Summary of Contents for Swegon SAFEGARD SYSTEM ThermShield FDC-DD
- Page 1 info@safegard.ie Systems House, Unit 33, Southern Cross, Business Park, Bray, Co. Wicklow, A98 HT99 www.safegard.ie +353 1 2761600 Product manual Product manual ThermShield FDC-DD EIS Classified Fire Damper Fire protection Version 1.0.0 Issue Date: 04.03.2025.
-
Page 2: Product Overview
1. Damper frame 2. Galvanized steel casing 3. Actuator 4. Cold smoke seal PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES MAINTENANCE AND OPERATION 1. Fire resistant damper blade 2. Installation contact layer/side FIRE DAMPER - FDC-DD PRODUCT OVERVIEW * The images shown are for illustration purposes only and may not be an exact representation of the product. PRODUCT OVERVIEW Fire dampers are equipped with Belimo electric actuators Fire dampers FDC-DD are used for prevention of fire spread trough... - Page 3 PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES MAINTENANCE AND OPERATION PRODUCT OVERVIEW FIRE DAMPER - FDC-DD PRODUCT OVERVIEW E - Integrity FIRE RESISTANCE I - Insulation 60 - Classification time in minutes CLASSIFICATION S - Smoke leakage ve - Damper installed in vertical compartment FDC-DD fire resistance is tested according to EN 1366-2 “Fire ho - Damper installed in horizontal compartment resistance tests for service installations- Part 2: Fire dampers”.
-
Page 4: Technical Data
PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES MAINTENANCE AND OPERATION FIRE DAMPER - FDC-DD PRODUCT OVERVIEW TECHNICAL DATA Product label Product specifications Pressure drop tables Fire damper casing is manufactured from galvanized 1 - Casing air leakage classification Pressure drop values are described with the “Zeta” values for Nominal sizes FDC-DD 100 - 315 [mm] steel sheet, but on demand can be produced out of:... - Page 5 PRODUCT OVERVIEW DIMENSIONS FDC - DD INSTALLATIONS ACTUATORS Dimensional range ACCESSORIES MAINTENANCE AND OPERATION Diameter Cross section Net area Model [mm] [dm²] [dm²] Ød FDC-DD D100 0,74 0,50 FDC-DD D125 1,17 0,87 FDC-DD D160 1,93 1,55 FDC-DD D200 3,05 2,56 FDC-DD D250 4,79 4,18...
- Page 6 PRODUCT OVERVIEW DIMENSIONS MODELS INSTALLATIONS Casings ACTUATORS FDC-DD ACCESSORIES Cylindrical fire damper with 25 mm damper blade and fire classification up to EI 60S. Sizes range from MAINTENANCE AND OPERATION d100 till d315. FIRE DAMPER - FDC-DD PRODUCT OVERVIEW Actuators Ordering key M230-S (1) Damper type...
-
Page 7: Installation
PRODUCT OVERVIEW DIMENSIONS INSTALLATION INSTALLATIONS The FDC-DD fire damper is always tested in ACTUATORS standardized support frames (both in a rigid wall and in a flexible wall) in accordance with EN 1366-2: 2015. ACCESSORIES The results obtained are valid for all similar support frames which have a thickness and/ or density and/ MAINTENANCE AND OPERATION or fire resistance similar or greater than the one on... - Page 8 INSTALLATION Check for more information about certificate Supporting Wall Supporting construction Tested Construction Sealing installations in the declaration of performance: Type of installation Classification Details construction thickness details underpressure type type Aerated concrete ( ≥ 550kg/m³) Rigid wall ≥ 100 mm EI 60 (ve i↔o)S 300Pa Reinforced concrete...
- Page 9 PRODUCT OVERVIEW DIMENSIONS Rigid wall INSTALLATIONS installation ACTUATORS ACCESSORIES The wall is composed of concrete blocks (minimum density of 550 kg/m³) or MAINTENANCE AND OPERATION reinforced concrete (minimum density of 2200 kg/m³) and with a minimum thickness of 100 mm. Possible damper orientations 0 - 90 - 180 - 270 - 360°...
- Page 10 PRODUCT OVERVIEW DIMENSIONS Gypsum blocks wall INSTALLATIONS installation ACTUATORS ACCESSORIES The wall is composed of gypsum blocks (minimum density of 995 kg/m³), and with minimum MAINTENANCE AND OPERATION thickness of 70 mm. Possible damper orientations 0 - 90 - 180 - 270 - 360° FIRE DAMPER - FDC-DD INSTALLATION 1.
- Page 11 Flexible wall installation PRODUCT OVERVIEW The wall is composed of 2x2 plasterboard boards, DIMENSIONS 12,5 mm thick, installed on a steel frame construction. To fulfill the classification it is NOT mandatory to use INSTALLATIONS the mineral wool inside the wall (mineral wool with density up to 60 kg/m³...
- Page 12 PRODUCT OVERVIEW DIMENSIONS Subframe for installation in flexible wall INSTALLATIONS UW50 UW50 rail ACTUATORS ACCESSORIES d+15 (max) MAINTENANCE AND OPERATION CW50 CW50 rail INSTALLATION FIRE DAMPER - FDC-DD FIRE DAMPER - FDC-DD S+40 Installation with D+15 (max) profiles inserts UW50 rail CW50 UW50 rail rail...
- Page 13 PRODUCT OVERVIEW Minimal installation DIMENSIONS distances INSTALLATIONS ACTUATORS ACCESSORIES MAINTENANCE AND OPERATION FIRE DAMPER - FDC-DD *Minimum distance from the ceiling / wall or other fire dampers!
- Page 14 PRODUCT OVERVIEW ELECTRIC DIMENSIONS ACTUATOR INSTALLATIONS M24-S, M230-S ACTUATORS ACCESSORIES Damper is delivered in closed position. When MAINTENANCE AND OPERATION electric actuator is connected to the power supply, damper blade will open. When the damper reaches the end position (damper open), the electro motor will stop.
- Page 15 PRODUCT OVERVIEW DIMENSIONS ACCESSORIES INSTALLATIONS ACTUATORS Flexible duct connections Flexible duct connec- ACCESSORIES tors are used in HVAC systems for isolation from structure-borne noise, expansion compensation and MAINTENANCE AND OPERATION fire damper connections (total length 150mm, flexible 60mm). Safety grilles Fire damper, safety grille and, if applicable, extension piece are assembled at the factory to form a unit.
- Page 16 PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES MAINTENANCE AND OPERATION FIRE DAMPER - FDC-DD MAINTENANCE TRANSPORT FUNCTIONS MAINTENANCE AND It is not permitted to alter the dampers in any way nor perform any changes to their structure (except for the service procedures described in this manual) without the manufacturer’s OPERATION •...
- Page 17 FIRE DAMPER - FDC-DD Systems House, Unit 33, Southern Cross, Business Park, Bray, Co. Wicklow, A98 HT99 +353 1 2761600 info@safegard.ie www.safegard.ie...
