Belden HIRSCHMANN RSR20 Series Installation Manual

Belden HIRSCHMANN RSR20 Series Installation Manual

Industrial ethernet rail switch rugged
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Installation
Industrial Ethernet Rail Switch Rugged
RSR20/RSR30 Family
5
6
7
8
9
10
Installation RSR20/RSR30
Release 06 07/2021
5
6
7
8
9
10
3
4
5
6
7
8
9
10
3
4
5
6
7
8
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
Technical support
https://hirschmann-support.belden.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIRSCHMANN RSR20 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Belden HIRSCHMANN RSR20 Series

Summary of Contents for Belden HIRSCHMANN RSR20 Series

  • Page 1 User Manual Installation Industrial Ethernet Rail Switch Rugged RSR20/RSR30 Family Installation RSR20/RSR30 Technical support Release 06 07/2021 https://hirschmann-support.belden.com...
  • Page 2 The naming of copyrighted trademarks in this manual, even when not specially indicated, should not be taken to mean that these names may be considered as free in the sense of the trademark and tradename protection law and hence that they may be freely used by anyone. ©...

  • Page 3: Table Of Contents

    Contents Important information Safety instructions About this manual Description General device description Description of the device variants 1.2.1 Combination options RSR20/RSR30 1.2.2 Port number and media for RSR20-... 1.2.3 Port number and media for RSR30-... Power supply 1.3.1 Supply voltage with characteristic value C Ethernet ports 1.4.1 10/100/1000 Mbit/s twisted pair port 1.4.2 10/100 Mbit/s twisted pair port...
  • Page 4 2.2.1 Installing the device onto the DIN rail 2.2.2 Mounting on a vertical flat surface 2.2.3 Grounding the device Installing an SFP transceiver (optional) Connecting the terminal block 2.4.1 Supply voltage 2.4.2 Supply voltage with the characteristic value C 2.4.3 Signal contact Mounting the terminal block Operating the device Connecting data cables...

  • Page 5: Important Information

    Important information Note: Read these instructions carefully, and familiarize yourself with the device before trying to install, operate, or maintain it. The following notes may appear throughout this documentation or on the device. These notes warn of potential hazards or call attention to information that clarifies or simplifies a procedure.
  • Page 6 NOTICE NOTE provides information about procedures that do not involve the risk of injury. Installation RSR20/RSR30 Release 06 07/2021...

  • Page 7: Safety Instructions

    Safety instructions WARNING UNCONTROLLED MACHINE ACTIONS To avoid uncontrolled machine actions caused by data loss, configure all the data transmission devices individually. Before you start any machine which is controlled via data transmission, be sure to complete the configuration of all data transmission devices. Failure to follow this instruction can result in death, serious injury, or equipment damage.
  • Page 8 Strain relief  Note: If the strain relief is insufficient, there is a potential risk of torsion, contact problems and creeping interruptions.  Relieve the connection points of cables and lines from mechanical stress.  Design strain reliefs in such a way that they help prevent any mechanical damage to cables, wires or conductors caused by external influences or their own weight.
  • Page 9 National and international safety regulations   Verify that the electrical installation meets local or nationally applicable safety regulations. Grounding the device  The device is grounded by the separate ground screw on the front panel.  Use a wire diameter for the ground conductor that is no smaller than the diameter of the supply voltage connection, however of at least 0.75 mm²...
  • Page 10  The cables used are permitted for the temperature range of the application case.  Relevant for North America: The power supply cables are suitable for ambient air temperatures of at least 167 °F (75 °C). The power supply cable wires are made of copper.
  • Page 11 Avertissement - Risque d'explosion - Ne pas débrancher tant que le circuit est sous tension à moins que l'emplacement soit connu pour ne contenir aucune concentration de gaz inflammable. Avertissement - Risque d'explosion - La substitution de tout composant peut rendre ce matériel incompatible pour une utilisation en classe I, division 2.
  • Page 12 Installation RSR20/RSR30 Release 06 07/2021...
  • Page 13 Installation RSR20/RSR30 Release 06 07/2021...
  • Page 14 Housing  Only technicians authorized by the manufacturer are permitted to open the casing.  Never insert pointed objects (narrow screwdrivers, wires, etc.) into the device or into the connection terminals for electric conductors. Do not touch the connection terminals. ...
  • Page 15 47 CFR § 2.1077 Compliance Information Industrial Ethernet Rail Switch Rugged RSR20/RSR30 U.S. Contact Information Belden – St. Louis 1 N. Brentwood Blvd. 15th Floor St. Louis, Missouri 63105, United States Phone: 314.854.8000 This device complies with part 15 of the FCC Rules. Operation is subject...

