- Page 1 MA00940001 09/2015 Operating instructions PD-FLAT 360i/6 mini DALI EP10427503 PD-C 360i/8 mini DALI EP10427510 ESYLUX GmbH | An der Strusbek 40 22926 Ahrensburg | Germany info@esylux.com | www.esylux.com...
-
Page 2: Table Of Contents
Cleaning EC Declaration of Conformity Activation Installation types Connecting the device Wiring diagram Factory settings Operating mode Automatic switch-on Automatic switch-off Switch-off delay time Light value Delay Orientation light PD-FLAT 360i/6 mini DALI 2 / 20 PD-C 360i/8 mini DALI... - Page 3 100 h burn-in function Corridor function LED feedback Sensitivity Electronic ballast DALI parameters Switch input Master / slave function Twilight switch mode Querying the active mode Reset Accessories Disposal ESYLUX manufacturer's guarantee PD-FLAT 360i/6 mini DALI 3 / 20 PD-C 360i/8 mini DALI...
-
Page 4: Using The Manual
If you have any questions that are still unanswered, please visit our website at www.esylux.com or contact our technical helpline directly on +49 (0) 4102 489 489. Safety instructions •... -
Page 5: Description Of The Devices
OPERATING INSTRUCTIONS Device description The ESYLUX ceiling-mounted presence detector is a passive infrared presence detector that responds to moving heat sources, such as people walking. The presence detector is designed for small rooms and passageways that benefit from natural light. -
Page 6: Technical Data
OPERATING INSTRUCTIONS Technical data PD-FLAT 360i/6 mini DALI / PD-C 360i/8 mini DALI Operating voltage DALI 16 V ⎓ Contact Max. 0.8 mm / plug-in terminal Protection type IP 55 Operating temperature range 0 °C to +50 °C Approx. dimensions H 39 mm / mH 60 mm, Ø... -
Page 7: Cleaning
0.6 mm to 0.8 mm . Observe the polarity. For DALI, avoid ring-shaped connection structures as these can cause problems. Other connection structures are permitted PD-FLAT 360i/6 mini DALI 7 / 20 PD-C 360i/8 mini DALI... -
Page 8: Wiring Diagram
/ electronic ballasts. All ballasts are addressed at the same time via the broadcast address. A maximum of 25 DALI/DSi electronic ballasts can be connected. The detector can be mounted on the ceiling in any orientation. PD-FLAT 360i/6 mini DALI 8 / 20 PD-C 360i/8 mini DALI... -
Page 9: Automatic Switch-On
/ presence. The lighting can then be switched manually at any time via remote control or DALI button. For further information, see the instructions for the remote control. PD-FLAT 360i/6 mini DALI 9 / 20 PD-C 360i/8 mini DALI... -
Page 10: Switch-Off Delay Time
/ off of the lighting, the detector is only triggered after a time delay. Example: a passing cloud could potentially cause unnecessary switching. Time delay from dark to light: 5 min. = red LED flashes slowly during this period. PD-FLAT 360i/6 mini DALI 10 / 20 PD-C 360i/8 mini DALI... -
Page 11: Orientation Light
Press this button to permanently switch off the orientation light 10/20% Exit programming mode The set parameters are stored on the detector. Acknowledgement: The blue LED is switched off. PD-FLAT 360i/6 mini DALI 11 / 20 PD-C 360i/8 mini DALI... -
Page 12: Switch-Off Warning
Pressing the dimming button causes the detector to start dimming the connected lighting. Once the lighting reaches the desired level, the value can be determined using the “Eye button”. PD-FLAT 360i/6 mini DALI 12 / 20 PD-C 360i/8 mini DALI... -
Page 13: Semi-Automatic Mode
If fluorescent tubes are operated in dimmed mode during the first 100 hours, the light output and the lifespan of the tubes are significantly reduced. For further information, see the operating instructions for the Mobil-PDi/MDi universal remote control (accessories). PD-FLAT 360i/6 mini DALI 13 / 20 PD-C 360i/8 mini DALI... -
Page 14: Corridor Function
For further information, see the operating instructions for the Mobil-PDi/MDi universal remote control (accessories). PD-FLAT 360i/6 mini DALI 14 / 20 PD-C 360i/8 mini DALI... -
Page 15: Electronic Ballast Dali Parameters
Simply press or press and hold the button to execute the respective function. The DALI button must be set to address 15 to communicate with the detector. The address cannot be changed on the detector. PD-FLAT 360i/6 mini DALI 15 / 20 PD-C 360i/8 mini DALI... -
Page 16: Master / Slave Function
Acknowledgement: The blue LED lights up permanently and the lighting is switched on continuously. Press button C2 Exit programming mode The set parameters are stored on the detector. Acknowledgement: The blue LED is switched off. PD-FLAT 360i/6 mini DALI 16 / 20 PD-C 360i/8 mini DALI... -
Page 17: Twilight Switch Mode
Acknowledgement: The blue LED lights up permanently and the lighting is switched on continuously. Press button C1 Exit programming mode The set parameters are stored on the detector. Acknowledgement: The blue LED is switched off. PD-FLAT 360i/6 mini DALI 17 / 20 PD-C 360i/8 mini DALI... -
Page 18: Querying The Active Mode
Acknowledgement: The red and blue LEDs flash three times. Exit programming mode The set parameters are stored on the detector. Acknowledgement: The blue LED is switched off. PD-FLAT 360i/6 mini DALI 18 / 20 PD-C 360i/8 mini DALI... -
Page 19: Accessories
Mobil-PDi/MDi-universal Remote control EP10425899 Mobil-PDi/Dali Remote control EM10425547 Mobil-PDi/User Switch contact EP10427473 SW DALI Full Automation Switch contact EP10427480 SW DALI Semi Automation Power pack EC10430008 CU PS DALI PD-FLAT 360i/6 mini DALI 19 / 20 PD-C 360i/8 mini DALI... -
Page 20: Disposal
Postfach 1840, 22908 Ahrensburg, Germany (for Germany) or the relevant ESYLUX distributor in your country (visit www.esylux.com for a complete overview) provides a guarantee against manufacturing / material defects in ESYLUX devices for a period of three years from the date of manufacture. This guarantee is independent of your legal rights with respect to the seller of the device.
