- Page 1 INDOOR AUTOMATION MOTION/PRESENCE DETECTOR OPERATING INSTRUCTIONS COMPACT MD/PD BMS DALI-2...
- Page 2 An der Strusbek 40, 22926 Ahrensburg, Germany Details may be subject to change. Copying is only permitted with the written consent of ESYLUX GmbH. This includes translation into other languages and reuse of content for other purposes. 2 / 18...
-
Page 3: Table Of Contents
ALS correction factor ................15 8.1.4 Determining the ALS correction factor ..........16 8.1.5 Memory bank 2 ................. 17 8.1.6 PIR sensitivity ..................18 9. Maintenance Cleaning ....................... 19 10. Disposal 11. EU Declaration of Conformity 12. ESYLUX manufacturer's warranty 3 / 18... -
Page 4: Information About The Document
The current version of this document is available on the respective product page at www .esylux.com and can be printed out in A4 format. Read the operating instructions carefully and observe all safety instructions and warnings. -
Page 5: Manufacturer's Address
Information about the document Manufacturer's address ESYLUX GmbH An der Strusbek 40 22926 Ahrensburg I Germany info@esylux.com www.esylux.com Product identification These instructions apply to the following products: Produktname PD-C 360/8 BMS DALI-2 PD-C 360/8 BMS DALI-2 BK PD-C 360/8 BMS DALI-2 WINSTA CodeI... - Page 6 Information about the document The product name contains essential information about the product: Differentiator Element Description Presence detector Device category Motion detector Series COMPACT Detection angle Specifiedin degrees (°) Detection range 8 / 24 / 32 / 40 Specified in metres (m) Ø diagonally Can be integrated into building management systems...
-
Page 7: Warnings
Information about the document Warnings Warnings are listed at the start of the relevant chapter if there is a risk of a hazardous situation occurring. The preceding signal words have the following meanings: DANGER! This signal word denotes a hazard involving a high level of risk. Failure to observe the warning will result in death or serious injury. -
Page 8: Basic Safety Information
Basic safety information Basic safety information Safety instructions Electrical devices connected to a 230 V mains supply may only be assembled Specialist person- and commissioned by electrical installation technicians or trained electricians, taking country-specific regulations into account. DANGER! Risk of fatal injury from electric shock! Observe the five safety rules: ¾... -
Page 9: Liability And Damages
Product description Liability and damages The device must not be changed, modified or painted – doing so will render any Warranty warranty claims void. The manufacturer accepts no liability for damage caused due to improper use. Check the device for damage after unpacking. If the device is damaged, return it to the place of sale. -
Page 10: Included In Delivery
Installation Included in delivery 1 x presence detector 1 x lens mask 1 x quick-reference guide Installation The following types of installation are possible: with accessory with accessory Installation using the Installation in Installation surface-mounted box* suspended ceilings and using the ceiling flush-mounted boxes installation set* *Required accessories are not included in the scope of delivery. -
Page 11: Connection
Connection Connection DANGER! Risk of fatal injury from electric shock! Before connecting, disconnect the bus voltage supply (e.g. APC) at the ¾ mains. Check that the relevant components have been de-energised. ¾ Connect the DALI-2 BMS presence detector: Observe the following wiring diagram and terminal assignment: ¾... -
Page 12: Initial Operation
Initial operation Initial operation Initial operation is carried out in accordance with the applicable DALI-2 standard. Connect the DALI bus voltage. ¾ A warm-up phase of approx. 25 seconds is initiated. When the green sensor LED briefly flashes three times, the warm-up phase is complete. -
Page 13: Settings
Settings Settings The presence detector is parameterised and controlled only via the application controller (APC). Memory bank 2 The DALI-2 BMS presence detector offers configuration/setting elements that have not yet been defined by the IEC-62386 standards. The following settings can be defined in memory bank 2: •... -
Page 14: Sensor Led Brightness
Settings Value Value bits* Description (decimal) 0000 0011 Sensor LEDs are activated. All events are signalled by the sensor LEDs. Deactivating the 303 instance deactivates the signalling of events in the "Motion detection suppressed" category. This is applied if the sensor does not need to indicate any detected movement. -
Page 15: Determining The Als Correction Factor
Settings The DALI-2 BMS presence detector does not perform an ALS correction. The light value reported via the DALI-2 bus corresponds to the measured light value from the ceiling. The light value reported by the DALI-2 BMS presence detector is limited to 819.0 lux. -
Page 16: Memory Bank 2
Settings 8.1.5 Memory bank 2 To configure settings in memory bank 2, use standard DALI commands for reading/writing to memory banks. Location Description Memory type Value Default RESET value (reference 1) range value (reference 2) 0x04 LED mode, e.g. LEDs activated, 0 …... -
Page 17: Pir Sensitivity
Maintenance Reference 2: Value is reset to this default value by the "0xFE 0x10 RESET" DALI command. Reference 3: Although some DALI-2 BMS presence detector models use more than one PIR sensor, the sensitivity of all sensors for the device can only be set to the same value once. -
Page 18: Cleaning
EMC 2014 / 30 / EU LVD 2014 / 35 / EU RoHS 2011 / 65 / EU Ecodesign 2009 / 125 / EG ESYLUX manufacturer's warranty ESYLUX manufacturer's warranty at www.esylux.com. Technical and design features may be subject to change. 18 / 18...
