

  • Page 18: Connecting Network Cables

    Magnum 10RX Installation and User Guide 01/13 Connecting Network Cables The Magnum 10RX is specifically designed to support standard Ethernet and Serial media types within a single unit. This is accomplished by supporting all popular fiber and copper port connectors which can be individually selected and configured. (See Section 5.1 for a description of the Port Modules choices, Request a quote if you do not see the ones you want.) NOTE: Shielded cable is required for ALL copper ports (RJ45 / DB9)

  • Page 19: Connecting Singlemode Fiber Optic

    Magnum 10RX Installation and User Guide 01/13 NOTE: for Power Substations: In support of the IEEE 1613 Class 2 standard, Garrettcom advises that, for substation applications, the RJ45 ports are intended for connectivity to other communication equipment such as routers or telecommunication multiplexers installed in close proximity (i.e., less than 2 meters or 6.5ft) to the 10RX.

  • Page 20: Connecting Fiber Optic Cable To Sfp Transceivers

    Magnum 10RX Installation and User Guide 01/13 3.2.4 Connecting Fiber Optic Cable to SFP Transceivers Before connecting the fiber optic cable, remove the protective dust caps from the module connectors. Save these dust caps for future use. Wipe clean the ends of the dual connectors with a soft cloth or lint-free lens tissue dampened in alcohol.

  • Page 21: Mounting

    Magnum 10RX Installation and User Guide 01/13 Mounting The Magnum 10RX Router can be easily mounted on a table-top or any suitable horizontal surface. They have four rubber feet to provide stability without scratching finished surfaces. 3.3.1 Rack-mounting options Installation of the Magnum 10RX Router in a 19” rack is a simple procedure. The units are 1.5U (2.63”) high for Thermal fin version and 1U (1.74”) high for non- Thermal fin version.
  • Page 22 Magnum 10RX Installation and User Guide 01/13 model without Thermal Fin cover model with Thermal Fin cover Fig 3.3a 10RX front mount dimensions www GarrettCom com...
  • Page 23 Magnum 10RX Installation and User Guide 01/13 model without Thermal Fin cover model with Thermal Fin cover Fig 3.3b 10RX reverse mount dimensions www GarrettCom com...

  • Page 24: Powering The Magnum 10Rx Router

    Magnum 10RX Installation and User Guide 01/13 Powering the Magnum 10RX Router The Magnum 10RX is available with the choice of Dual Hot-Swappable power supplies or a single fixed (non Hot-Swappable) internal power supply. The Hot-Swappable power supplies are available with 90-250V AC/DC and 24/48V DC power inputs.

  • Page 25: Alarm Contacts For Monitoring Internal Power, And Software Traps

    Magnum 10RX Installation and User Guide 01/13 Alarm Contacts for monitoring internal power, and Software Traps The Alarm Contacts feature, standard on the Magnum 10RX, provides two Form C Normally Closed (NC) contacts to which the user can attach two sets of status monitoring wires at the Alarms terminal block, see Fig 3.5a below.

  • Page 26: Connecting The Console Terminal

    Magnum 10RX Installation and User Guide 01/13 Connecting the Console Terminal Use a (RJ45) “null modem” cable to connect the Console Port (the RJ45 Console port on the 10RX) to your PC, so that your PC becomes the 10RX Console Terminal.

  • Page 27: Module Pin Assignments

    Magnum 10RX Installation and User Guide 01/13 Note: To use the Console port to configure the managed router, a serial (Null-modem) male to male cable is required to communicate properly. The Null-Modem (RJ45) cable is optional and can be ordered from the factory, along with the unit as: CONSOLE-CBLQD for serial port CONSOLE-CBLQU for USB port NOTE for Power Substations: In support of the IEEE 1613 Class 2 standard, GCI...
  • Page 28 Magnum 10RX Installation and User Guide 01/13 RJ48 T1/E1 Adapter ports Signal Description (Direction) RX Data - Ring Receive (In) RX Data - Tip Receive (In) Not used TX Data - Ring Transmit (Out) TX Data - Tip Transmit (Out) Not used Not used Not used...
  • Page 29 Magnum 10RX Installation and User Guide 01/13 DB9 (Female) Serial ports – RS232 DTE (10TS2-DB9-DTE) Signal Description (Direction) Data Carrier Detect (In) Receive Data (In) Transmit Data (Out) Data Terminal Ready (Out) Signal Ground Data Set Ready (In) Request to Send (Out) Clear to Send (In) Ring Indicator (In) DB9 (Female) Serial ports –...

  • Page 30: Operation

    Magnum 10RX Installation and User Guide 01/13 OPERATION This chapter describes the functions and operation of the Magnum 10RX Router. Switching Functionality A Magnum 10RX provides switched connectivity at Ethernet wire-speed among all of its Ethernet ports. The Magnum 10RX supports 10/100/1000 Mbps for copper media and 100/1000 Mbps for fiber ports to maximize bandwidth utilization and network performance.

