- Page 1 Magnum DX940e Industrial Cellular Router Installation Guide Garrettcom 255 Fourier Avenue, Fremont, CA 94539, USA Ph: (510) 438-9071 Fax: (510) 438-9072...
- Page 2 Declara ons Copyright Copyright 2019 by GarrettCom Inc. Printed in the US. All rights reserved. This manual may not be reproduced or disclosed in whole or in part by any means without the written consent of GarrettCom. DynaStar is a trademark of GarrettCom Inc. All other trademarks mentioned in this document are the property of their respective owners.
- Page 3 WARRANTY GarrettCom warrants equipment manufactured by it to be free from defects in materials and workmanship for a period of three (3) years from date of shipment. If within the warranty period the purchaser discovers such item was not as warranted above and promptly notifies GarrettCom in writing, GarrettCom shall repair or replace the items at the company's option.
- Page 4 RETURN OF EQUIPMENT No equipment may be returned without purchaser first obtaining written Return Material Authorization (RMA) from GarrettCom. An RMA can be obtained by contacting Sales at 510-438-9071. Equipment accepted for credit, not involving a GarrettCom error, shall be subject to all the terms of the original purchase contract and to a service charge.
- Page 5 SAFETY WARNING: Service to this unit can be made only by factory authorized personnel. Failure to observe this caution can result in malfunction to the unit as well as electrocution to personnel. Avertissement: Cet appareil ne peut être examiné ou réparé que par un employé autorisé du fabricant. Si cette consigne n’est pas respectée, il y a risque de panne et d’électrocution.
- Page 6 Preface ABOUT THIS MANUAL This document provides instructions for installing the Magnum DX940e hardware. This document gives product descriptions, specifications, detailed information on ports and pin-outs, all site preparation required to install the product, complete installation procedures, power up instructions, and instructions for removing and maintaining the product.
-
Page 7: Table Of Contents
Contents 1.0 Overview ................................. 1 Overview ..............................1 Configura on ............................... 1 1.2.1 Connec vity ............................. 1 1.2.2 Power and Ground ........................... 2 1.2.3 Indicators ..............................2 1.2.4 Moun ng Op ons ............................ 3 Specifica ons ............................... 4 1.3.1 Physical ..............................4 1.3.2 Environmental ............................ -
Page 8: Overview
1.0 Overview Overview The Magnum DX940e can be configured at order time and provides connectivity to Ethernet via four 10/100/1000 Base-T Ethernet ports, 100Mbps or 1000Mbps Fiber ports via SFP's. Additionally, two 10/100/1000 Base-T ports can be added for Gigabit connectivity or 1000Mbps fiber ports (via SFP) can be added for 1000Mbps fiber connectivity. Other connectivity options includes optional four programmable serial ports, and one DDS or T1/E1 WAN port. -
Page 9: Power And Ground
1.2.2 Power and Ground The DX940e can be ordered with a high (90 -250 VAC or VDC) or Low (24-48 VDC) voltage power supply. The connection point for the power supply is located at the rear of the chassis. The rear face also contains the primary ground stud and labels including serial number, model number, and port and power specifications. -
Page 10: Moun Ng Op Ons
Figure 1-3a, Possible LEDs in positions “A” and “B” shown in Figure 1-3 above. The LEDs shown in Figure 1-3(a) are as follows: E1, E2 - Gigabit Ethernet ports C1 - Cellular Interface W1 - WAN Port ... -
Page 11: Specifica Ons
Specifica ons The following sections provide detailed information about the physical, electronic, and industrial specifications of the DX940e. 1.3.1 Physical The physical dimensions and weight of the DX940e are defined in Table 1-1. Table 1-1, Physical Specifications Height: 1.75 inches (4.45 cm) Width: 9.5 inches (24.13 cm) Depth:... -
Page 12: Power Requirements
1.3.4 Power Requirements The power requirements of the DX940e are defined in Table 1-4. Table 1-4. Power Requirements High Voltage AC/DC Low Voltage DC (Polarized) Voltage Input Range: 90-250 VAC/VDC 24-48 VDC Max. Power (Wa s): Typical Power (Wa s): Max. -
Page 13: Indicators
1.3.6 Indicators The status indicators of the DX940e are described in Table 1-6. There are two sets of LEDs so that you can conveniently monitor ac vity regardless of the orienta on of the device. See Figure 1-3 for more details. Table 1-6. -
Page 14: Pin-Outs
Pin-outs The following subsections describe the pin-outs of the connectors used with the DX940e. 1.4.1 RJ48 DDS Connec on Table 1-7 defines the pin-out of the RJ48 connector used on port W1 with the DDS connection. Table 1-7. RJ48 DDS Pin-Out Signal Tx Data - Ring Tx Data - Tip... -