  • Page 16: About This Manual

    About this manual The “Installation” user manual contains a device description, safety instructions, a description of the display, and the other information that you need to install the device. Documentation mentioned in the “User Manual Installation” that is not supplied with your device as a printout can be found as PDF files for downloading on the Internet at: https://www.doc.hirschmann.com Installation RSR20/RSR30...

  • Page 17: Key

    The symbols used in this manual have the following meanings:  Listing Work step   Subheading Installation RSR20/RSR30 Release 06 07/2021...

  • Page 18: Description

    Description General device description You can choose from between a wide range of variants. You have the option to set up your device individually based on different criteria:  Number of ports  Transmission speed  Types of connectors  Temperature range ...

  • Page 19: Description Of The Device Variants

    The short designation is in column 3. You have numerous options of combining the device characteristics. You can determine the possible combinations using the configurator which is available in the Belden Online Catalog https://catalog.belden.com on the web page of the device.
  • Page 20 Position Characteristic Charac Property teristic value 11 and 12 Port 1 and 2 or Port 1 CC 2 × Combo port 100/1000 Mbit/s Ethernet 2 × SFP slot 1000 Mbit/s Ethernet 2 × Multimode FX (DSC) 2 × Multimode FX (MTRJ) 2 ×...

  • Page 21: Port Number And Media For Rsr20

    1.2.2 Port number and media for RSR20-... To put together your personal RSR20 device in the above table (see table you have the following combination options ("?" = any value from the "Characteristic value" column): Position Position Position Position Position Position Position 1 to 10...
  • Page 22 Supply voltage connection 1 Product code 2-pin terminal block Position 18 Voltage range: See “General technical data” on page 53. LED display elements for device status USB interface Connection for signal contact 1 V.24 connection for external management Supply voltage connection 2 Product code 2-pin terminal block Position 19...
  • Page 23 1 to 9 See table 4 on page 22. port 3 to 8 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type port 1 to 2 LAN port for Standard IEEE 802.3 100BASE-FX Fiber optic cable Connection depending on type...
  • Page 24 1 to 9 See table 4 on page 22. port 1 to 8 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Table 6: RSR20 device variants with 8 twisted pair ports (RJ45) 1 to 9 See table 4 on page 22.

  • Page 25: Port Number And Media For Rsr30

    port 4 to 9 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Ports 1 to 3 LAN port for Type of fiber Multimode Fiber optic cable Standard IEEE 802.3 100BASE-FX Connection MTRJ type Table 7: RSR20 device variants with 3 fiber optic ports (MTRJ) and 6 twisted pair ports (RJ45) 1.2.3...
  • Page 26 1 to 9 See table 4 on page 22. port 4 to 9 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type Ports 1 to 3 LAN port for Standard IEEE 802.3 100BASE-FX (combo Fiber optic cable ISO/IEC 8802-03 1000BASE-SX/LX ports) Connection...
  • Page 27 1 to 9 See table 4 on page 22. port 5 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type port 3 to 4 LAN port for Standard IEEE 802.3 100BASE-FX Fiber optic cable Connection SFP slot type...
  • Page 28 1 to 9 See table 4 on page 22. port 5 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type port 3 to 4 LAN port for Standard IEEE 802.3 100BASE-FX Fiber optic cable Connection SFP slot type...
  • Page 29 1 to 9 See table 4 on page 22. port 3 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type port 1 to 2 LAN port for Standard IEEE 802.3 100BASE-FX (combo ports) Fiber optic cable ISO/IEC 8802-03 1000BASE-SX/LX Connection SFP slot...

