Swegon actionair A60 Installation Manual

A60 Marine Fire Damper
With ATEX rated Electrical (Schischek) Actuator Installation Manual
TYPE OF PROTECTION 'C' TYPE OF PROTECTION 'C'
ll 2G Exh ll C T6 Gb
ll 2D Exh lll C T85 Db
Sira 11ATEX6259
EN ISO 80079-36:2016
EN ISO 80079-37:2016
1. Description
The actionair Marine Fire Damper is tested and approved
for fitting to class A-0 A-15 A-30 A-60 divisions (bulkheads
and decks), when suitably insulated.
A-0 must have insulation over case.
2. Tests, approvals and certification
• Lloyds Register Approved.
• DNV-GL Approved.
• ABS Approved
• USCG Approved.
• Transport Canada Approved.
• MED Marine Equipment Directive Compliant.
• Fire tested to the latest IMO FTP code & in compliance
with the international convention for the safety of life
at sea (SOLAS)
• Sira certification (Ex) category 2 equipment
•
•
3. Health and Safety
•
Do not introduce any items, fingers or limbs between the
blades.
•
•
4. General Information
•
2923/YYYY
YYYY Denotes the
year the Wheel mark
•
is affixed to damper
•
5. Installation - see below.
6. Maintenance & Cleaning
•
1/ Galvanised Steel casing and 430 Stainless steel
blades, only suitable for installation in dry filtered
systems.
Corrosion Tested - EN60068-2-52 severity 2 conditions
Vibration Tested – EN60068-2-6 (5Hz to 350Hz @2g)
Care must be taken when installing and inspecting
dampers, as they are likely to close without warning
due to loss of electrical power, or a temperature rise in
the ductwork. This is their prime function.
Larger dampers are heavy and must be handled in
accordance with current local regulations and good
practice.
All wiring should be carried out in accordance with the
wiring details provided, to the IEC regulations.
The actionair Marine Fire Damper is suitable for both
vertical and horizontal applications, with airflow in
either direction.
The dampers tested to IMO fire test procedure,
Annex 1 Pt 3, are normally open, and fail-safe to the
closed position. The Actionair Marine Fire Dampers
are supplied with the blades in the fully interlocked
closed position to avoid damage during transit and
installation. It is recommended that the dampers
remain closed until actual date of commissioning.
All fire dampers are life safety products and must
be treated with care during handling, storage and
installation.
Actionair Marine Fire Dampers are designed for
applications in normal dry filtered air systems
and should be subjected to a planned inspection
programme.
Dampers are supplied in two casing and blade material
options: -