  • Page 31: Auto-Cross (Mdix) And Auto-Negotiation, For Ethernet Rj45 Ports

    Magnum 10RX Installation and User Guide 01/13 Auto-Cross (MDIX) and Auto-negotiation, for Ethernet RJ45 ports The RJ45 ports independently support auto-cross (MDI or MDIX) in auto- negotiation mode and will work properly with all the other connected devices with RJ45 ports whether they support Auto-negotiation (e.g 10 Mbps Hub, media converter) or fixed mode at 10, 100 or 1000 Mbps Half/Full Duplex(managed switch) or not.

  • Page 32: Packet Prioritization, 802.1P Qos

    Magnum 10RX Installation and User Guide 01/13 Packet Prioritization, 802.1p QOS Quality of Service (QOS) means providing consistent predictable data delivery to users from datagram paths that go all across a network. As a LAN device, the Magnum 10RX can do its part to prevent any QOS degradation while it is handling Ethernet traffic through its ports and internal switch buffers.

  • Page 33: Flow-Control, Ieee 802.3X Standard

    Magnum 10RX Installation and User Guide 01/13 Flow-control, IEEE 802.3x standard The Magnum 10RX incorporates a flow-control mechanism for Full-Duplex mode. The purpose of flow-control is to reduce the risk of data loss if a long burst of activity causes the switch to save frames until its buffer memory is full. This is most likely to occur when data is moving from a 100 Mbps port to a 10 Mbps port and the 10 Mbps port is unable to keep up.

  • Page 34: Magnum 10Rx Router Port Modules

    Magnum 10RX Installation and User Guide 01/13 MAGNUM 10RX Router Port Modules This chapter describes each Port Module, including appearance, functionality, and status displays. 10RX Modules An important feature of the Magnum 10RX is the use of Port Modules for flexible mixed-media connectivity to RJ45 copper, fiber media and Serial connections.

  • Page 35: 10-1Rjsfp, One Auto-Media Rj45/Sfp (Use In Slots A,B)

    Magnum 10RX Installation and User Guide 01/13 5.1.2 10-1RJSFP, one auto-media RJ45/SFP (use in Slots A,B) The 10-1RJSFP provides one auto-media port with one RJ45 connection or one open SFP, supporting distances to 70km and beyond. Ports are auto media detect and may use either RJ45 or SFP module.

  • Page 36: 10Ts2-Db9, Db-9 Serial Module (Use In Slots C-J)

    Magnum 10RX Installation and User Guide 01/13 5.1.5 10TS2-DB9, DB-9 Serial module (use in Slots C-J) The 10TS2-DB9 is a two DB-9 serial port module for 10RX. Each serial port module can be ordered as RS232 only (DCE) or RS232 / RS485 / RS422 (DTE). See Section 1.2 for ordering information.

  • Page 37: Troubleshooting

    Magnum 10RX Installation and User Guide 01/13 TROUBLESHOOTING All Magnum products are designed to provide reliability and consistently high performance in all industrial network environments. The installation of a Magnum 10RX is a straight forward procedure. The operation is also straightforward and is discussed in Section 4.0 of this User Guide.

  • Page 38: When Calling For Assistance

    GarrettCom will carefully test and evaluate all returned products, will repair products that are under warranty at no charge, and will return the warranty-repaired units to the sender with shipping charges prepaid (see Belden Americas Terms & Conditions for warranty information). However, if the problem or condition causing the return cannot be duplicated by GarrettCom, the unit will be returned as: No Problem Found.

  • Page 39: Shipping And Packaging Information

    Magnum 10RX Installation and User Guide 01/13 Shipping and Packaging Information Should you need to ship the unit back to GarrettCom, please follow these instructions: Package the unit carefully. It is recommended that you use the original container if available. Units should be wrapped in a "bubble-wrap" plastic sheet or bag for shipping protection.

  • Page 40: Appendix A: Dc Power Input

    Magnum 10RX Installation and User Guide 01/13 APPENDIX A: DC Power Input A1.0 Specifications for Magnum 10RX, DC Power at 24/48VDC and 90-250 AC/DC Power input Each Magnum Model 10RX requires DC power input, at 24/48VDC and 90- 250 AC/DC nominal. The wide range of DC power input types qualifies this product for use in 24/48VDC and 90-250 AC/DC applications in different industries.
  • Page 41 Magnum 10RX Installation and User Guide 01/13 10RX, 24/48VDC, 90-250VDC INSTALLATION This section describes the proper connection of the 24/48VDC, leads to the DC power terminal block on the Magnum 10RX Router. The DC terminal block on the Magnum 10RX is located on the right rear or left front (Reverse unit) of the unit and is equipped with four (6) screw-down lead posts.

  • Page 42: Appendix B: Removal / Installation Of The Hot-Swap Power Supply

    Magnum 10RX Installation and User Guide 01/13 APPENDIX B: Removal / Installation of the Hot-Swap power supply Tools Required: #1 Phillips head screwdriver Step 1: Locate the Hot-Swap power supply locking screw. Loosen the locking screw until no longer engaged. Step 2: Lift the Hot-Swap power supply handle (shown above) to disengage from the 10RX chassis.