  • Page 30: Power Supply

    1 to 9 See table 4 on page 22. port 3 to 10 LAN port for Standard IEEE 802.3 10BASE-T/100BASE-TX Twisted pair Connection RJ45 socket type port 1 to 2 LAN port for Standard ISO/IEC 8802-03 1000BASE-SX/LX Fiber optic cable Connection SFP slot type...

  • Page 31: 10/100/1000 Mbit/S Twisted Pair Port

    1.4.1 10/100/1000 Mbit/s twisted pair port This port is an RJ45 socket. The 10/100/1000 Mbit/s twisted pair port allows you to connect network components according to the IEEE 802.3 10BASE-T/100BASE-TX/ 1000BASE-T standard. This port supports:  Autonegotiation  Autopolarity  Autocrossing (if autonegotiation is activated) ...

  • Page 32: 100 Mbit/S F/O Port

    The 1000 Mbit/s F/O port offers you the ability to connect network components according to the IEEE 802.3 100BASE-SX/1000BASE-LX standard. This port supports:  Autonegotiation  Full duplex mode Delivery state: Autonegotiation activated Verify that you connect LH ports only with LH ports, SX ports only with SX ports, and LX ports only with LX ports.

  • Page 33: Pin Assignments

    Media type Connection options Twisted pair cable Technical standard IEEE 802.3 10BASE-T/100BASE-TX/ 1000BASE-T Connection type RJ45 Fiber optic cable either Technical standard IEEE 802.3 100BASE-FX Connection type Fast Ethernet SFP transceiver Technical standard IEEE 802.3 1000BASE-SX/LX Connection type 1 Gigabit Ethernet SFP transceiver Table 16: Combo ports: Connection options 10/100/1000 Mbit/s twisted pair port ...

  • Page 34: Display Elements

    Display elements After the supply voltage is set up, the software starts and initializes itself. Afterwards, the device performs a self-test. During this process, various LEDs light up. The process takes around 40 seconds. Figure 1: LED display elements 1 – Device status 2 –...
  • Page 35 Stand-by (green LED) Meaning Glowing green Standby mode enabled Not glowing Stand-by mode not enabled RM and StandBy during read and write access - display saving processes Flashing alternately Error during saving process. LED's flash synchronously, two Loading configuration from the AutoConfiguration Adapter times a second ACA or from the device.

  • Page 36: Port Status

    1.5.2 Port status These LEDs display port-related information. During the boot phase, they indicate the status of the boot process. Figure 3: Port status LEDs 1 – Port status LEDs for single or single-row RJ45 sockets: one green and one yellow LED per port 2 –...

  • Page 37: Interface (External Management)

    Figure Function VCC (VBus) − Data + Data Ground (GND) Table 17: Pin assignment of the USB interface 1.6.2 V.24 interface (external management) The V.24 interface is an RJ11 socket. At the V.24 connection, a serial interface is provided for the local connection of an external management station (VT100 terminal or PC with corresponding terminal emulation) or an AutoConfiguration Adapter ACA 11.

  • Page 38: Signal Contact

    Signal contact Figure 5: Signal contact: 2-pin terminal block with screw locking The signal contact is a potential-free relay contact. The signal contact is open when the device is not connected to a power supply. The signal contact allows you to control external devices or monitor device functions.

  • Page 39: Installation

    Installation The devices have been developed for practical application in a harsh industrial environment. On delivery, the device is ready for operation. Perform the following steps to install and configure the device:  Checking the package contents  Installing and grounding the device ...

  • Page 40: Mounting On A Vertical Flat Surface

    To mount the device onto a horizontally mounted 35 mm DIN rail according to DIN EN 60715, proceed as follows:  Slide the upper snap-in guide of the device into the DIN rail.  Press the media module downwards onto the clip-in bar. ...

  • Page 41: Grounding The Device

    Figure 6: Mounting the device on the wall Proceed as follows:  Mount the device on the wall plate as shown in the illustration. Insert the upper snap-in guide of the device into the rail and press it down against the rail until it snaps into place.

