Table of contents Table of contents Introduction ............................... 5 Manufacturer/Contact .........................5 Product Identification ...........................5 Content and meaning of the document ..................6 Safety ................................ 6 Intended use ............................6 Staff qualifications ..........................7 Instructions ..............................7 Overview ..............................9 Scope of delivery ........................... 9 Technical data ............................
Page 4
Table of contents Settings ..............................19 Control via external “S” button ......................19 Configuring parameters via remote control ................20 REMOTE CONTROL MDi/PDi (EM10425509) ................20 REMOTE CONTROL MDi/PDi temporary settings ..............21 Programming the REMOTE CONTROL MDi/PDi ............... 22 Configuring parameters via ESY app with ESY-Pen ..............24 Installing the ESY app .........................
Introduction Manufacturer/Contact If you have questions about the product, need help with the app or are planning extensions, do not hesitate to get in touch with us: ESYLUX GmbH Phone: +49 4102 489-0 An der Strusbek 40 E-mail: info@esylux.com 22926 Ahrensburg Internet: www.esylux.com...
This document contains detailed information about the installation, configuration and complex functions of the product. The current document is available for download as a PDF at www.esylux.com. It can be printed out if required. • Read the document before using the product.
Safety Staff qualifications Installation, commissioning and other work on the 230 V mains may only be carried out by electricians or electrical specialists in keeping with the country- specific regulations. Configuration and operation can also be performed by individuals with no electrical engineering qualification.
Page 8
Safety WARNING! Risk of fatal injury from interfering with the device. Opening and modifying the device can result in death or serious injury – also for any others working on the system. – Only remove the connection cover of the Powerbox for installation. CAUTION! Risk of injury due to improper installation.
Overview Overview Scope of delivery The product scope of delivery comprises: • Device • 2 cable tie for strain relief • Brief instructions for installation and commissioning Technical data Basic Express General Ceiling mounted presence or motion Device category detector Control system ON/OFF Status signalling...
Page 10
Overview Basic Express Max. inrush current 78 A / 5 ms Short pulse/1 min, 2 min, 5 min, Switch-off delay time 10 min, 15 min, 30 min (via ESY-App) Protection type / protection class IP23 / II Operating temperature range -25 °C...+50 °C Test mode Not implemented...
Page 11
Overview Basic Express Housing Outer diameter Ø 79 mm Housing height 79 mm Material UV-stabilised polycarbonate Colour White, similar to RAL 9010 Protection class IP23 Electrical version Mains voltage 230 V~ ±10 % Mains frequency 50-60 Hz Power consumption 0.4 W Standby consumption <0.4 W Protection class...
Operation Operation • 360° field of detection, 8 m range at an installation height of 2.5 m. • Automatically controlled lighting channels when motion is detected. • With zero-cross switching. Detection range 2.5 m mounting height 360° field of detection, 8 m range •...
Operation Conditions in which the lighting is switched on The lighting is switched on if the target brightness value is below the preset lux value and movement is detected in the field of detection. Further movement is acknowledged by the sensor with two short flashes of the red LED (the LED can be switched off;...
Installation Installation Mechanical work Description The device is intended for mounting in the ceiling panel of a suspended ceiling. Requirements • There are no cables in the mounting area that could be damaged during drilling. • The installation dimensions shown can be adhered to. WARNING! Switch off the power supply before installing the system.
Installation Circuit diagram S S N N L’ L’ S S N N L’ L’ 10 A Single connection Parallel connection Phase, 230 V Lighting Neutral conductor Push button Electrical work WARNING! Risk of fatal injury from electric shock. Working on the 230 V mains can result in death or serious injury. –...
Page 16
Installation Procedure Open the transparent terminal cover. The terminal cover is fitted with clips on two side. Remove the covers in the connection cover at the points where cables are to be fed through. Remove the insulation on each of the sheathed cables and individual wires.
Page 17
Installation Lance the cable inlets on the wire gasket and insert the input and output cables through. Connect the 2-way terminal* to connect earth conductors of input and output cables. *The 2-way terminal is not included in delivery. After establishing the electrical connection, fix the installation cable to the housing using cable ties (strain relief).
Page 18
Installation Close the terminal cover. Insert the device with the mounting folded up into the installation opening. 56.75 mm 30 mm 22.3 mm ø 68 mm 18 / 28...
Activation Activation Connect the power supply. A warm-up phase of 45 seconds is initiated. The red LED flashes. During this time, the lighting is switched on. Overview of factory settings Factory settings Operating mode Fully automatic Brightness switching value approx. 500 lux Follow-up time 5 mins Sensitivity...
Settings Modes activated by pressing the external button: • Press button for approx. 1 seconds: The lighting is switched on or off (for the duration of the switch-off delay time). • Press button for approx. 3 seconds: The lighting is switched on or off continuously for 4 hours.
Settings REMOTE CONTROL MDi/PDi temporary settings Parameter configurations are only temporarily applied. Function Customised setting ON / OFF Switching the lighting ON / OFF manually. Note: The “ON / OFF” mode can be cancelled by pressing the “Reset” button. “ON” acknowledgement: Movement detected in the field of detection is acknowledged with two short flashes of the red LED.
Settings Programming the REMOTE CONTROL MDi/PDi Alterations to parameters are applied permanently. Function Customised setting Enter programming mode The detector goes into programming mode. Acknowledgement: The red LED lights up permanently and the lighting is switched on continuously. Exit programming mode Programming mode will automatically end 5 minutes after the last parameter set without storing the set parameters.
Page 23
Settings Function Customised setting Fully automatic / semi-automatic mode The lighting can be controlled in fully automatic and semi-automatic modes. Fully automatic: The lighting is switched on depending on the set lux value and movement being detected. If movement is no longer detected, the preset switch-off delay time will start.
Settings Function Customised setting PIR sensitivity Settings: maximum (100 %), 75 %, 50 %, minimum (25 %)*. *25%, 50%, 75%, 100% accessible with combination of The sensitivity of the detector for the purpose of detecting movement can be set. Press the 15 min button twice to set to 30 min.
Settings (depending on your selection) when an infrared signal is being transmitted. It is not possible to transfer parameters from the product to the ESY app. Communication between the ESY-Pen and the product is unidirectional. Note: For optimum signal transmission, maintain a minimum distance corresponding to the mounting height.
Settings To be able to parameterise your product, you must add it to the ESY app product list the first time: ¾ Start the ESY app. ¾ Press the button < Select products and configure >. ¾ Press the button < Add product > and select your product using the search function or by scanning the bar code on your product.
Troubleshooting Troubleshooting Fault Cause Lighting does not switch • Ambient light level is above the preset target brightness value • Lighting has been switched off manually • There are people in the field of detection • There are sources of thermal interference in the field of detection, such as heating, air-conditioning or moving objects (e.g.
Cleaning and Maintenance Cleaning and Maintenance Maintenance The ceiling-mounted motion detector does not contain any components that require maintenance. The device can only be replaced as a complete unit. Cleaning No corrosive cleaning agents or solvents may be used for cleaning and care of the device.