Page 15: Db9 (Female) - Rs232 Serial Ports And Console Port
1.4.4 DB9 (Female) – RS232 Serial Ports and Console Port Table 1-10 defines the pin-out of the DB9 female connector for the console port and for serial ports S1 -S4 when they are configured for the RS232 interface. DB9 connectors are used on RS232 serial ports S1 - S4 and the console port, for asynchronous connec ons. -
Page 16: Installa On
2.0 Installa on This chapter provides specific procedures for installing the Magnum DX940e, preparing for installa on, and uninstalling the device. Preparing for Installa on The DX940e is designed to be installed in standard 19" racks, on a DIN-Rail system, or on a panel. 2.1.1 Tools Regardless of the moun ng system you are using you will need the following tools: ... -
Page 17: External Connec Ons
2.1.4 External Connec ons You can speed up the installa on of the DX940e by having the following equipment and informa on on hand before beginning: A supply of cables and connectors of the required types. IP addresses for new devices and any exis ng devices you will be connec ng to. ... - Page 18 2.3.1.1 Moun ng on a Panel Each bracket for moun ng on a panel a aches with two screws to the screw holes located toward the rear of the DX940e (see Figure 1-4). You can adjust the distance of the DX940e from the panel to two posi ons by your selec on of which pair of screw holes to use in a aching the bracket to the DX940e.
- Page 19 2.3.1.2 Moun ng in a 19” Rack System The DX940e device can be mounted in a 19” rack system with the I/O connectors on the aisle side and the power and ground connectors on the wire side (conven onal moun ng) or in the reverse configura on. Power connector Conven onal...
- Page 20 Reverse Moun ng The brackets provided for reverse moun ng have an opening in their forward projec ng parts to accommodate the power cable. Figure 2-6, Reverse Rack Moun ng brackets Figure 2-7, Reverse Rack Moun ng – Dimensions 2.3.1.3 Moun ng in a DIN-Rail system To mount the DX940e on a DIN-Rail, follow the below steps: ...
- Page 21 Step 2: A ach the DIN-Rail moun ng brackets to the Panel Mount Brackets with the latch plungers oriented to the rear of the DX using two 10-32x3/8" screws as shown below. Step 3: Rea ach the Panel Mount Brackets with DIN-Rail brackets to the DX940e using the 6-32x1/4" screws removed in step 1.
-
Page 22: Connec Ng Facility Power
2.3.2 Connec ng Facility Power The DX940e comes in either high or low voltage models. The unit does not have a power on/off switch and is ac ve when the power is connected. ELECTRICAL WARNING: Always ensure that the ground connec on is made prior to connec ng facility power to the DX940e. -
Page 23: Connec Ng To The Console Port And The Alarm Port
Making the Power Connec on The power wires should be 14 AWG. Smaller wires may be used, down to 18 AWG, but verify that they meet your local electrical requirements. Connect the power to the unit as follows. ELECTRICAL WARNING: Ensure that power is disconnected from wiring prior to handling! Check the voltage ra ng next to the power connector - verify that it matches the power source. -
Page 24: Connec Ng Network Cables
2.3.4 Connec ng Network Cables There are two types of connec ons that can be made to the DX940e. They are serial and Ethernet copper. The following sec ons describe each type of connec on separately. 2.3.4.1 Connec ng Serial Cables This procedure assumes that one end of the serial device cable is already a ached to the end unit. - Page 25 2.3.4.3 Connec ng the WAN Cable The single WAN connec on on the DX940e can be a DDS or a T1/E1 port. An RJ48 is used for both the DDS and the T1/E1 ports. This is a modular connector that connects the DX940e to the external telecommunica ons network. The following procedure assumes that the line and telecom equipment are ready to accept data traffic from the DX940e and the interfacing cable is already a ached to this gear.
-
Page 26: Maintenance
Maintenance The DX940e is designed to be replaced as a unit. There are no servicing requirements and there are no user- repairable/replaceable components in this device including the RTC lithium-ion ba ery. Maintenance is limited to replacing the unit. The following sec ons detail disconnec ng all connec ons to the chassis, removing the chassis, cleaning op cal devices and packing the DX940e for return to the manufacturer. -
Page 27: Product Bulle N
Administrator Guide The Administrator Guide for the DX940e is available on the Garre Com website and is available at: h ps://www.belden.com/products/industrial/networking/so ware/magnum-mns-dx-so ware 1) Scroll down page and choose Magnum MNS-DX Technical Support, then Garre com. 2) Login with current account or Register for new account, to access the desired documenta on.