  • Page 42: Installing An Sfp Transceiver (Optional)

    Installing an SFP transceiver (optional) Prerequisites: Exclusively use Hirschmann SFP transceivers. See “Accessories” on page 61. Figure 7: Installing SFP transceivers: Installation sequence Perform the following work steps:  Take the SFP transceiver out of the transport packaging (1).  Remove the protection cap from the SFP transceiver (2). ...

  • Page 43: Supply Voltage

    The torque for tightening the supply voltage terminal block on the device is 4.5 lb-in (0.51 Nm). Supply voltage connection 1 Product code 2-pin terminal block Position 18 Voltage range: See 53 “General technical data”. Supply voltage connection 2 Product code 2-pin terminal block Position 19 Voltage range:...

  • Page 44: Supply Voltage With The Characteristic Value C

    2.4.2 Supply voltage with the characteristic value C You will find information on the characteristic values here: “Combination options RSR20/RSR30” on page 19 − Figure 8: Supply voltage with characteristic value C: 2 pin terminal block with screw lock The supply voltage is connected via pin 1 and pin 2. Type of the voltages that Specification of the supply Pin assignment...

  • Page 45: Mounting The Terminal Block

    Mounting the terminal block Proceed as follows:  Mount the terminal block for the voltage supply and signal contact on the front of the device using the snap lock. Verify that the snap lock latches in place. Operating the device Proceed as follows: ...

  • Page 46: Filling Out The Inscription Label

    Filling out the inscription label The information field for the IP address helps you identify your device. Figure 9: Label area for IP address of device 1 – IP address of device (label area) 2 – MAC address of device (label) Installation RSR20/RSR30 Release 06 07/2021...

  • Page 47: Making Basic Settings

    Making basic settings The IP parameters must be entered when the device is installed for the first time. The device provides the following options for configuring IP addresses:  Configuration via V.24 connection  Configuration using the HiDiscovery protocol  Configuration via BOOTP ...

  • Page 48: First Login (Password Change)

     Log on to the device again with your new password. Note: If you lost your password, then use the System Monitor to reset the password. For further information see: https://hirschmann-support.belden.com/en/kb/required-password- change-new-procedure-for-first-time-login Installation RSR20/RSR30 Release 06 07/2021...

  • Page 49: Monitoring The Ambient Air Temperature

    Monitoring the ambient air temperature Operate the device below the specified maximum ambient air temperature exclusively. See “General technical data” on page 53. The ambient air temperature is the temperature of the air at a distance of 5 cm (2 in) from the device. It depends on the installation conditions of the device, for example the distance from other devices or other objects, and the output of neighboring devices.

  • Page 50: Maintenance And Service

    Maintenance and service  When designing this device, Hirschmann largely avoided using high-wear parts. The parts subject to wear and tear are dimensioned to last longer than the lifetime of the product when it is operated normally. Operate this device according to the specifications. ...

  • Page 51: Disassembly

    Disassembly Removing the device Proceed as follows:  Disconnect the data cables.  Disable the supply voltage.  Disconnect the terminal blocks.  Disconnect the grounding.  Insert a screwdriver horizontally below the casing into the locking gate.  Without tilting the screwdriver, pull the locking gate down and tilt the device upwards.

  • Page 52: Removing An Sfp Transceiver (Optional)

    Removing an SFP transceiver (optional) Figure 10: De-installing SFP transceivers: De-installation sequence Perform the following work steps:  Open the locking mechanism of the SFP transceiver (1).  Pull the SFP transceiver out of the slot via the open locking mechanism (2).

  • Page 53: Technical Data

    Technical data General technical data  Dimensions RSR20-.../RSR30-... 4.72 in × 5.39 in × 4.53 in W × D × H (120 mm × 137 mm × 115 mm) RSR20-.../RSR30- 4.72 in × 5.71 in × 4.53 in (120 mm × 145 mm × ...inclusive wall mounting 115 mm) plate...
  • Page 54 Dimension drawings  inch 4.72 6,99 120,83 0.28 4.76 Drill holes drawing for wall mounting plate  4.72 inch 0.40 3.94 0.22 0.28 Installation RSR20/RSR30 Release 06 07/2021...
  • Page 55 EMC and immunity  IEC/EN 61850- Description Certification C Certification H 3:2002 EMI TYPE tests, test in comp. with Test level Test level IEC/EN 61000-4-2 ESD Contact discharge +/- 8 kV +/- 8 kV Air discharge +/- 15 kV +/- 15 kV IEC/EN 61000-4-3 Electromagnetic field 80 - 2700MHz 20 V/m...
  • Page 56 IEEE 1613:2009 Description Certification C Certification H EMI TYPE tests, test in comp. with Test level Test level IEEE C37.90.1 Damped oscillation DC Power line +/- 2.5kV line/ground +/- 2.5kV line/ground +/- 1kV line/line +/- 1kV line/line AC Power line +/- 2.5kV line/ground +/- 2.5kV line/ground +/- 1kV line/line...
  • Page 57 Network range  Note: The line lengths specified for the transceivers apply for the respective fiber data (fiber attenuation and Bandwidth Length Product (BLP)/ Dispersion). Product Wave Fiber System Example Fiber code length attenuatio for F/O attenuatio Dispersion M-SFP-... cable length -SX/LC...
  • Page 58 Product Wave Fiber System Example Fiber code length attenuatio for F/O attenuatio Dispersion M-SFP-... cable length -LH+/LC LH 1550 nm 9/125 µm 15 dB ... 44.12 mi ... 0.25 dB/km 19 ps/(nm×km) 30 dB 67.11 mi (71 km ... 108 km) -LH+/LC LH 1550 nm 9/125 µm...
  • Page 59 Product Wave Fiber System Example Fiber BLP/ code length attenuatio for F/O attenuation Dispersion M-FAST- cable SFP-... length -MM/LC... MM 1310 nm 50/125 µm 0 dB ... 0 mi ... 1.0 dB/km 800 MHz×km 8 dB 3.11 mi (0 km ... 5 km) -MM/LC...
  • Page 60 10/100/1000 Mbit/s twisted pair port Length of a twisted pair segment max. 328 ft (100 m) (for Cat5e cable) Table 24: Network range: 10/100/1000 Mbit/s twisted pair port...
  • Page 61 Power consumption/power output, order numbers  The order numbers correspond to the product codes of the devices. See “Combination options RSR20/RSR30” on page 19. RSR device power power output consumption (inclusive (inclusive transceivers) transceivers) 3 × Combo port and 6 × TX port (100 Mbit/s) 15 W 51 Btu (IT)/h 2 ×...
  • Page 62 Gigabit Ethernet SFP transceiver Order number M-SFP-SX/LC EEC 943 896-001 M-SFP-MX/LC EEC 942 108-001 M-SFP-LX/LC 943 015-001 M-SFP-LX/LC EEC 943 897-001 M-SFP-LX+/LC 942 023-001 M-SFP-LX+/ LC EEC 942 024-001 M-SFP-LH/LC 943 042-001 M-SFP-LH/LC EEC 943 898-001 M-SFP-LH+/LC 943 049-001 M-SFP-LH+/LC EEC 942 119-001 SFP-GIG-LX/LC 942 196-001...
  • Page 63 Fast Ethernet SFP transceiver Order number M-FAST SFP-LH/LC EEC 943 948-001 SFP-FAST-MM/LC 942 194-001 SFP-FAST-MM/LC EEC 942 194-002 SFP-FAST-SM/LC 942 195-001 SFP-FAST-SM/LC EEC 942 195-002 Table 27: Accessory: Fast Ethernet SFP transceiver a. You will find further information on certifications on the Internet on the Hirschmann product pages (www.hirschmann.com).
  • Page 64 Name IEEE 802.1Q Virtual LANs (VLANs, MRP, Spanning Tree) IEEE 802.1Q Virtual Bridged Local Area Networks (VLAN Tagging, GVRP) IEEE 802.1w Rapid Reconfiguration IEEE 802.3 Ethernet IEEE 1613 IEEE Standard Environmental and Testing Requirements for Communication Networking Devices in Electric Power Substations UL 508 Safety for Industrial Control Equipment Table 28: List of the technical standards...
